  1. MS BMI

  2. MS BMI Channel Request Get SDDCH

  3. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established

  4. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.)

  5. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request)

  6. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering

  7. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP

  8. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP Call Proceeding

  9. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP Call Proceeding Alert

  10. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP Call Proceeding Alert Assignment CMD

  11. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP Call Proceeding Alert Assignment CMD Assignment Complete

  12. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP Call Proceeding Alert Assignment CMD Assignment Complete Connect

  13. MS BMI Channel Request Get SDDCH Immediate Assignment RR connection established SABM(CM Service Request - Call Orig.) UA(CM Service Request) Authentication and Ciphering SETUP Call Proceeding Alert Assignment CMD Assignment Complete Connect Conn Ack
