  1. Computer Architecture Lecture 14 FasihurRehman

  2. Last Class • Control Unit • Microprogrammed Control

  3. Today’s Agenda • Arithmetic (Integer) • Representation • Signed numbers • Operations and their implementation

  4. Binary Representation

  5. Binary Representation

  6. Signed Numbers • Representation Methods • Signed Magnitude • 1’s Complement • 2’s Complement

  7. Signed Magnitude

  8. 1’s Complement • – N = (2n -1) - N • where: n is the number of bits per word • N is a positive integer • -N in 1's complement (Negative Number) • For example with an 8-bit word and N = 6, we have: • – N = (28 -1) - 6 = 255 - 6 = 249 = 11111001 • Alternatively • N = +6 = 000001102 • (-N ) = -6 = 111110012 • the values 00000000 and 11111111 both represent zero

  9. 2’s Complement • N * = 2n- N • where: n is the number of bits per word • N is a positive integer • N* is -N in 2's complement notation • For example with an 8-bit word and N = 6, we have: N* = 28 - 6 = 256 - 6 = 250 = 11111010 • Alternatively, to take 2's complement is to start at the right and complement each bit to the left of the first "1". • For example: N = +6 = 00000110 • N* = -6 = 11111010

  10. Examples

  11. Examples

  12. Examples

  13. Addition/subtraction of signed numbers x y Carry-in c Sum s Carry-out c i i i i i +1 0 0 0 0 0 0 0 1 1 0 0 1 0 1 0 0 1 1 0 1 1 0 0 1 0 1 0 1 0 1 1 1 0 0 1 1 1 1 1 1 x y c + x y c + x y c + x y c s = = x Å y Å c i i i i i i i i i i i i i i i i y c x c x y c = + + i i i i i i i +1 E xample: x X 7 0 1 1 1 Carry-out Carry-in i y + Y = + 6 = + 0 1 1 0 0 1 1 0 0 c i c i +1 i 13 1 1 0 1 s Z i Legend for stage i

  14. Summary • Arithmetic • Representation • Signed numbers • Operations and their implementation
