  1. Open wireless standardsWireless M-Bus, KNX RF, ZigBee, 6LoWPAN Hallvard Moholdt, Technical Solutions Manager Ørjan Nottveit, Product Line Manager www.radiocrafts.com

  2. Agenda • AMI overview • Wireless M-Bus • NTA8130 • OMS • KNX RF • ZigBee • Total cost of ownership (TCO) • Q&A

  3. AMI WAN NAN HAN/LAN

  4. HAN/LAN Gateway

  5. Why open standards • Open standards enable interoperability • Open standards give multi-vendor ecosystem and hence lower cost • What are open standards • EN/IEC/ISO • IETF • Industry standard

  6. Wireless M-Bus

  7. figawa,

  8. Wireless M-Bus 3 Key points • Only European Norm for wireless metering • Field proven in millions of meters • Supported by all major metering companies in Europe

  9. Wireless M-Bus Basics • Slaves reporting to Master (concentrator) • Slave receives acknowledge with minimum time response Message decryptionand acknowledge within2-3 ms ((())) ((())) ((())) Meter wakes up and transmits reading(gas: each 30 min) ((())) ((())) Water: TX each 4 hours (with randomtime-spread) Ack can contain ’shut valve’ command ((()))

  10. Background • Standardization work -> Cenelec, TC 294 • EN 13757 standard“Comm. Syst. for remote reading of meters” • EN13757-4:2005: Wireless Meter Readout • -3 M-Bus application layer • -1 DLMS application layer • The Netherlands: NTA8130 as of Feb 2006(last revision of Jan 2009) • Germany: OMS specification released September 2009 • TC 294 again active (re-launched July 2009)

  11. EN13757-4:2005 • “Stationary Mode” S • Unidirectional, S1, or bi-directional, S2 • 32.768 kb/s, 868.3 MHz • “Frequent transmit mode” T • Unidirectional, T1, or bi-directional, T2 • 100kb/s, 868.95 MHz • “Frequent receive mode” R • 10 channels, 4.8 kb/s

  12. NTA 8130 (DSMR) • Netherlands Technical Agreement 8130 • Dutch Smart Meter Requirements • P2 interface • Max 4 metering instruments and/or grid company equipments in each metering system • Defines T1 / T2 and AES128

  13. OMS • Open Metering System specification • Assured co-existence with NTA 8130 / DSMR • Unified approach for the different media(electricity, gas, heat and water) as well asactuators and displays • Interoperation • Optimized for battery lifetime of > 14 years • Installation supported

  14. OMS cont. • MUC (Multi Utility Controller): Intelligent concentrator between AMM and the devices • Either S or T mode and AES 128 encryptionMUC <-> meters • OMS is being reviewed by CEN as European new work item proposal TC294

  15. System topology

  16. RC1180-MBUS module • Embedded protocol • supporting EN 13757-4:2005 mode S, T and R2 • AES 128 HW co-prosessor • 12.7 x 25.4 x 3.3 mm • compact module for SMD mounting • No configuration required • 4 pins + gnd connection • 2.0 – 3.6 V supply voltage • ultra low power modes

  17. RC1180-MBUS module • 2 channels in mode S and T • 868.3 and 868.95 MHz • 10 channels in mode R2 • 868.03 + n x 0.06 MHz • CE marked • Conforms with EU R&TTE directive • EN 300 220, EN 301 489, EN 60950 • Designed for EX compliance • High temperatures

  18. Feature sets standard

  19. High-end performance • Output power typical 10 dBm • Excellent receiver sensitivity • Typical -102 dBm at 32.768 kbps • Excellent blocking • >-45 dBm at 2 MHz offset • Two way communication simplifies installation compared to only one-way • 8-900m range / quarterwave antenna

  20. UART : Data in – RF out

  21. Micro- controller Wireless M-Bus communication modem EN 13757-3 EN 13757-4 Customer Application UART GPRS modem UART Ethernet gateway UART

  22. M-Bus application module • Tailoring to different end users requirements Pulse input Innstallation button input Status LED output UART for reading meter info

  23. MUC platforms: RC1180-MBUS+ GPRS/GSM / Ethernet RC1180-MBUS

  24. PC Suite w/Packet sniffer

  25. Man. ID

  26. KNX is a registered Trademark of the KNX Association cvba, used with kind permission

  27. KNX RF + wireless M-Bus = a complete solution for building automation and load management & home area metering KNX is a registered Trademark of the KNX Association cvba, used with kind permission

  28. KNX is the worldwide standard for home and building control (~7000 certified products) • IEC/ISO and EN standard • Supporting media (RF, PL, TP, IP) KNX is a registered Trademark of the KNX Association cvba, used with kind permission

  29. RF • KNX-RF has the same lower layers as wireless M-Bus • KNX RF • 868 MHz, multiple channels • New version of standard just released • Improvement in battery lifetime and performance improvement in noisy environment

  30. ZigBee is a registered Trademark of the ZigBee Alliance

  31. ZigBee basics • Short range radio based on IEEE 802.15.4 • 2.4 GHz Mesh radio • Limited to 10 mW/MHz in Europe by EN 300 328

  32. ZigBee Smart Energy • Public Application profile for support of • Meters • Display • Repeater • Load Control Devices • Demand response support • Security to allow consumer only, utility only, or shared networks • ZigBee Smart Energy : Preferred solution in US. for Smart Energy HAN

  33. Smart Energy Security • Security is critical requirement • AES128 bit network key and link keys • Preconfigured link key • Used to receive network key • Certificate based public key exchange to achieve final link key • Utilizes a Certificate Authority for the device keys • Process has been independently audited and approved by Carnegie-Mellon

  34. The way forward: ZigBee IP stack • New ZigBee stack option in development • Based on end to end IP for smart metering • MAC – 15.4 2006 with MAC security • 6LoWPAN

  35. 6LoWPAN • Standardized through IETF • IPv6 packets over Low power Wireless Personal Area Network • Compression, fragmentation++ • ROLL (Routing Over Low power and Lossy networks ) • Radiocrafts is working with 6LoWPAN leader Sensinode

  36. RC2400/RC2400HP • Support ZigBee Smart Energy and ZigBee PRO • 256 kB Flash • Excellent range • 102 dB system gain – RC2400 • 110 dB system gain – RC2400HP(European setup) • Excellent battery lifetime • RC2400 and RC2400HP pin compatible

  37. FW options • ZigBee Network Module • Include precompiled ZigBee PRO stack • UART/SPI to external processor • ZigBee 2007/PRO compliant stack available for download free of charge • Easy-to-use development environment for customers to develop their own solution • Customer tailored solution

  38. Application Security library ZigBee PRO stack Easy to use API interface via UART/SPI RC2400-ZNM MCU

  39. Total cost of ownership of wireless solutions Finance and logistics • Supply Chain Management • Interest rate/ROI • Risk/Time to market • Evolution of standards • New and better IC’s • Adding functionality • Assembly • Manufacturing test • Yield loss • HW • FW • Characterization Solution maintenance Manufacturing Design Bill of material

  40. Lowest TCO =

  41. One design – Multiple solutions New! 868MHz High Power ½ Watt Wireless M-Bus New! Wireless M-Bus @ 433MHz KNX-RF ZigBee ZigBee High Power Customer specific

  42. Questions?

  43. Thank you for your attentionwww.radiocrafts.com Visit us at Booth #201
