  1. Cold Rolled Steel Characteristics • High quality products manufactured by the • computer integrated system at Asan Bay Works • Uniform thickness, wider width, and hardness • and tensile strength • Smooth surface, and uniform flatness • Superior workability

  2. Fender Trunk lid Outer Floor Members Fuel Tank Cold Rolled Steel Application • Cold rolled steel that Dongbu Steel provides is the • optimal product for using in automobile parts as roofs, • fenders, hoods, panels, oil fans, etc.

  3. Class Standard Specification Dongbu T.S (kg/mm2) EL min.(%) T.S (kg/mm2) Hardness (HrB) Hardness (HrB) EL min.(%) Commercial Quality 28 and over 32∼38 and over 28 and over 32∼38 50 and under 28 and over 34∼40 and over 28 and over 34 49 and under Drawing Quality Deep Drawing Quality 28 and over 36∼42 and over 47 and under 28 and over 36∼44 Non-Aging DDQ 36∼42 and over 28 and over 28 and over 47 and under 43∼47 Cold Rolled Steel Mechanical Properties

  4. Class Standard Specification Dongbu T.S (kg/mm2) EL min.(%) Hardness (HrB) T.S (kg/mm2) EL min.(%) Hardness (HrB) High- Strength DQ 35kg/R 35 and over 34 and over 35 and over 34 and over 40kg/R 40 and over 30 and over 40 and over 30 and over DDQ 35kg/E 35 and over 34 and over 35 and over 34 and over 40kg/E 40 and over 30 and over 40 and over 30 and over Cold Rolled Steel Mechanical Properties ※ Specifications of high tensile strength steel shall be subject to agreement between manufacturer and purchaser.

  5. Cold Rolled Steel Mechanical Properties • Specification

  6. Cold Rolled Steel Size Availability (mm)

  7. Galvanized Products [Galvanized & Galvannealed] Characteristics • Specialty products manufactured by computer • integrated system • Excellent flatness achieved by using PLTCM’s • base metal • Excellent adhesion of Fe-Zn coating • Induction heating GA furnace • - Uniform iron contents on the alloyed surface • - Improvement of powdering resistance • → Excellent corrosion resistance, weldability, and paintability

  8. Galvanized Products [Galvanized & Galvannealed] Application Automotive Engine Heat protector

  9. Class Standard Specification Dongbu T.S (kg/mm2) Y.P (kg/mm2) EL (%) T.S (kg/mm2) Y.P (kg/mm2) EL (%) Hardness (HrB) Commercial Quality - - - 36∼42 26∼32 34∼42 55∼65 Drawing Quality min 28 max 22 min 41 28∼34 18∼22 41∼46 40∼50 Deep Drawing Quality min 28 max 18 min 43 28∼32 15∼18 43∼48 38∼48 Non-Aging DDQ min 28 max 17 min 45 28∼32 13∼17 45∼50 38∼48 High- Strength 35kg/R min 35 min 20 min 36 35∼38 20∼24 36∼42 56∼64 40kg/R min 40 min 23 min 30 40∼44 23∼27 34∼40 60∼68 Galvanized Products [Galvanized & Galvannealed] Mechanical Properties ※ Specifications of high tensile strength steel shall be subject to agreement between manufacturer and purchaser.

  10. Galvanized Products [Galvanized & Galvannealed] Mechanical Properties • Specification

  11. Galvanized Products [Galvanized & Galvannealed] Size availability DQ / DDQ / EDDQ CQ ※ Please contact our representative for more information on 2.3mm thickness of galvanized steel sheets.

  12. ALCOT [Hot-Dip Aluminium Coated Steel] Characteristics • Excellent heat resistance • Surface appearance after heat treatment ALCOT GALVANIZED STEEL COLD ROLLED STEEL ※ Test Condition : At 450℃×24Hours In Air

  13. ALCOT [Hot-Dip Aluminium Coated Steel] Characteristics • Corrosion resistance • Corrosion rate with PH changes in solution ※ The corrosion resistance of ALCOT is excellent due to the coating characteristics to form a thin stable aluminum oxide layer.

  14. ALCOT [Hot-Dip Aluminium Coated Steel] Application Automotive Exhaust system

  15. Class Standard Specification Dongbu T.S min. (kg/mm2) Y.P (kg/mm2) EL min. (%) T.S min. (kg/mm2) Y.P (kg/mm2) EL min. (%) Commercial Quality 28 21 min - 28 21 min - Drawing Quality DQ1 28 26 max 34∼38 28 26 max 34∼38 DQ2 28 24 max 36∼40 28 24 max 36∼40 DQ3 28 21 max 38∼42 28 21 max 38∼42 EDDQ 26 19 max 40∼44 26 19 max 40∼44 ALCOT [Hot-Dip Aluminium Coated Steel] Mechanical Properties ※ Specifications of high tensile strength steel shall be subject to agreement between manufacturer and purchaser.

  16. ALCOT [Hot-Dip Aluminium Coated Steel] • Specification • Scope of Manufacturing Field
