  1. Developing a VR System Mei Yii Lim

  2. System Development Life Cycle - Spiral Model • Problem definition • Preliminary study • System Analysis and Design • System Development • System Testing • System Evaluation • Refinement

  3. Case Study: MY Virtual Graffiti System

  4. Introduction • ‘graffiti’ - Greek word ‘graphein’ • Modern graffiti - New York, tagging using water resistant marker • Today - using aerosol spray • Rude, humorous, political or constituting vandalism and are generally illegal

  5. Problem Objectives • What do you aim to achieve? • Solution to the problem of illegality • Preserves and documents art works • Virtual spray on virtual buildings • Flexibility and natural interaction • Realistic reproduction of the spray • User-friendly and intuitive interface

  6. CAVE

  7. Problem Definition

  8. Problem Definition • Define the problem you are trying to solve • What are the major issues?

  9. Project Benefits • What are the benefits of the project? • Why is it so important? • Expression of opinions, creativity lawfully • Coping with society’s problems • London councils - £13m and graffiti committee - £100m spent annually on cleaning up graffiti • New type of art, uncover hidden talent

  10. Project Management • Project scheduling • Divides work into smaller chunks - Gantt Chart • Risk Analysis • Degree of uncertainty or potential problems • Eg. lack of knowledge , inappropriate or difficult to use interaction devices, simulation algorithm, underestimation of time

  11. Project Management continued… • Risk Planning • Best way for project with users as target - involve them • Trial and error • Project schedule must be realistic

  12. Preliminary Study

  13. Literature Review • Find out the state-of-the-art • Who has done what • What can be improve • What should be avoided

  14. Literature Review of MYVG • Eschler & Stricker 03 (Fraunhofer IGD) • projection filled totally by a 2D wall • Dave Pape - ‘Vandalism’ • alter existing artworks, 3D paintings and sculptures • Lang • Virtual Graffiti Painter and Light bombing • MobSpray (mobile application) • http://www.mobspray.com/indexphp

  15. System Analysis

  16. System Analysis • Understand the requirements of the system you are going to develop • Determine ‘what’ is to be accomplished • To ensure successful system development • Human Computer Interaction concepts

  17. Rapid Iterative Prototyping • Offers the best approach for system which accurate requirements can not be defined at its early stage • Prototype – a mechanism for identifying the actual requirements • Iterative and corrective cycle

  18. Rapid Prototyping Development Cycle

  19. Requirements Elicitation • Fact-gathering – active manipulation of conditions or passive observation of people • Researching and reviewing existing documents • Individual interviews • Mailing list • Observation – demonstration from experts • Questionaires - evaluation

  20. Analysis with Justification • Every choice must be justified • Why a particular device or methodology is chosen and not the others?

  21. Analysis Result of the MYVG system

  22. MY Virtual Graffiti System • CAVE Environment • Graffiti using VR technologies • 2 sensor gloves (pinch gloves) sensors

  23. Space Orb 360º (6 degree of freedom) Stereo glasses Tracking system Dummy spray can with sensor MY Virtual Graffiti System

  24. Use cases – scenarios of usage Analysis model – subsystems of the end product Object-Oriented Model

  25. System Requirements Specification • Hardware requirements • Software requirements • Functionality description • Non-functional requirements • Interface specification • Design constraints • System validation and verification criteria

  26. System Design

  27. System Design • How to accomplish the proposed functionality? • How are all the VR devices linked together? • Representation of the system

  28. Architectural Design • UML class diagrams - shows all available classes

  29. Architectural Design … • Object-relationship model – static model, reflects the object classes and their relationship

  30. Architectural Design … • State diagram – dynamic model • Describes the behavior of the system, events

  31. Architectural Design … • Sequence diagram – illustrate each significant interaction between objects

  32. Algorithm Design • Pseudocode – description of the program • Example – a method to create scene METHOD createScene char*(filename) returns pfScene* Generate scene state Add lighting Set traversal mask Load file RETURN scene END

  33. Scenegraph

  34. User Interface Design • A useful system with a poor user interface = non-functional system • HCI golden rules • Know the user population • Reduce cognitive load • Engineer for errors • Maintain consistency and clarity

  35. WELCOME TO VIRTUAL GRAFFITI ! SPRAY MODE BUTTON A / LEFT PINKIE CLEAR BUTTON B SAVE BUTTON C / LEFT MIDDLE NAVIGATE BUTTON D, PS / RIGHT INDEX RESET BUTTON E EXIT BUTTON F CLOSE MENU RIGHT PINKIE

  36. SPRAYING MODE SPRAYING RIGHT MIDDLE COLOUR LEFT MIDDLE NOZZLE LEFT RING MAIN MENU LEFT PINKIE NAVIGATE RIGHT INDEX CLEAR RIGHT RING / BUTTON B CLOSE MENU RIGHT PINKIE

  37. Denote the size of the nozzle Denote the color of the nozzle 3D icon that appears while spraying S

  38. System Development and Testing

  39. System Development • Programming • Example of Challenges • Format incompatibility • Incorrect hit points Correct Ray Bounding Plane A box

  40. Single ray Multiple rays Number of rays

  41. System Testing • Tedious but essential for quality assurance • Formal technical review • Unit testing • Integration testing

  42. Risk Monitoring • Throughout the whole life cycle to ensure that everything is under control • Users’ opinions were checked • Project progress was monitored

  43. System Implementation and Evaluation

  44. System Implementation • Putting the system into operation • Prototyping approach – implementation is parallel with the development and testing phases

  45. System Evaluation • Acquire feedback for eventual improvement • Formative evaluation – usability evaluation • Can be repetitive • Each evaluation process serves as guide for changes in subsequent iterations

  46. Example – Initial Evaluation • Half a dozen subjects

  47. Refinement • Menu shift and simplification • User manual was provided • More flexible interaction – Space Orb or pinch gloves • Dummy spray can • Allow deactivation of menu • Bigger paint particles for wider coverage
