  1. Introduction to Web Architecture A Brief Overview

  2. Topics • Basic Web Architecture • HTML • URI • HTTP • CGI • Cookie • Database-driven Website Architecture • AJAX • Web Services • XML • JSON

  3. The World Wide Web

  4. The World Wide Web • In 1989, Tim Berners-Lee suggested a way to let all users [primarily scientists], browse each others’ papers on the Internet. • He developed HTML, URLs, and HTTP.

  5. Basic Web Architecture

  6. Basic Web Architecture • The web is a two-tiered architecture. • A web browser displays information content, • and a web server that transfers information to the client.

  7. Web Browser • The primary purpose of a web browser is to retrieve information resources for the end-user. • A web browser is an application for retrieving, presenting, and navigating information resources.

  8. Web Server • The term web server or webserver can mean one of two things: • A computer program • That accepts HTTP requests and return HTTP responses with optional data content. • A standalone computer • Whose sole purpose to run a computer program as described above.

  9. Some Interesting Statistics(Source: Netcraft January 2013 Web Server Survey)

  10. Some Interesting Statistics(Source: Netcraft January 2013 Web Server Survey)

  11. Some Interesting Statistics(Source: Netcraft January 2013 Web Server Survey)

  12. Some Interesting Statistics(Source: Netcraft January 2013 Web Server Survey)

  13. Some Interesting Statistics(Source: Netcraft January 2013 Web Server Survey)

  14. Some Interesting Statistics(Source: Netcraft January 2013 Web Server Survey)

  15. Some Interesting Statistics(Source: StatCounter Global Stats, Top 5 Browsers June 2012 – June 2013)

  16. URI Universal Resource Identifier

  17. URI • A URL is a type of URI that's used to describe the location of a specific document. • A URL doesn't define the type of content to be found (texts, images, movies, etc.); it only says where and how to find it.  • URLs are location dependent • A URL contains four distinct parts, namely: • the protocol type • the machine name • the directory path • file name. • There are several kinds of URLs: • FTP URLs • HTTP URLs.

  18. URI More Information: http://www.htmlquick.com/reference/uri-url.html

  19. HTTP HyperText Transfer Protocol

  20. HTTP • HTTP is a request/response standard of a client and a server. • Typically, a HTTP client (e.g. Firefox) initiates a request. • Resources to be accessed by HTTP are identified using Uniform Resource Identifiers (URIs).

  21. Request message • The Hyper Text Transfer Protocol (HTTP) is the client-server network protocol that has been in use by the World-Wide Web since 1990. • Whenever you surf the web, your browser will be sending HTTP request messages for HTML pages, images, scripts and styles sheets. • Web servers handle these requests by returning response messages that contain the requested resource. More Info: http://www.httpwatch.com/httpgallery/introduction/

  22. Request methods • HTTP defines eight methods (sometimes referred to as "verbs") indicating the desired action to be performed on the identified resource. • HEAD • GET • POST • PUT • DELETE • TRACE • OPTIONS • CONNECT

  23. HTTP methods • The most common methods that are used by a client in an HTTP request are as follows:-1) GET:- Used when the client is requesting a resource on the Web server.2) HEAD:- Used when the client is requesting some information about a resource but not requesting the resource itself.3) POST:- Used when the client is sending information or data to the server—for example, filling out an online form (i.e. Sends a large amount of complex data to the Web Server).4) PUT:- Used when the client is sending a replacement document or uploading a new document to the Web server under the request URL.5) DELETE:- Used when the client is trying to delete a document from the Web server, identified by the request URL.6) TRACE:- Used when the client is asking the available proxies or intermediate servers changing the request to announce themselves.7) OPTIONS:- Used when the client wants to determine other available methods to retrieve or process a document on the Web server. 8) CONNECT:- Used when the client wants to establish a transparent connection to a remote host, usually to facilitate SSL-encrypted communication (HTTPS) through an HTTP proxy.

  24. HTTP methods • HEAD, GET, OPTIONS and TRACE are defined as safe (no side effects). • POST, PUT and DELETE are intended for actions which may cause side effects (possibly) on the server.

  25. Status Codes • The first line of the HTTP response is called the status line. • The way the user agent handles the response primarily depends on the code and secondarily on the response headers. • Success: 2xx • Redirection: 3xx • Client-Side Error: 4xx • Server-Side Error: 5xx

  26. HTTP session state • HTTP is a stateless protocol. • Hosts do not need to retain information about users between requests. • Statelessness is a scalability property. • For example, when a host needs to customize the content of a website for a user. • Solution: • Cookies • Sessions • Hidden variables (when the current page is a form) • URL encoded parameters (such as /index.php?session_id=some_unique_session_code)

  27. Cookies tracking cookie, browser cookie, or HTTP cookie

  28. Cookie • Cookie is a small piece of text stored on a user's computer by a web browser. • A cookie consists of one or more name-value pairs containing portions of information such as user preferences. • A cookie can be used for: • authenticating, • session tracking, and • remembering specific information about users.

  29. Cookie Expiration • Cookies expire, and are therefore are not sent by the browser to the serverin the following scenarios: • At the end of the user session if the cookie is not persistent • An expiration date has been specified, and has passed • The expiration date of the cookie is changed to a date in the past • The browser deletes the cookie by user request

  30. Sample HTTP Request and Response • Client request • Server response

  31. Languages of the Internet

  32. Hyper Text Markup Language HTML

  33. Hyper Text Markup Langauge • Document layout language (not a programming language) • Defines structure and appearance of Web pages

  34. Hyper Text Markup Langauge • HTML is a language for describing web pages. • HTML is a markuplanguage • A markup language is a set of markup tags • The tags describe document content • HTML documents containHTML tags and plain text • HTML documents are also called web pages Source: http://www.w3schools.com/html/html_intro.asp

  35. HTML TAGs • HTML markup tags are usually called HTML tags • HTML tags are keywords (tag names) surrounded by angle brackets like <html> • HTML tags normally come in pairs like <b> and </b> • The first tag in a pair is the start tag, the second tag is the end tag • The end tag is written like the start tag, with a forward slash before the tag name • Start and end tags are also called opening tags and closing tags Source: http://www.w3schools.com/html/html_intro.asp

  36. HTML ELEMENTS • A HTML Element: • Everything between the start and end tag including the tags • Example: • <p> This is a Paragraph of text </p> Source: http://www.w3schools.com/html/html_intro.asp

  37. HTML & Web Browsers • Web Browsers Read HTML documents and display them as webpages • The browser Reads the HTML TAGS but does not display them • The web browser uses the HTML TAGS to determine how to display / present the webpage.

  38. Sample HTML Webpage http://sheldonbrown.com/web_sample1.html

  39. Hypertext PreProcessor(PHP) • PHP • Is a server side langauge • Is a widely-used, open source scripting language • Scripts are executed on the server • Is free to download and use • PHP • Runs on different platforms (Windows, Linux, Unix, Mac OS X, etc.) • Is compatible with almost all servers used today (Apache, IIS, etc.) • Has support for a wide range of databases

  40. Structured Query Language(SQL) • SQL • lets you access and manipulate databases • is an ANSI (American National Standards Institute) standard • can execute queries against a database • can retrieve data from a database • can insert records in a database • can update records in a database

  41. SQL • Can delete records from a database • Can create new databases • Can create new tables in a database • Can create stored procedures in a database • Can create views in a database • Can set permissions on tables, procedures, and views

  42. Java Script • An increasingly common way to provide dynamic feedback for Web users is to include scripts or programs that run on the user's machine rather than the Web server. • These programs can be • Javaapplets • Java scripts OR • ActiveX controls. • These technologies are known collectively as client-side solutions

  43. JavaScript • JavaScript is the scripting language of the Web. • All modern HTML pages use JavaScript to: • add functionality • validate input • communicate with web servers, and much more.

  44. AJAX Asynchronous JavaScript and XML

  45. AJAX • AJAX = Asynchronous JavaScript and XML. • AJAX is not a new programming language, but a new way of using existing standards. • AJAX is the art of exchanging data with a server, and updating parts of a web page - without reloading the whole page • Ajax is a method of using Javascript, DHTML and the XMLHttpRequest object to perform a GET or POST and return a result without reloading the HTML page.

  46. XML eXtensible Markup Language

  47. What is XML ? • XML • stands for EXtensibleMarkupLanguage • is a markup language much like HTML • designed to carry data, not to display data • tags are not predefined, you must define your own tags • is designed to be self-descriptive • is a W3C (World Wide Web Consortium) Recommendation

  48. XML (cont.) <?xml version=\"1.0\" encoding=\"UTF-8\"?> <person> <id type="integer">1111</id> <last_name>Smith</last_name> <first_name>John</first_name> <address> <city>New York</city> <street>21 2nd Street</street> <postal_code type="integer">10021</postal_code> <state>NY</state> </address> </person>

  49. JSON JavaScript Object Notation

  50. JSON • JSON is a lightweight computer data interchange format. • JSON is based on a subset of the JavaScript programming language. • It is considered to be a language-independent data format. • It serves as an alternative to the use of the XML format. Douglas Crockford is a senior JavaScript Architect at Yahoo! He is well known for his work in introducing JavaScript Object Notation (JSON).
