**Chapter 2**Bits, Data Types & Operations Integer Representation Floating-point Representation Other data types**CS Reality #1**• You’ve got to understand binary encodings. • Examples • Is x2 ≥ 0? • Int’s: • 40000 * 40000 --> 1600000000 • 50000 * 50000 --> ?? • Float’s: Yes! • Is (x + y) + z = x + (y + z)? • Unsigned & Signed Int’s: Yes! • Float’s: • (1e20 + -1e20) + 3.14 --> 3.14 • 1e20 + (-1e20 + 3.14) --> 0? 3? 3.1? • Is 4/5 = 4/5.0? • Maybe? (int) 4/5 = 0 what is 4/5.0?**Data types**• Our first requirement is to find a way to represent information (data) in a form that is mutually comprehensible by human and machine. • Ultimately, we will have to develop schemes for representing all conceivable types of information - language, images, actions, etc. • Specifically, the devices that make up a computer are switches that can be on or off, i.e. at high or low voltage. Thus they naturally provide us with two symbols to work with: we can call them on & off, or (more usefully) 0 and 1. • We will start by examining different ways of representing • Strings of Characters • Integers • Floating point numbers**Why do Computers use Base 2?**• Base 10 Number Representation • Natural representation for human transactions • Binary floating point number cannot exactly represent $1.20 • Hard to Implement Electronically • Hard to store • ENIAC (First electronic computer) used 10 vacuum tubes / digit • Hard to transmit • Need high precision to encode 10 signal levels on single wire • Messy to implement digital logic functions • Addition, multiplication, etc. • Base 2 Number Representation • Easy to store with bistable elements • Reliably transmitted on noisy and inaccurate wires • Examples • Represent 1521310 as 111011011011012 • Represent 1.2010 as 1.0011001100110011[0011]…2 • Represent 1.5213 X 104 as 1.11011011011012 X 213 1.20 = 1×20+ 0×2-1+ 0×2-2+…**Unsigned Binary Integers**Y = “abc” = a.22 + b.21 + c.20 (where the digits a, b, c can each take on the values of 0 or 1 only) N = number of bits Range is: 0 i < 2N – 1 Umin = 0 Umax = 2N – 1 • Problem: • How do we represent negative numbers?**Signed Magnitude**• Leading bit is the sign bit Y = “abc” = (-1)a (b.21 + c.20) Range is: -2N-1 + 1 < i < 2N-1 – 1 Smin = -2N-1 + 1 Smax = 2N-1 – 1 • Problems: • How do we do addition/subtraction? • We have two numbers for zero (+/-)!**Two’s Complement**• Transformation • To transform a into -a, invert all bits in a and add 1 to the result Range is: -2N-1 < i < 2N-1 – 1 Tmin = -2N-1 Tmax = 2N-1 – 1 • Advantages: • Operations need not check the sign • Only one representation for zero • Efficient use of all the bits**Manipulating Binary numbers - 1**• Binary to Decimal conversion & vice-versa • A 4 bit binary number A = a3a2a1a0 corresponds to: a3 x 23 + a2 x 22 + a1 x 21 + a0 x 20 = a3 x 8 + a2 x 4 + a1 x 2 + a0 x 1 (where ai = 0 or 1 only) • A decimal number can be broken down by iteratively determining the highest power of two that “fits” in the number: e.g. (13)10 => e.g. (63)10 => e.g. (0.63)10 => • In the 2’s complement representation, leading zeros do not affect the value of a positive binary number, and leading ones do not affect the value of a negative number. So: 01101 = 00001101 = 13 and 11011 = 11111011 = -5 00001101 11111011 00001000 => 8 (as expected!)**Manipulating Binary numbers - 10**• Overflow • If we add the two (2’s complement) 4 bit numbers representing 7 and 5 we get : 0111 => +7 0101 => +5 1100 => -4 (in 4 bit 2’s comp.) • We get -4, not +12 as we would expect !! • We have overflowed the range of 4 bit 2’s comp. (-8 to +7), so the result is invalid. • Note that if we add 16 to this result we get back 16 - 4 = 12 • this is like “stepping up” to 5 bit 2’s complement representation • In general, if the sum of two positive numbers produces a negative result, or vice versa, an overflow has occurred, and the result is invalid in that representation.**Speeding Things up With Hex**• Conversion from binary to/from Hex is much faster • A 32-bit register might contain the value: 01010011101010011011101100110111 • It is much faster to view it like this: x53A9BB37 • What if we want to add:01010011101010011011101100110111+ 00111100001011111010011110011100 • We can do it this way: x53A9BB37+ x3C2FA79C----------- x8FD962D3**x31**#49 x35 #53 x32 #50 x31 #49 #51 x33 x00 #00 Representing Strings char S[6] = "15213"; • Strings in C • Represented by array of characters • Each character encoded in ASCII format • Standard 7-bit encoding of character set • Other encodings exist, but uncommon • UNICODE 16-bit superset of ASCII that includes characters for non-English alphabets • Character “0” has code 0x30 • Digit i has code 0x30+i • String should be null-terminated • Final character = 0 • Line termination, and other special characters vary Dec Hex Strings are really just arrays of numbers! How can we represent numbers using bits? “Hey, how do I know it’s a string in the first place?”**Interpreting data**• If some memory contains x4869206D6F6D2100, is it: • Two signed or unsigned integers: x4869206D = 1,214,849,133 and x6F6D2100 = ?? • A 64-bit floating point number? • A string: “Hi mom!” ? • There is no way to know, without • Seeing the source code, • Talking to the programmer, or • Reverse engineering Remember this: Memory and registers contain BINARY, and only binary, at all times.**C Integer Puzzles**• Assume machine with 32 bit word size, two’s complement integers • For each of the following C expressions, either: • Argue that is true for all argument values • Give example where not true • x * x >= 0 • ux >= 0 • ux > -1 • x < 0 (2*x) < 0 • x > y -x < -y • x > 0 && y > 0 x + y > 0 • x >= 0 -x <= 0 • x <= 0 -x >= 0 Initialization int x = foo(); int y = bar(); unsigned ux = x; unsigned uy = y;**Problems**• Patt & Patel, Chapter 2: • 2.4, 2.8, 2.10, 2.11, 2.17, 2.21**Real numbers**• Most numbers are not integer! • Range: • The magnitude of the numbers we can represent is determined by how many bits we use: • e.g. with 32 bits the largest number we can represent is about +/- 2 billion, far too small for many purposes. • Precision: • The exactness with which we can specify a number: • e.g. a 32 bit number gives us 31 bits of precision, or roughly 9 figure precision in decimal representation • Our decimal system handles non-integer real numbers by adding yet another symbol - the decimal point (.) to make a fixed point notation: • e.g. 3,456.78 = 3.103 + 5.102 + 4.101 + 6.100 + 7.10-1 + 8.10-2 • The floating point, or scientific, notation allows us to represent very large and very small numbers (integer or real), with as much or as little precision as needed.**Real numbers in a fixed space**• What if you only have 8 digits to represent a real number? • Do you prefer…... a low-precision number with a large range? … or a high-precision number with a smaller range? Wouldn’t it be nice if we could “float” the decimal point to allow for either case?**Scientific notation**• In binary, we only have 0 and 1, how can we represent the decimal point? • In scientific notation, it’s implicit. In other words: 425000 (× 100) = 425 × 103 = 42.5 × 104 = 4.25 × 105 • We can represent any number with the decimal after the first digit by “floating” the decimal point to the left (or right) 0.00125 =**Real numbers in binary**• We mimic the decimal floating point notation to create a “hybrid” binary floating point number: • We first use a “binary point” to separate whole numbers from fractional numbers to make a fixed point notation: • e.g. 25.7510 = 1.24 + 1.103 + 1.101 + 1.2-1 + 1.2-2 = 11001.1102 (2-1 = 0.5 and 2-2 = 0.25, etc.) • We then “float” the binary point: • 00011001.110 => 1.1001110 x 24 mantissa = 1.1001110, exponent = 4 • Now we have to express this without the extra symbols (x, 2, . ) • by convention, we divide the available bits into three fields: sign, mantissa, exponent**23 bits**32bits: 1 8 bits s fraction biased exp. IEEE-754 fp numbers - 1 • Sign: 1 bit • Mantissa: 23 bits • We “normalize” the mantissa by dropping the leading 1 and recording only its fractional part (why?) • Exponent: 8 bits • In order to handle both + and - exponents, we add 127 to the actual exponent to create a “biased exponent” (this provides a lexographic order!) • 2-127 => biased exponent = 0000 0000 (= 0) • 20 => biased exponent = 0111 1111 (= 127) • 2+127 => biased exponent = 1111 1110 (= 254) N = (-1)s x 1.fraction x 2(biased exp. – 127)**IEEE-754 fp numbers - 2**• Example: • 25.75 => 00011001.110 => 1.1001110 x 24 • sign bit = 0 (+) • normalized mantissa (fraction) = 100 1110 0000 0000 0000 0000 • biased exponent = 4 + 127 = 131 => 1000 0011 • so 25.75 => 0 1000 0011 100 1110 0000 0000 0000 0000 => x41CE0000 • Special values represented by convention: • Infinity (+ and -): exponent = 255 (1111 1111) and mantissa = 0 • NaN (not a number): exponent = 255 and mantissa 0 • Zero (0): exponent = 0 and mantissa = 0 • note: special case => fraction is de-normalized, i.e no hidden 1**IEEE-754 fp numbers - 3**• Double precision (64 bit) floating point 64 bits: 52 bits 1 11 bits s fraction biased exp. N = (-1)s x 1.fraction x 2(biased exp. – 1023) • Range & Precision: • 32 bit: • mantissa of 23 bits + 1 => approx. 7 digits decimal • 2+/-127 => approx. 10+/-38 • 64 bit: • mantissa of 52 bits + 1 => approx. 15 digits decimal • 2+/-1023 => approx. 10+/-306**Floating point in C**• C Guarantees Two Levels float single precision double double precision • Conversions • Casting between int, float, and double changes numeric values • Double or float to int • Truncates fractional part • Like rounding toward zero • Not defined when out of range • Generally saturates to TMin or TMax • int to double • Exact conversion, as long as int has ≤ 53 bit word size • int to float • Will round according to rounding mode**Floating point puzzles in C**Assume neither d nor f is NAN int x = …; float f = …; double d = …; • x == (int)(float) x • x == (int)(double) x • f == (float)(double) f • d == (float) d • f == -(-f); • 2/3 == 2/3.0 • d < 0.0 ((d*2) < 0.0) • d > f -f > -d • d * d >= 0.0 • (d+f)-d == f**Practice Problems**• Patt & Patel • 2.39, 2.40, 2.41, 2.42, 2.56**Other Data Types**• Other numeric data types • e.g. BCD • Bit vectors & masks • sometimes we want to deal with the individual bits themselves • Logic values • True (non-zero) or False (0) • Instructions • Output as “data” from a compiler • Misc • Grapics, sounds, …**Ariane 5**• Danger! • Computed horizontal velocity as floating point number • Converted to 16-bit integer • Worked OK for Ariane 4 • Overflowed for Ariane 5 • Used same software • Result • Exploded 37 seconds after liftoff • Cargo worth $500 million
