  1. Interacting Process Classes Abhik Roychoudhury National University of Singapore Joint work with Ankit Goel and P.S. Thiagarajan

  2. Component Behavior • Communicating Active Components • Focus is more on the communication than computation. • Modeling and simulation of component interaction • Can be extended to support model checking. • Many similar components can be grouped into “classes” in the specification.

  3. Network of FSM • Describe each component as a finite state LTS • Labels on the edges correspond to (multi-party) interactions. • Interactions may be a protocol snippet • Bi-directional communication • Captured by a guarded Sequence Diagram • Concrete Execution Semantics

  4. CTP • Communicating Transaction Processes • Network of FSMs • Intra-component control flow not suppressed. • Actions in FSMs denote Transactions • Communication between components. • Executable assuming that in our specs • A component can decide locally which transaction to take part in.

  5. System or Requirements ? • High-level System description • Modeling and Simulation at high level • Combination of state-based and MSC based modeling • Appl. in Reactive Embedded Systems • Contrast with Live Sequence Charts • Executable Requirements Description • No state-based description, extends MSCs

  6. The problem addressed here • Systems with many similar components • Telecommunications • Phones, Switches • Transportation • Railways – Rail-shuttle, Terminal-controllers • Avionics – Aircraft controller • Specify and execute these systems without suffering blow-up.

  7. A Simple Example (ActNode) *  ( (ActNode)*Txsnd ) Txsnd s1 Erase Txrcv data Store s2 Role snd Role rcv (a) TSNode (b) Transaction Tx

  8. Highlights - Specification • Combine • Intra-process control flow. • Scenario based interactions between processes. • Process Classes • Classes of Active objects. • Objects of the same class have similar control flow. • Objects of the same class may interact via scenarios. • Associations between objects • E.g. Phone objects engaged in a conversation.

  9. Highlights - Execution • The execution semantics is symbolic. • States of concrete objects not directly represented • Partition concrete objects of a process class • Current control state • History of MSCs executed • different histories may lead to diff. futures from the same control state. • Maintain # of objects in each partition • No need to maintain identifiers of behaviorally indistinguishable objects.

  10. Questions about Specification • Each process class described by a FSM • Arcs in the FSM labeled with transactions. • Transaction = Guarded MSC • Guard needs to hold for Tx. to be enabled. • Guard on MSC history – Regular Expressions • Prevents blow-up of the FSM for each class. • Many processes can participate in a Tx • Two objects of the same class can participate in a transaction ?

  11.  (* Tx snd ) * A node object can play diff. roles in a Tx. execution, Maintain seq. of Tx role as local history of process objects. Guard on strings of Tx role Last action not a send Data Txsnd snd rcv s1 Transaction Tx – Comm. between network nodes Txrcv Store s2

  12. Concrete Simulation Txsnd Txsnd Tx Txrcv Txrcv Store Store The number of nodes could be very large, consider 10^7 phones in a region of a telecom network

  13. Symbolic Simulation s1 Txsnd Txsnd s1 Tx Txrcv Txrcv Store Store s2 s2 ( s1 -> 2, s2 -> 0 ) ( s1 -> 1, s2 -> 1) But this is not (yet) accurate since the transactions are guarded.

  14. Behavioral Partitions • Group active objects into “Behavioral Partitions” • Control state of Process class’s FSM • Automata states for each history-based guard of the process class. • Maintain count of objects in each behavioral subclass during simulation. • Object names not mentioned anywhere.

  15. Illustration of Behavioral Partitions Erase, Store – No communication Guards of Tx are * , (* Txsnd)  = {Erase,Store,Txsnd, Txrcv } Txsnd, Erase s1 Txsnd Txrcv Store  Txsnd t u2 u1 Tx snd s2 Tx snd *  (* Tx snd ) Behavioral partitions (s1, t, u1) (s1,t,u2) (s2,t,u1) (s2,t,u2) Tx snd rcv

  16. Symbolic Simulation Txsnd, Erase s1  Txsnd t u2 u1 Txrcv Tx snd Tx snd Store One step of symbolic simulation (s1, t, u1) = 100 (s1,t,u2) = (s2,t,u1) =(s2,t,u2) = 0 s2 Tx (s1, t, u1) = 98 (s1,t,u2) =1 (s2,t,u1) =1 (s2,t,u2) = 0

  17. Dynamic Object Associations Dynamic relation Wait-for-Ack Tx inserts (snd, rcv) to Wait-for-Ack Ack checks (rcv,snd)  Wait-for-Ack Ack deletes (rcv,snd) from Wait-for-Ack s Txrcv Acksnd Ackrcv Txsnd Node3 t1 t2 Node1 Connect Node1/Node2/Node3 Node2 Tx checks (snd,rcv) in Connect

  18. Simulation Execute Tx Txrcv Ackrcv Acksnd Txsnd Node1/Node2/Node3 No distinction among objects of the same class.

  19. Simulation Execute Tx -- executed Execute Tx Wait-for-ack = { ( ) } Txrcv Acksnd Txsnd Ackrcv Node1/Node2/Node3

  20. Simulation Execute Tx -- executed Execute Tx -- executed Wait-for-ack = { ( ), ( ) } Txrcv Ackrcv Acksnd Txsnd Denote behavioral partitions of Node1/Node2/Node3 -- No object Identifiers Node1/Node2/Node3

  21. What do we have ? But, the proof of the pudding …

  22. … is in the eating ! • Cuts simulation time/memory for realistic controllers • CTAS weather update controller • Rail Shuttle system from Paderborn • Benchmarks for State & Seq. Diagram based modeling • Rail car (from Live Sequence Charts) • Many cars operating in two parallel cyclic paths • Many process classes – cars, cruisers, proximity sensors • Telephone switch network (from SPIN model checker) • Simulator found realizable bugs in the examples • Deadlock scenarios in CTAS weather controller

  23. A (more realistic) example • NASA CTAS • Automation tools for managing large volume arrival air traffic in large airports. • Final Approach Spacing Tool • Determine speed and trajectory of incoming aircrafts on their final approach. • Master controller updates weather info. to “clients” • controllers using inputs to compute aircraft trajectories.

  24. Weather update subsystem 1 CM 1 1 connected itsWCP 0..N 1 Clients N WCP 1 WCP -- Weather Control Panel (contains weather info.) CM -- Communications Manager (transfers info from WCP to clients) Clients – Weather aware, seek connection with CM

  25. Usage of Process Classes • Weather aware Clients • Class of similar processes • Communicating among each other (in general) and with other process classes. • Behavior can be captured succinctly … • Through an FSM which captures all clients • But what about system simulation ? • No need to maintain each client process’s state separately !!

  26. Experiments Simulation stopped after 1000 transactions

  27. Wrapping up • Combining intra-component and inter-component style to produce an executable spec. is challenging. • CTP formalism • Avoiding blow-up in specification and execution of such specs. due to many similar processes. • Symbolic execution semantics • Many other challenging issues • Hierarchy of process classes • We only consider a collection of process classes !!

  28. Overall Summary • Scenarios are useful to capture requirements, test cases, possible behaviors. • Can blend into later stages of system design as well • Test cases tried on actual system • Collection of scenarios – HMSCs • Understanding system behavior at high-level

  29. Overall Summary • Developing executable specs. based on scenarios • Directly executing and testing out inter-component specifications. • LSCs – completely suppress intra-process flow • CTP – combine intra process flow with scenarios • Efficient execution of these specs. is an issue • Symbolic execution of process class specifications. • Code generation • Backward association between models and code.

  30. Other Work • Code generation of a restricted subset of the modeling language to SystemC • SystemC supports • description of mixed HW-SW designs • Performance simulation • Our work pushes the abstraction one level • Support rough perf. sim of UML descriptions • Tried out various SoC bus protocols (AMBA from ARM) and other SoC protocols
