Jig & Fixture Design

faustine avatar
faustine
18 diapositives · 2.7K Views · Feb 10, 2013

Jig & Fixture Design. Purpose of Tool design. Unit1. Purpose of Tool Design. Tool design: the process of designing and developing the tools, methods, and techniques necessary to improve manufacturing efficiency and productivity. Purpose of Tool Design. Tool design objectives;

Jig & Fixture Design - slide 1
01 / 18Jig & Fixture Design
1 / 17

Télécharger la présentation

Jig & Fixture Design
Une image / un lien ci-dessous est fourni (tel quel) pour télécharger la présentation

Politique de téléchargement : le contenu du site vous est fourni TEL QUEL pour votre information et votre usage personnel ; il ne peut être vendu, concédé sous licence ni partagé sur d’autres sites sans l’accord de son auteur.Le contenu vous est fourni TEL QUEL, pour votre information et votre usage personnel uniquement. Téléchargez la présentation en cliquant sur ce lien. Lors du téléchargement, si vous ne parvenez pas à télécharger une présentation, l’éditeur a peut-être supprimé le fichier de son serveur.Pendant le téléchargement, si vous ne parvenez pas à obtenir une présentation, le fichier a peut-être été supprimé par l’éditeur.

F I N

Plus de contenu associé

Transcription de la présentation

  1. Jig & Fixture Design

  2. Purpose of Tool design Unit1

  3. Purpose of Tool Design Tool design: the process of designing and developing the tools, methods, and techniques necessary to improve manufacturing efficiency and productivity

  4. Purpose of Tool Design Tool design objectives; • Provide simple, easy operating tools for maximum efficiency • Produce with lowest possible cost • Produce part with high quality

  5. Purpose of Tool Design Tool design objectives; • Increase production rate • Foolproof • Adequate tool life • Safety

  6. Purpose of Tool Design Tool Design in MFG. • Manufacturing for global competitiveness required the success of concurrent engineering

  7. Tool Design in MFG. Planning the Design Manage information resources • Part Drawings • Production Plan • Alternatives

  8. Tool Design in MFG.Planning the Design Part Drawings: complete understanding of the part; • Overall size and shape • Condition of the material • Type of operation • Degree of accuracy • Number of producing • Locating surfaces

  9. Tool Design in MFG.Planning the Design Production Plan: itemized list of mfg operations; • Type and size of m/c tool • Type and size of cutters • Sequence of operations • Previous operations performed

  10. Tool Design in MFG.Planning the Design Alternatives: ensure the optimize method is chosen; • Should special tool be used? • Should multiple or single spindle m/c be used? • Should the tool be single or multi-purpose used? • What type of gauge be used? • Will the savings justify the cost of the tool?

  11. Tool Design in MFG. Challenges to the Tool Designer Understand the extent of these additional duties • Design • Supervision • Procurement • Inspection

  12. Tool Design in MFG.Challenges to the Tool Designer Design: Develop the drawings and sketches of the tool design ideas

  13. Tool Design in MFG.Challenges to the Tool Designer Supervision: Good working relationship with the group of skilled people

  14. Tool Design in MFG.Challenges to the Tool Designer Procurement: Choose the vender which meet the designer’s needs in the most timely, efficient, and reliable manner

  15. Tool Design in MFG.Challenges to the Tool Designer Inspection: Inspect the tool drawing and finished tool to ensure specifications

  16. Purpose of Tool Design Requirement to become a tool designer • Able to make mechanical drawings and sketches • Understand modern manufacturing methods, tools, and techniques • A creative mechanical ability

  17. Purpose of Tool Design Requirement to become a tool designer • Understand basic toolmaking methods • A knowledge of technical mathematics • Geometric dimensioning and tolerance

  18. Purpose of Tool Design Requirement to become a tool designer • CAD drafting skills • File management • Electronic communication skills
