Layer Command in AutoCAD

In this command we can give the different color for the different type of object and different type of style also. We can edit the object of the different type from the current layer window.<br><br>

instituteadmec
Télécharger la présentation

Layer Command in AutoCAD

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. LAYER COMMAND LAYER COMMAND PRESENTATION PRESENTATION ADMEC MULTIMEDIA INSITITUTE C-7/114, 2nd FLOOR, SECTOR- 7, ROHINI, NEW DELHI PRESENTED BY: ANKIT SINGH

  2. LAYER COMMAND LAYER COMMAND This command’s shortcut is LA (Enter). In this command we can give the different color for the different type of object and different type of style also. We can edit the object of the different type from the current layer window. This command allows you to create the different type of object. When we using the layer command then open a layer window. There are many types of sub tool to modifying the object.

  3. This is the window of layer where's we can change the object line type, line weight, color and give the description of the object.

  4. NEW PROPERTY FILTER NEW PROPERTY FILTER In this property, from which current layer we have done work, we can save and hide that layer. We cannot modify layer in this property.

  5. NEW GROUP FILTER NEW GROUP FILTER In this option we can save and maintain the layer from which layer we have done our work.

  6. LAYER STATES MANAGER LAYER STATES MANAGER In this option we can save the layer for recovery, from which layer we have done work. If we have done our work from many layer then we can save our layer in this option, and we are recover in this.

  7. NEW LAYER (Alt + N) NEW LAYER (Alt + N) From this option we can make a new layer according to our work and we can give the name of layer.

  8. NEW LAYER VP FROZEN IN NEW LAYER VP FROZEN IN ALL VIEWPORTS ALL VIEWPORTS This option is work as a new layer option. In this option we can freeze the layer.

  9. DELETE LAYER (Alt + D) DELETE LAYER (Alt + D) From this option we can delete the layer which is not usable.

  10. SET CURRENT LAYER (Alt + C) SET CURRENT LAYER (Alt + C) From this option we can set the layer which is we want to use in drawing.

  11. ON ON In this option we can hide or unhide the object.

  12. FREEZE FREEZE In this layer we can hide and leave the object. This layer is never freeze current layer.

  13. LOCK LOCK In this layer we can lock the layer which we want to lock. If we are locking the layer then we cannot done any work of object which is made by that layer.

  14. COLOR COLOR In this layer we can give the different color of different object.

  15. LINETYPE LINETYPE In this layer we can change the line type of object.

  16. LINEWEIGHT LINEWEIGHT In this layer we can change the line width of object.

  17. From Menu Bar Format – Layer Tool There are many tools of layer such as..

  18. MAKE OBJECT’S LAYER CURRENT MAKE OBJECT’S LAYER CURRENT From this tool we can change the object layer in to the current layer.

  19. LAYER PREVIOUS LAYER PREVIOUS From this tool we can set the current layer to previous layer which layer is active first from the current layer.

  20. LAYER WALK LAYER WALK From this tool we can see from which layer to make which object.

  21. LAYER MATCH LAYER MATCH From this tool we can match any object layer to any object layer.

  22. CHANGE TO CURRENT LAYER CHANGE TO CURRENT LAYER From this tool we can convert the any layer of object in the current layer.

  23. COPY OBJECTS TO NEW LAYER COPY OBJECTS TO NEW LAYER From this tool we can copy the layer object and we can change the layer of copy object.

  24. LAYER ISOLATE LAYER ISOLATE From this tool we can highlight the layer object which was we selected.

  25. THAW THAW From this tool we can unfreeze of all layer.

  26. COLOR COLOR Its shortcut command is COL (Enter). When we will open this command after that window will be open, from this we can maintain color. There are two option (By layer, By block) to maintain the color.

  27. BYLAYER BYLAYER BYLAYER In this option we can maintain the color from current layer only.

  28. BYBLOCK BYBLOCK BYBLOCK From this option, in running with current layer we can make the content through any color. We maintain the by block through property option .

  29. -- Contact Us - ADMEC MULTIMEDIA INSTITUTE Leader in Animation & Digital Media Education ISO 9001 : 2008 CERTIFIED - Visit Our Websites - www.admecindia.co.in www.cadtraininginstitute.com Phones: +91-9811-8181-22, +91-9911-7823-50

  30. T h a n k y o u
