MAGNETISM

dawnv avatar
dawnv
18 diapositives · 427 Views · Jan 02, 2020

Magnetism involves tiny regions in metals, known as 'domains', that function like miniature magnets. Magnetic fields are areas where magnetic forces exist, influenced by electric currents as demonstrated by Oersted's 1820 experiment. The Earth possesses a vast magnetic field, resembling a colossal bar magnet, with magnetic field lines stretching from the geographic north to south poles. This field protects Earth from solar wind, creating phenomena like the Aurora Borealis and Aurora Australis. Understanding magnetism is crucial in fields ranging from physics to geology.

#magnetism #magnetism ppt #powerpoint #presentation
MAGNETISM - slide 1
01 / 18MAGNETISM
1 / 17

Télécharger la présentation

MAGNETISM
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. MAGNETISM

  2. The metals affected by magnetism consist of tiny regions called 'Domains' which behave like tiny magnets.

  3. Magnetic fields • Magnetic fields are areas around a magnet where there is a magnetic force. • You can investigate these using a plotting compass or iron filings. • Like poles repel and unlike poles attract.

  4. Unlike poles attract. North and South. • Like poles repel. North and north. South and south

  5. Field lines run from North to South. The magnetic field is strongest at the poles.

  6. The Earth itself has a huge magnetic field - as if it had a huge bar magnet embedded at its centre. The Earth’s magnetic field lines emerge from near the geographical north pole and re-enter it at the south pole.

  7. Angle of Declination • Difference between true north and magnetic north

  8. Dip Angle • Needle points down. Why? • Shape of the world magnetic field

  9. Now show them our compasses

  10. Final Pattern Notice field moves from north to south

  11. Oersted’s Experiment Hans Christian Oersted (1777-1851) Hans Christian Oersted discovered in 1820 that an electric current near a compass causes the compass needle to be deflected. Oersted's experiment showed that every electric current has a magnetic field surrounding it.

  12. Electromagnets • A wire with a current in it has a magnetic field around it. • The strength of a magnetic field can be increased by wrapping a wire around an iron bar

  13. Electromagnet • A soft iron rod has no magnetic field • When current flows in the wire the soft iron becomes magnetised so a magnetic field is detected by the plotting compasses.

  14. Notice the compasses point at right angles to the current

  15. The Earth’s magnetic field extends far into space. It is called the “magnetosphere.” The solar wind is constantly bombarding the Earth’s magnetic field. Sometimes these charged particles penetrate that field. These particles are found in two large regions known as the Van Allen Belts. When the magnetic particles from the sun, called “solar wind”, strike this magnetosphere, we see a phenomenon called…

  16. When the magnetic particles from the sun, called “solar wind”, strike this magnetosphere, we see a phenomenon called… The Aurora Borealis in the Northern Hemisphere And the Aurora Australis in the Southern Hemisphere
