  1. Distribution ED01 English OfficeServ 7400 VE Introduction Module No. : STM #117 August, 2006 Mail to training@samsung.com

  2. Objectives • After successful completion of the course the trainees should be able to execute the following activities. ⓒ SAMSUNG Electronics Co.,Ltd.

  3. Contents Comparison 7200 & 7400 Features of OfficeServ7400 T-Model OS7400 vs OS7400 VE ⓒ SAMSUNG Electronics Co.,Ltd.

  4. Comparison 7200 & 7400 ⓒ SAMSUNG Electronics Co.,Ltd.

  5. OfficeServ 7200 Configuration Internal Connection (10/100Base-Tx) Mail Server (WEB Server) LIM 1 2 3 4 9 10 11 12 5 6 7 8 13 14 15 16 V.35 RS232C 10/100Base-Tx 10Base-T 10/100Base-Tx DSU/CSU WIM ADSL/VDSL/Cable Modem Console eth1 eth2 eth0 eth3 SIO Edge Router Office PC SERIAL Internet DSLAM Router Module FE Switch Module ⓒ SAMSUNG Electronics Co.,Ltd.

  6. OfficeServ 7400 Configuration T3/E3 Internet(WAN) T1/E1 eth0 eth1 GWIM Router V.35 eth2 HSSI GSIM GSIM L3 Switch GPLIM GPLIM L2 Switch GPLIM GPLIM 10/100Mbps 1000Mbps RJ-45 console ⓒ SAMSUNG Electronics Co.,Ltd.

  7. OfficeServ 7400 Network Configuration F.S F.S F.S F.S F.S F.S F.S F.S F.S F.S F.S F.S Switch (Gigabit) Switch (Gigabit) Switch (10/100M) Switch (10/100M) Switch (10/100M) Switch (10/100M) Switch (10/100M) Switch (10/100M) Switch (10/100M) Switch (10/100M) WAN (CSU / DSU) WAN (xDSL/CABLE) OfficeServ Enterprise Third G.S OfficeServ Enterprise Router Call server Workstation IP Phone OfficeServ Enterprise Second G.S F.S First Floor Part A Part B Workstation IP Phone Workstation IP Phone Workstation IP Phone Server ※ G.S = Switch (Gigabit) F.S = Switch (10/100M) ⓒ SAMSUNG Electronics Co.,Ltd.

  8. Comparison OfficeServ 7200 & 7400 (1/3) • OS7200(2 Rack) • LIM: 1.6Gbpa * 4ea * 2 • OS7400(3 Rack) • GSIM: 10Gbps * 2ea * 3 • GPLIM:3.2Gbps * 11ea *3 ⓒ SAMSUNG Electronics Co.,Ltd.

  9. Comparison OfficeServ 7200 & 7400 (2/3) ⓒ SAMSUNG Electronics Co.,Ltd.

  10. Comparison OfficeServ 7200 & 7400 (3/3) ⓒ SAMSUNG Electronics Co.,Ltd.

  11. Features of OS7400 T-Model ⓒ SAMSUNG Electronics Co.,Ltd.

  12. OS7400 T-Model • Capacity ⓒ SAMSUNG Electronics Co.,Ltd.

  13. OS7400 T-Model • GWIMT Layout System Controller MV64460 (Marvell) RGMI x 3 GE_PHY BCM5464 (Broadcom) MAGNETIC H5008 1 Port MAGNETIC H5012 2 Port RJ45 Module 657PCB8-DUPLEX-ST2 (DEE) 4 Ports SIO/Debug Port ⓒ SAMSUNG Electronics Co.,Ltd.

  14. OS7400 T-Model • GSIMT Layout SWITCH BCM5696 (Broadcom) 12 Port SGMII x 3 SGMII x 4 SGMII x 3 GE_PHY BCM5464 (Broadcom) GE_PHY BCM5464 (Broadcom) GE_PHY BCM5464 (Broadcom) MAGNETIC H5008 x 2 H5012 x 2 RJ45 Module 44170-0002 (MOLEX) 12 Ports SIO/Debug Port ⓒ SAMSUNG Electronics Co.,Ltd.

  15. OS7400 T-Model • GPLIMT Layout Fast Ethernet Switching Chip VIA VT6526CF 24 Port SS-SMII x 6 SS-SMII x 6 GMII FE_PHY VT6108 (VIA) 8 Ports FE_PHY VT6108 (VIA) 8 Ports GE_PHY BCM5464 (Broadcom) MAGNETIC H5012 2 Port MAGNETIC H2006AN x 3 6 Ports MAGNETIC H2006AN x 3 6 Ports RJ45 Module 44170-0002 (MOLEX) 12 Ports RJ45 Module 2 Port ⓒ SAMSUNG Electronics Co.,Ltd.

  16. OS7400 vs OS7400 T-Model ⓒ SAMSUNG Electronics Co.,Ltd.

  17. OS7400 via OS7400 T-Model • Comparative Table (Base on Ethernet Ports) ⓒ SAMSUNG Electronics Co.,Ltd.

  18. OS7400 via OS7400 T-Model • GWIM via GWIMT ⓒ SAMSUNG Electronics Co.,Ltd.

  19. OS7400 via OS7400 T-Model • GSIM via GSIMT ⓒ SAMSUNG Electronics Co.,Ltd.

  20. OS7400 via OS7400 T-Model • GPLIM via GPLIMT ⓒ SAMSUNG Electronics Co.,Ltd.
