  1. Impacting Local GovernmentUpdating Functional Classification Using GIS Bentonville, Arkansas September 12, 2013

  2. Presentation Overview • Introduction • Federal-Aid System • Functional Class • Adjusted Urban Area Boundary • Purpose of Project • Methodology – GIS • Proposed Process • Good Practice Steps & Schedule • Questions and Answers

  3. The Federal-Aid System “Federal-Aid highway funds are authorized by Congress to assist the States in providing for construction, reconstruction, and improvement of highways and bridges on eligible Federal-Aid highway routes and for other special purpose programs and projects.”

  4. The Federal-Aid System Arkansas 22,360 miles • State Highways16,220 miles • County Roads 3,780 miles • City Streets2,360 miles

  5. Functional Classification • Importance • Federal-Aid highway funding • Impacts to Roadway Design • Project Prioritization Remember Funding is directly related to the functional classification of a road

  6. Functional Classification

  7. Functional Classification

  8. Functional Classification • Interstate • Other Freeway & Expressway • Other Principal Arterial • Minor Arterial • Major Collector • Minor Collector • Urban Minor Collectors – Yes • Rural Minor Collectors - No

  9. Functional Classification

  10. Adjusted Urban Area Boundary

  11. Adjusted Urban Area Boundary City (Urban) Responsibility TEST

  12. Adjusted Urban Area Boundary County (Rural) Responsibility

  13. Purpose of Project • FHWA requirement to update the urban boundary and functional class of roadways every 10 years. • Update functional classifications due to changes in the urban boundary as a result of the 2010 U.S. Census data. • Re-assess the existing functional classifications and make changes and additions where necessary to the system since 2000.

  14. Methodology • Updating using GIS is a new process • Utilize • ESRI Shapefiles • Geo-Database Files • Learn as we go • Utilize stakeholder Input • Inter-Agency Cooperation

  15. Methodology Proposed Process

  16. MethodologyProposed Process • Assess Need for Additional Functional Classification Changes • Make updates • Meet FHWA mileage % ranges • Prepare Maps or GIS Files for AHTD Evaluation • Work with AHTD during evaluation process • Evaluation process will take some time • Seek FHWA Approval • FHWA is a concerned stakeholder

  17. MethodologyProposed Process • Functional Classification - Triggers • Changes in roadway characteristics or use • New significant roadways • Significant growth (population/traffic) • Extension of existing roadways • Changes in traffic patterns • New schools, industry, or other economic assets

  18. MethodologyProposed Process • Minimize functional class changes along the roadway • A roadway of higher classification should not terminate at a single roadway of a lower classification • There will be exceptions • Maintain Topological Connectivity • Be consistent • Use common sense

  19. MethodologyProposed Process Think Continuity

  20. Good Practice Steps & Schedule • Determining level of functional classification of a roadway can be difficult at times and create uncertainty. • FHWA Functional Classification Manual • FHWA Functional Classification Website (under construction) • AHTD as a resource • Share understanding of the game plan • Encourage & work towards timely delivery of functional classification revisions

  21. Good Practice Steps & Schedule

  22. What If What If: If we do not complete the functional class update, what happens? Answer: AHTD will update the State Highways in your area and leave the existing functional classification at the 2000 level with only minor adjustments. What If: Can functional classification be updated at a later date? Answer: Yes, but only on a case-by-case basis. System-wide update is a one shot deal. What If: Future or proposed un-built roads are included? Answer: There is a 4-year must be built clause and it should already be in the STIP before being added to the functional class file. (see above)

  23. If you have any questions please contact me by e-mail at: greg.nation@ahtd.ar.gov or (501) 569-2406
