The Structure of the Nervous System

erna avatar
erna
30 diapositives · 427 Views · Jul 24, 2014

This chapter delves into the intricate structure and remarkable functions of the nervous system. It covers key components such as the brain, spinal cord, and peripheral nerves, along with details on neurons, their parts, and the types of neurons: sensory, interneurons, and motor neurons. Explore how nerve impulses travel through synapses and the concept of the reflex arc. Additionally, learn about the brain's various divisions, including the cerebrum, thalamus, hypothalamus, and cerebellum, and understand the role of the spinal cord and peripheral nervous system in transmitting information.

#the structure of the nervous system #the structure of the nervous system ppt #powerpoint #presentation
The Structure of the Nervous System - slide 1
01 / 30The Structure of the Nervous System
1 / 17

Télécharger la présentation

The Structure of the Nervous System
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. The Structure of the Nervous System Chapter 23A

  2. Nervous System • Brain • Spinal cord • Nerves • Sensory organs CNS PNS

  3. nerves Neurons • neuron: nerve cell

  4. Parts of a Neuron • Cell body • Dendrites • Axon • myelin sheath • Schwann cells • axon terminal

  5. Synapse • The junction between two neurons • Synaptic cleft

  6. Nerve Impulse • Electrochemical pulse that moves along the membrane of a neuron • Based on movement of sodium and potassium ions • Must cross synaptic cleft by using neurotransmitters

  7. Three Types of Neurons • Sensory neurons • Interneurons • Motor neurons

  8. Reflex

  9. The Reflex Arc • Shortcut approach to nerve impulses • The impulse will be reflected back to the muscles or glands involved at the same time the impulse is sent to the brain.

  10. The Reflex Arc sensory receptor sensory neuron interneuron motor neuron muscle brain

  11. The CNS

  12. Coverings of CNS • Meninges • dura mater • arachnoid membrane • pia mater

  13. Cerebrospinal Fluid • Fluid between the pia mater and arachnoid membrane • Fills spaces around brain and spinal cord • Nourishes and cushions

  14. The Brain

  15. The Brain • 3 pounds • Receives 20% of the blood pumped by the heart • Pinkish-gray

  16. The Brain • Gray matter • cell bodies and dendrites • White matter • axons and myelin sheaths

  17. Divisions of the Brain • cerebrum • thalamus • hypothalamus • midbrain • pons • medulla oblongata • cerebellum

  18. Cerebrum • Two hemispheres • Gyri (gyrus) • Fissures • Cerebral cortex (gray matter) • Lobes • frontal, parietal, occipital, temporal

  19. Medulla Oblongata • Continuous with the spinal cord • Relay center between the spinal cord and the brain • Contains respiratory and cardiac control centers • Controls some reflexes

  20. Cerebellum • Second largest part of brain • Two hemispheres • Regulates activities stimulated by the rest of the brain • Coordinates movement • Works on unconscious level

  21. Thalamus • Two oval gray masses near center of brain • Receives sensations and decides which are important enough to be sent on • Alertness and wakefulness

  22. Philippians 4:8 Finally, brethren, whatsoever things are true. . . honest. . . just. . . pure. . . lovely. . . of good report; if there be any virtue, and if there be any praise, think on these things.

  23. Hypothalamus • Controls involuntary activities • body temperature • blood volume • fluid balance • appetite • emotional control (hormones)

  24. Midbrain • Between thalamus and pons • Controls • body movements • space relationships • vision reflexes • hearing reflexes

  25. Pons • Between medulla and midbrain • Carries information from one side of the brain to the other • Contains reflex centers that control facial expressions, chewing, sound responses, eyeball movement

  26. The Spinal Cord

  27. Spinal Cord Facts • 31 pairs of spinal nerves • Butterfly-shaped gray matter • interneurons and cell bodies of sensory and motor neurons • White matter • myelinated axons arranged vertically

  28. The PNS

  29. PNS • Sensory division • info from the body to the CNS

  30. PNS • Motor division • info from the CNS to the body • somatic system (voluntary) • autonomic system (involuntary)
