  1. Apply Program Model Checking Qian Ling Oct. 28, 2004 Bell Labs Research China

  2. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  3. Motivation • Testing of concurrent programs • VMS TTS Server Program • OS Adapter Project • POSIX thread impl. on VxWorks 5.4 • Progress in Program Model Checking • New tech and tools developed

  4. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  5. SW Quality Control Tech • Software Testing • Unit/integration/system test • Functional test, Conformance test • Stress test • API test, etc • Code Review • Peer Review • Design Review • Program Model Checking • Formal Method • Software Verification • Software Quality Assurance

  6. Software Testing “Sequential, Stand-alone”

  7. Code Review “Static”

  8. Facing Concurrent & Distributed Software It is not too surprising that the behavior of even non-buggy distributed applications can easily defy our human reasoning skills. Gerard J. Holzmann

  9. Facing Concurrent & Distributed Software, cont Really Hard Issue • Deadlock • Livelock, starvation • Underspecification • unexpected reception of messages • Overspecification • Dead code • Violations of constraints • Buffer overruns • Array bounds violations • Assumptions about speed • Logical correctness vs.real-time performance

  10. What is Model Checking? • [Clarke & Emerson 1981] “Model checking is an automated technique that, given a finite-state model of a system and a logical property, systematically checks whether this property holds for (a given initial state in) that model.” • Model checking tools automatically verify whether M |= φ Holds where M is a (finite-state) model of a system and property φ is stated in some formal notation • Problem: state space explosion • SPIN is one of the most powerful model checker

  11. Classic v.s. Modern MC WaterfallSW Lifecycle Process

  12. Classic Model Checking

  13. Modern Model Checking • Abstraction: To fight with explosion • Focus on Modern Model Checking

  14. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  15. Tools for program model Checking • SPIN • Gerard J. Holzmann (Bell-Labs), 1991~ • Proving the correctness of process interaction, asynchronized control • Verisoft • Patrice Godefroid (Bell Labs), 1996~ • Runtime analyses for multi-process programs • SLAM • Thomas Ball (MS Research), 1999~ • Static analyses for “API Usage Rules” in programs

  16. Tools for program model Checking, cont • Eraser • Stefan Savage (University of Washington) & DEC, 1997~ • Dynamic detecting data-race in lock-based multithread programs • FLAVERS • Matthew B. Dwyer, L. A. Clarke (University of Kansas State/Massachusetts Amherst) &DoD, DAAH, NSF, IBM… , 1999~ • Check if all executions adhere to specification, data flow analysis, stack • SMV • CMU, 1992~ • Symbolic model checker • …

  17. Tool Comparison • Modeling Languages • Static Analyze v.s. Dynamic • Explicit State space? • Scope of verification • Safety only • Acceptation cycle, etc • Stages in development • Design phase • Code Ready • Incremental development

  18. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  19. The SPIN Model Checker • SPIN = Simple Promela Interpreter • is a tool for analysing the logical consistency of concurrent systems, specifically of data communication protocols. • Concurrent systems are described in the modelling language called Promela. • state-of-the-art model checker

  20. Promela • Promela = Protocol/Process Meta Language • allows for the dynamic creation of concurrent processes. • communication via message channels can be defined to be • synchronous (i.e. rendezvous), or • asynchronous (i.e. buffered). • resembles the programming language C • specification language to model finite-state systems

  21. Modern Model Checking with SPIN

  22. Foundation of SPIN • Based on automata theoretic model • System Model • Translate process tmpl to automaton • State space=product of all automata • Global behavior modeled by an automaton • Specification • Correctness requirement in LTL formula • Convert LTL to Büchi automaton • Verification • global automaton× Büchi automaton • (Accepted language = empty) not satisfied • (Accepted language ‡ empty) satisfied behaviors • SPIN formalize the erroneous behaviors • Prove such behavior are impossible • Provide detail matched behaviors Vardi & Wolper 83

  23. Algorithms of SPIN • Nested Depth-First Search (Cycles detection) • 1st search: from initial state, find accepting states • 2nd search (nested): from all accepting states • LTL to Büchi automaton • Normalize LTL formulasrecursive conversion • Make use of Promela condition statement • Partial Order Reduction • Represent classes of execution sequence with one single path, statically • Memory Management • State Compression (60%~80% reduction) • Separate local state (small) and global state • Global state use index to refer to local state • Bit-State Hashing (Improve problem coverage 1) • 2 bits are used to store a reachable state • 2 bits:F1(S1) = M[m1], F2(S2)=M[m2] • Collision problem Problem coverage = M / (N*S) M=2^m: memory space in bytes N=2^n: true # of Reachable states S=2^s: bytes for each state

  24. Debug with SPIN • Correctness Requirement: • Inline assertions • assert(…) • End-state label / deadlock • endxxx: • Progress-state label / livelock • progressxxx: • Acceptance-state label • acceptxxx: • LTL properties • Make use of LTL specification • Never-claims • never {…} Commonly Used

  25. Extensions to SPIN (1) • dSpin = dynamic SPIN • R. Iosif & R. Sisto, Kanas State University, 1999~ • Solve Limitations in SPIN, • Object creation & deletion • Pointer and reference variables • Polymorphic function calls • Solutions • Memory management • Dynamic memory allocation • Reference mechanism • Functional management • Function declaration, call and reference • Local scoping

  26. Extensions to SPIN (2) • FeaVer/Modex = Model Extractor for C • Gerard J. Holzmann, Bell Labs, 1998~ • Extract Promela model from ANSI C • 3 phases: • Parsing: C  Full Parse Tree • Interpretation: Tabled Abstraction • Optimization • Applications: • Lucent PathStar™ Access Server

  27. Extensions to SPIN (3) • JPF1/JPF2 = Java Path Finder • Automated Software Engineering Group, NASA • JPF1, since 1998 • A translator from Java 1.0 to Promela • Suitable for multi-threaded Java programs • Applications • Find deadlocks in Game Server • Analyze Remote Agent • JPF2, since 2000 • Work on Java Byte Code, 100% Java support • Garbage Collection • Static analysis dependencies for partial-order reduction • Contain runtime race-cond analysis by “Eraser” Algorithm • Use Bandera to calculate slices

  28. Extensions to SPIN (4) • Bandera Toolset • Santos Laboratory, since 2000 • source code  FSM model checker, SPIN/SMV • Analyze, • Abstraction • Transformation • More than just a SPIN extension!

  29. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  30. VeriSoft • A tool for systematically testing concurrent reactive software • Stateless search, for: • Deadlocks • Livelocks • Assertion violations • Divergence • Replay Error Scenarios • Applications: • 4ESS Heart-Beat Monitor debugging and unit testing • WaveStar 40G R4 integration and system testing • 7R/E PacketStar Gateway Solutions Feature Server unit testing • CDMA Call Processing Library testing

  31. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  32. SLAM • Check Temporal safety property in sequential C programs • Based on Boolean Program • Solutions: • Preparation: • Model conterexample in SLIC • C  BP (C2BP) • Verification: • BEBOP: perform reachability analysis of BP • NEWTON: refine BP by discover additional predicts • Error in BP  Error in P • Applications • API in Windows XP device drivers

  33. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  34. VMS TTS Server • Multi-threaded • 1 server thread • 1~10 tts working threads • 1~10 IBM viavoice synthesis threads • Asynchronzed Message Q • server  working threads • Synchronized • synthesis threads  working threads

  35. VMS TTS Server, cont • A Sequence Diagram

  36. Purpose • Check safety properties • potential deadlocks • Unexpected end states • Unreachable code • Check if it works for 10 V V instances • Currently we have only 1 instance • Check about the Msg Loss

  37. Result in Simulation • No Error found in program (simulation) • 1 bug found in promela model • Deadlock in server thread • Forget to add lock when access globals in abstr. • There are un-reached code • Abstraction is not a easy work • Programs works for 10 threads • There are message loss • Under high stress • Every thread are full loaded • Increase # of buffers  fewer loss • Increase # of instance  fewer loss • Decrease synthesis delay • As for performance • Simulation is not trustable

  38. Result in PAN

  39. Restrictions, Lessons • No Timer in Promela • Use loop to simulate a timer • Different behavior in simulation & PAN • Hard to locate an error • Too many messages • Generally, subtle errors occur after quite a long time • Platform dependant APIs are hard to be abstracted • What is the size of the Win32 thread message queue?

  40. Agenda • Motivation • Program Model Checking • Program Model Checking Tools • The Spin Tool • The Verisoft Tool • The SLAM Tool • Use Spin tool to check TTS Server • Future Work

  41. Future Work • More applications • OS Adapter Project • POSIX thread • … • Tool enhancements • Locate bug easier ? • Timer ? • Automata  LTL ?

  42. Reference Site • SPIN • http://spinroot.com/spin/whatispin.html • Verisoft • http://cm.bell-labs.com/who/god/verisoft/ • SLAM • http://research.microsoft.com/slam/

  43. Suggestions! Thanks! &
