Presented by: VARSHA BHAMBHANI
Outline • Fractional controller was designed at CSOIS (IFAC2008) based on PID controller designed by Lasse Eriksson (ACC2007) • This paper is extension of ACC2007 work by Lasse Eriksson (CDC2007) • Filters of different orders are used to get any desired jitter margin at slight decrease in performance. • Our goal:- extend IFAC 2008 work and apply to networked control system ( Smartwheel)
