  1. Micro Electronics Processing Lab Wet and Dry Oxide Growth Team 1B Sudipta Bera Matthew Berg Cooper Swenson Glenda Anderson Dana Olson

  2. Introduction • RCA Clean • Theoretical Oxide Thickness Calculated • 2 Different Sets of Data 2 1 2 3 4 5 6 1 3 Group 1B Group 2B

  3. Concentration Gradient In Furnace Gas Inlet CA inlet Concentration of oxidizing gas decreases as it reacts with Silicon surface Wafer Position 4 Wafer Position 3 Wafer Position 2 CA inlet > CA outlet Wafer Position 1 CA outlet Front Of Furnace

  4. Results Theoretical Thickness 530 A

  5. Results Theoretical Thickness 1250 A

  6. Diffusion Of Gas Stagnant Gas Layer SiO2 Si Substrate Diffusion of O2 or H2O

  7. Results Theoretical Thickness 5299 A

  8. Results Theoretical Thickness 6610 A

  9. Conclusions • Temperature and Oxidant Effects • Position in Furnace has Large Impact on oxide thickness • Random Growth on Wafers • Variations From Theoretical Calculations Group B1 Group B2 Theoretical 530 5299 1250 6610 Average 560 2500 1000 4250 (Dry) (Wet) (Dry) (Wet)

  10. Variation Of Oxide Thickness On Wafer • Wafers have thin initial layer of oxide before heating. • During heating, oxidizing gas will diffuse through initial layer and grow in non-uniform manner. • Regions of thin initial oxide layer will grow fastest and regions of thick initial oxide layer will grow slowest. • Variations in thickness for wet oxide are greater than dry oxide due to faster diffusion rate of H2O.

  11. Average Thickness On Wafer – Group 2B Wet Oxide

  12. Average Thickness On Wafer – Group 2B Dry Oxide
