  1. Astro-Wise and EGEE Fokke Dijkstra Donald Smits Center for Information Technology University of Groningen, NL In collaboration with OmegaCEN, Kapteyn institute, University of Groningen, NL 23 September - EGEE conference Istanbul

  2. Introduction

  3. Astro-Wise setup

  4. TARGET diagram Extreme data lineage!

  5. Astro-WISE: Services

  6. Lofar in short • Large distributed radio telescope • In NL 2008: initial roll out 20 stations • Full scale aperture synthesis array, extends 100 km • Fibre network, Software Correlator • Run as a broad common-user observatory • Making the transition now from“project” to “observatory” • Extended with European partners • Up to 4 Petabytes/year to archive

  7. New Tier 1 location Jülich - Germany Code base Amsterdam CIT / Tape Meta data and Files CIT – Groningen Blue Gene Nearline storage & processing Global FS view Astro-WISE SAS Archive Oracle DB Export by file C=IT/O=INFN /L=CNAF/CN=Pinco Palla/CN=proxy C=IT/O=INFN /L=CNAF/CN=Pinco Palla/CN=proxy Tier 0 Astro-WISE view Tier 1 VOMSpseudo-cert VOMSpseudo-cert Communities - Groningen - Amsterdam - Leiden - Nijmegen - Jülich Euro VO Lofar Communities Grid user EGEE Tier 2 LoWise SRM

  8. Astro-Wise and Grid • User authentication • VOMS proxies • Proxy server • Preferably client installation • Python only! • Web portal (should work) • Astro-Wise system will obtain delegated proxy • Extend to Oracle database • Job submission • Manage collection of tasks • Storage • Support SRM

  9. connects connects tasks Linux cluster tasks connects credentials VOMS server Proxy server Astro-Wise Database DPU VOMSattributes tasks credentials Astro-Wise job submission Astro-Wise user gLite UI

  10. Problems encountered • Preferrably no gLite-UI installation for all users • Currently only myproxy-init really necessary • Python implementation needed • OMII-UK (NDG) seems to have one, earlier tests unsuccessful • Other option java webstart version • CCLRC version works

  11. Job submission • Image processing inherently parallel • e.g. Processing per single CCD image • One step requires global communication • Communication through database • MPI job type used for processing • No real MPI program used • Independent processes started using ssh

  12. Future plans • Investigate current state of python myproxy implementation as used by NDG • Use of SRM for Lofar storage (StoRM on global file system) • Further integration of GSI with Astro-Wise and Oracle • Allow Astro-Wise to store data through SRM

  13. Final remarks • Grid job submission relatively easy • Credential management stumble block for users • Obtaining certificate • Managing (proxy) certificates • Renewing certificates • Lack of portable tools • Cannot ship current gLite UI to everyone • UI portals may be a solution • Advantages of Grid • Standards! • Job submission • Data management • Security

  14. Acknowledgments • Kor Begeman (implementation in Astro-Wise) • Willem Jan Vriend (implementation in Astro-Wise) • Danny Boxhoorn • Andrey Belikov All from: OmegaCEN Kapteyn Institute University of Groningen, NL
