  1. Application Models for utility computing Ulrich (Uli) Homann Chief Architect Microsoft Enterprise Services

  2. Session Objectives And Takeaways • Highlight the looming energy crisis in the data center • Understand the application designers role in reducing energy consumption • Understand how virtualization can support you in going Green

  3. “Sins” of our fathers

  4. Synchronicty is Dead

  5. “Success” - a design tenet

  6. SOYP – capacity planning methodology

  7. Application architects – Belts-and-suspenders people?

  8. Solution approaches

  9. Constraint based planning Energy Spend • You can: • Increase DC count • Hold # DC • Decrease # DC • With a corresponding • Increase Capacity • Hold capacity steady • Decrease Capacity Service Units Available Service Units Consumed • You can: • Increase DC size • Hold DC Size • Decrease DC size • With a corresponding • Increase power $$ • No change • Increase flexibility at a cost of faster to full Data Center #’s of DC’s Key lesson: Servers use vital resources whether on or off

  10. Where does capacity go? Data Center Reserved Capacity Safety Margin Waste Planned Capacity Limit Benefit Application design most effectively impacts waste % Overhead “Run It Full”

  11. A Responsible Dynamic Topology? SQL ASP ASP ASP ASP ASP IIS IIS IIS IIS IIS

  12. Segment your solution Service Model <ITService> <Site> <Server Group> Simple topology view <Server> <ServerRole>

  13. Server (workload) segmentation • Server Groups manage like servers (workloads); • Today Server Groups are static – numbers of instances are effectively fixed; • Enable your solutions and deployment to allow the infrastructure to reduce and increase the numbers of servers in any given server group at any given time; The term “server” doesn’t mean what it used to anymore!

  14. Server Role segmentation • Introduce Server Roles as part of your solution • Going from component to Services is not granular enough • Group related functionality in Server Roles • E.g. Payrolls, general ledger • Plan your Services deployment with Server Role isolation in mind • Allow the infrastructure to dynamically start and stop server roles (deployed as VM’s)

  15. Start slow and grow in ‘scale units’ • Pete’s SharePoint order (representing max growth): • 50,000 users • 20,000 team sites • 150MB/site • Responses per second: 100 • Monitoring counters in the operational configuration and monitoring environment (SC OM 2007) trigger growth (or shrink) provisioning once the specific capacity driver hits 80% of specified value: • Growth based upon RPS (growth type A): initial size – 99 RPS; counter is set to 80 RPS • Growth based upon content db size (growth type B): initial size – 0.8 TB; counter is set to 0.7 TB

  16. Projected Load Profile

  17. Load by Time of Day

  18. Enable Virtualization and "Run Full" • Decompose application into work loads (servers) that can be dynamically scheduled • Break dependencies between your product’s services • Allow customers to pick time of day, day of week, etc, and allocate capacity of individual parts dynamically • If one server role is “out” right now, application should not break • Define scale units for your server roles so that they can be reduced in size to a minimal level and grown in chunks • Application server roles should not break if resources get allocated by quota by application role • (20% CPU for you, 60% for you) • Monitoring can no longer assume all parts are “on” at all times. • Server roles become dependency bound for scheduling of parts that need to run together. • If inseparable parts, put in same server role, deploy in same image • Break up the work types that your application does so they can operate out of band over units of time • Synchronicity (scale out) is not by server. It is by virtual server image. • Parts communicate across images

  19. Resources • Green Computing Architecture Journal: http://msdn.microsoft.com/en-us/architecture/dd393308.aspx • Specific article about app patterns: http://msdn.microsoft.com/en-us/architecture/dd393307.aspx
