  1. Bluetooth Technology Presented by V. Venkata Krishna

  2. History • The name ‘Bluetooth’ was named after 10th century Viking king in Denmark Harald Bluetooth who united and controlled Denmark and Norway. • The name was adopted because Bluetooth wireless technology is expected to vunify the telecommunications and computing industries

  3. Who Started Bluetooth? • Bluetooth Special Interest Group (SIG) • Founded in Spring 1998 • By Ericsson, Intel, IBM, Nokia, Toshiba; • Now more than 2000 organizations joint the SIG

  4. What Is Bluetooth? ☼ Bluetooth is an open standard for short-range digital radio to interconnect a variety of devices Cell phones, PDA, notebook computers, modems, cordless phones, pagers, laptop computers, printers, cameras by developing a single-chip, low-cost, radio-based wireless network technology

  5. Bluetooth • Simplifying communications between: - devices and the internet - data synchronization • Operates in licensed exempt ISM band at 2.4ghz • Uses frequency hoping spread spectrum • Omni directional, no requiring line of sight • Bluetooth offers data speeds of up to 1 Mbps up to 10 meters (Short range wireless radio technology ) • Unlike IrDA, Bluetooth supports a LAN-like mode where multiple devices can interact with each other. • The key limitations of Bluetooth are security and interference with wireless LANs. • Short range wireless radio technology

  6. Content • One is master, which controls and setup the network • All devices operate on the same channel and follow the same frequency hopping sequence • Two or more piconet interconnected to form a scatter net • Only one master for each piconet • A device can’t be masters for two piconets • The slave of one piconet can be the master of another piconet

  7. A Typical Bluetooth Network Piconet • Master sends its globally unique 48-bit id and clock • Hopping pattern is determined by the 48-bit device ID • Phase is determined by the master’s clock • Why at most 7 slaves? • (because a three-bit MAC adress is used). • Parked and standby nodes • Parked devices can not actively participate in the piconet but are known to the network and can be reactivated within some milliseconds • 8-bit for parked nodes • No id for standby nodes • Standby nodes do not participate in the piconet

  8. Security Protocol • There are five phases of Simple Pairing: · Phase 1: Public key exchange · Phase 2: Authentication Stage 1 · Phase 3: Authentication Stage 2 · Phase 4: Link key calculation · Phase 5: LMP Authentication and Encryption • Phases 1, 3, 4 and 5 are the same for all protocols whereas phase 2 (Authentication Stage 1) is different depending on • the protocol used. Distributed through these five phases are 13 steps.

  9. Bluetooth Frequency • Has been set aside by the ISM( industrial ,sientific and medical ) for exclusive use of Bluetooth wireless products • Communicates on the 2.45 GHz frequency

  10. Frequency Selection • FH is used for interference mitigation and media access; • TDD (Test-Driven Development) is used for separation of the transmission directions In 3-slot or 5-slot packets

  11. Avoiding Interference : Hopping • In this technique, a device will use 79 individual, randomly chosen frequencies within a designated range • Transmitters change frequency 1600 times a second • Each channel is divided into time slots 625 microseconds long • Packets can be up to five time slots wide • Data in a packet can be up to 2,745 bits in length

  12. Content • The master for a piconet can join another piconet as a slave; in this case, all communication within in the former piconet will be suspended . • When leaving a piconet, a slave notifies the master about its absence for certain amount of time. • Communication between different piconets takes place by devices jumping back and forth between these nets

  13. Bluetooth Profile Structure

  14. How Does It Work? • Bluetooth is a standard for tiny, radio frequency chips that can be plugged into your devices • These chips were designed to take all of the information that your wires normally send, and transmit it at a special frequency to something called a receiver Bluetooth chip. • The information is then transmitted to your device

  15. BluetoothChip RF Baseband Controller Link Manager Bluetooth Chip

  16. SPECIFICATIONS • Application Specifications • These specifications include the following • Profiles Cordless Telephony • Serial Port • Headset • Intercom • Dialup Networking • Fax • File Transfer • Service Discovery Application • Generic Access

  17. Bluetooth Devices Bluetooth will soon be enabled in everything from: • Telephones • Headsets • Computers • Cameras • PDAs • Cars • Etc …

  18. Advantages (+) • Wireless (No Cables) • No Setup Needed • Low Power Consumption (1 Milliwat) • Industry Wide Support

  19. Disadvantages (-) • Short range (10 meters) • Small throughput rates • - Data Rate 1.0 Mbps • Mostly for personal use (PANs) • Fairly Expensive

  20. Thank you…
