  1. ANA 812 Digestive System III: Liver, Gallbladder & Pancreas Bethany Cox Sarah Marks Joe Slusher Kara Stebbins

  2. Slide #106 Liver- Pig 4x Portal Area Liver Lobule

  3. Slide #106 Liver- Pig 10x Central Vein 40x • Central Vein • Cords of Hepatocytes • Liver Sinusoids • Binucleate Cell

  4. Slide #106 Liver- Pig 4x 40x • Portal Vein • Hepatic Artery • Lymphatic Vessel • Bile Ductule

  5. Slide #106 Liver- Pig-40X • Portal Vein • Lymphatic • Bile Ductule • Hepatic Artery

  6. Slide #101 Liver- Human-4X • Note relative • lack of connective • tissue.

  7. Slide #101 Liver- Human-10X • Central Vein • Liver Sinusoids • Hepatocyte Cords • Lipid Droplets

  8. Slide #104 Liver- Mouse 40x 4x Portal Vein Bile Ductule Lymphatic Vessel

  9. H&E stain (human, slide 101) Trypan blue stain with neutral red (monkey, slide 103) Liver: Von Kupffer cells-40X Large oval nuclei projecting into sinusoids Trypan blue phagocytized into granules

  10. Normal liver (H&E stain, human, slide 101) Cirrhosis (Masson’s trichome stain, human, slide 107) Liver: One Effect of Cirrhosis-40X Vacuolated hepatocyte cytoplasm Bile canaliculi

  11. Normal liver (H&E stain, human, slide 101) Cirrhosis (Masson’s trichome stain, human, slide 107) Liver: Another Effect of Cirrhosis-4X Blue-staining collagen (fewer hepatocytes, more CT)

  12. Slide #178 – Pancreas and Suprarenal Gland – Monkey (Azan Stain) – 4X • Pancreatic Islets of Langerhans (endocrine portion of the pancreas) • Ducts • Intercalated • Intralobular • Interlobular

  13. Slide #178 – Pancreas and Suprarenal Gland – Monkey (Azan Stain) – 40X • Islet of Langerhans 4X

  14. Slide #178 – Pancreas and Suprarenal Gland – Monkey (Azan Stain) – 10X • More secretory acinar divided into lobules • Ducts • Intercalated (not seen at this power) • Intralobular • Interlobular

  15. Slide #104-Gallbladder and liver-10X • Simple columnar eplithelium • Lamina propria • Smooth muscle layer • Definitive mucosal folds Monkey, H&E stain

  16. Slide #105-Gallbladder -10X • Human specimen after death • Extremely folded gallbladder • mucosa seen here is typical of • human gallbadder Human, H&E stain

  17. Comparison of Slides #104/#105-10X Monkey, H&E stain Human, H&E stain
