Advanced Drawing Commands in Computer-Aided Drafting
This lecture covers essential modify drawing commands in Computer-Aided Drafting (CAD) for the third semester of Engineering Architecture at Pharos University. Key topics include the Offset, Trim, Extend, and Fillet commands, as well as the use of Polyline, Distance, and Radius. Additional techniques like Chamfer, Divide, Explode, and properties editing are discussed, along with essential commands such as Move, Copy, Mirror, Rotate, Scale, and Stretch. The lecture also emphasizes the use of Array commands for both rectangular and polar distributions to enhance drafting efficiency.
Advanced Drawing Commands in Computer-Aided Drafting
E N D
Presentation Transcript
Pharos University Faculty of Engineering Architecture Department 3rd semester 2013/2014 COMPUTER AIDED DRAFTING 1 AE (151)
Lecture 2 Modify Drawing Commands
Modify Drawing Command: - Using Offset command 1- Distance 2- Through - Using Trim command - Using Extend command - Using Fillet command 1- Poly-line 2- Radius 3- Trim - Using Chamfer command 1- Poly-line 2- Distance 3- Angle 4-Trim 5- Method
- Using Divide command 1- Controlling divide points 2- Connections between divide points - Using Explode command - Using Properties editing - Using Match – properties editing Modify Drawing Command: - Using Move command - Using Copy command 1- Single copy 2- Multi copy - Using Mirror command - Using Rotate command - Using Scale command 1- Scale by factor 2- Scale by reference - Using Stretch command - Using Array command 1- Rectangular distribution 2- Polar distribution
- Array command 1- Rectangular distribution 2- Polar distribution
