  1. Loads on Structures http://ceeserver.cee.cornell.edu/jfa5/cee371/

  2. Structure = man-made object which must transmit or survive loads to perform a desired function

  3. Equilibrium! Must provide a “path” to transmit or resist the loads Must provide serviceability, strength and stiffness under appropriate levels of loads

  4. The Structural Design Process • Conception • Loads analysis • Structural analysis • Strength analysis/Detailed design • Implementation/Construction • Evaluation of performance
