Sect. 11.3: Angular Momentum Rotating Rigid Object. Translation-Rotation Analogues & Connections. Translation Rotation Displacement x θ Velocity v ω Acceleration a α Force (Torque) F τ Mass (moment of inertia) m I

Télécharger la présentation
## Sect. 11.3: Angular Momentum Rotating Rigid Object

**An Image/Link below is provided (as is) to download presentation**
Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.
Content is provided to you AS IS for your information and personal use only.
Download presentation by click this link.
While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.
During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

**Translation-Rotation Analogues & Connections**Translation Rotation Displacement x θ Velocity v ω Acceleration a α Force (Torque) F τ Mass (moment of inertia)m I Newton’s 2nd Law ∑F = ma ∑τ = Iα Kinetic Energy (KE) (½)mv2 (½)Iω2 Work (constant F,τ) Fd τθ Momentum mv ? CONNECTIONS: s = rθ,v = rω, at= rα ac = (v2/r) = ω2r , τ = Fdsin, I = ∑(mr2)**Recall:Angular MomentumLof point massmat position rmoving**with momentump = mv(see figure)the cross product: • Units:(kg.m2)/s • Magnitude:L = mvr sin =angle betweenp& r • Direction:Perpendicular to the plane formed byr&p. If r& pare in thexy-plane, Lis in thez-direction.**Special Case:Particle of mass m moving with**velocity v in a circular path of radius r (see figure).Momentum p = mv. Note also that for this case, v = rω, where ω = angular velocity of m around the center of the circle. • Angular Momentum Magnitude L = mvr sin(90o) = mvr = mr2ω vis perpendicular tor anglebetweenp& r is = 90º sin = sin(90o) = 1 • Angular Momentum Direction Vectoris pointed out of the diagram (towards the reader). • So, a particle in uniform circular motion has a constant angular momentum L = mvr = mr2ω about an axis through the center of its path.**Generalize to a Rigid Object rotating about an axis passing**through it’s center of mass (see figure).Each particle in the object rotates in the xy plane about the z axis with angular speed w.Angular momentum of an individual particle is Li = mi ri2w. The vectors & are directed along the z axis.**To find the total angular momentum Lof the object, sum up**the angular momentaLiof the individual particles: (1) From Ch. 10, I ∑miri2is the object’s moment of inertia. Combining (1) with Newton’s 2nd Law for Rotations: Gives: Newton’s 2nd Law for Rotations: (for rigid objects) α =angular acceleration of the object**Example 11.5: Bowling Ball**• A bowling ball (assume a perfect sphere, mass M = 7 kg, radius R = 0.12 m), spins at frequencyf = 10 rev/s ω = 2πf = 20π rad/s From table (Ch. 10) moment of inertia is I = (2/5)MR2 • Calculate the magnitude of the angular momentum, Lz = Iω • Direction of L is clearly the +z direction. Lz = Iω = (2/5)MR2ω = (2/5)(7)(.12)2(20π ) = 2.53 kg m2/s**Example 11.6: Seesaw**• A father, mass mf& his daughter, mass md sit on opposite sides of a seesaw at equal distances from the pivot point at the center. Assume seesaw is a perfect rod, mass M & length l. At some time, their angular speed is ω. • Table (Ch. 10) gives moment of inertia of seesaw:Is = (1/12)Ml2. Moments of inertia of the father & daughter about pivot point. Treat them like point masses:If = mf[(½)l]2, Id = md[(½)l]2 (A) Find an expression for the magnitude of the angular momentum (about pivot point) at time when angular speed is ω. Note: Total moment of inertia is:I = Is + If + Id = (1/12)Ml2 + (¼)mfl2 + (¼)mdl2 The total angular momentum is: L = Iω = (¼)l2[(⅓)M + mf + md]ω**Example 11.6: Seesaw continued**mdgcosθ (B) Find an expression for the magnitude of the angular acceleration when the seesaw makes an angle θ with the horizontal.Newton’s 2nd Law for Rotations:∑τext= Iα ∑τext= [(1/12)Ml2 + (¼)mfl2 + (¼)mdl2]α (1) Left side: ∑τext= τs+τf +τd mfgcosθ Torque definition: τ = rFsin = Fd; = angle between force F & vector r from point of application to pivot point. Moment arm d = rsin Seesaw: τs= Mgds; Mgpasses through pivot point. Moment armds = 0 τs= 0 Father: τf= wfdf; wf = component of father’s weight: wf = mfgcosθdf = (½)lsin; = 90º, sin = 1, df = (½)l τf= (½)lmfgcosθ(counterclockwise, positive torque!) Daughter: τd= wddd; wd = component of daughter’s weight: wg = mfgcosθ; dd = (½)lsin; = 90º, sin = 1, dd = (½)l τd= - (½)lmfgcosθ(clockwise, negative torque!) So, from (1),α = [∑τext]/I = [2(mf – md)cosθ](l)[(⅓)M +mf+ md]
