  1. NetherLight update Lambda networking in The Netherlands, Europe Erik-Jan Bos, SURFnet

  2. Overview • SURFnet intro • Hybrid networking, SURFnet6 • GLIF, GOLEs, NetherLight SURFnet, Pioneering Network for Higher Education and Research

  3. SURFnet • Dutch National Research & Education Network (NREN) • Not for profit organization, 60 employees • 100% ownership by users via SURFfoundation • 180 connected institutions, 750.000 end-users • Business-model: • Innovation by project subsidies (14 M€/year) • Operations by tariffs from institutions (18 M€/year) SURFnet, Pioneering Network for Higher Education and Research

  4. NREN Challenge • How to accommodate needs of scientific users for higher speed, higher quality networking, e.g.: • Astronomy: eVLBI and LOFAR • Particle Physics: Large Hadron Collider • Medical research • Media streaming, such as HDTV and 4K • While protecting the performance of the network for current users • And keeping the successful end-to-end model of the internet SURFnet, Pioneering Network for Higher Education and Research

  5. Photo section SURFnet, Pioneering Network for Higher Education and Research

  6. eEVN: European VLBI Network Data processing centre: 16 Gbps (2005)1 Tbps(2010) Russia China USA asymmetric star topology 1-30Gbps South Africa SURFnet, Pioneering Network for Higher Education and Research This slide courtesy of Richard Schilizzi schilizzi@jive.nl, from 2003…

  7. LHC high-level network architecture SURFnet, Pioneering Network for Higher Education and Research

  8. We realized that… • Counting on bigger routers and fatter pipes was no longer a realistic option. • And introducing QoS was not a viable alternative of course. • Next Generation Research Networks would not be a simple extrapolation of the current Internet evolution anymore. SURFnet, Pioneering Network for Higher Education and Research

  9. Hybrid networking • Hybrid Networking concept has evolved since 2001 in a global context, with yearly LambdaGrid Workshops. IP + lambdas • Packet switched internet for regular many-to-many usage • Light Paths for new high speed few-to-few usage SURFnet, Pioneering Network for Higher Education and Research

  10. Lightpaths and OPNs • Lightpath: high quality and high capacity optical network connection • Lightpaths provide applications with dedicated bandwidth with fixed characteristics at relatively low costs and with added security • Optical Private Network: system of permanent lightpaths to interconnect multiple locations SURFnet, Pioneering Network for Higher Education and Research

  11. SURFnet6 overview • Nation-wide hybrid optical and packet switching infrastructure • Based on 6000+ km of SURFnet-owned managed dark fiber, all the way to the institutions premises • SURFnet6 delivers 1/10 Gbit/s IP services (native IPv4 and IPv6) plus lightpath provisioning: • Over a single transmission infrastructure • Managed via a single control plane • In an economically sound way SURFnet, Pioneering Network for Higher Education and Research

  12. SURFnet6 infrastructure Hamburg Muenster Aachen SURFnet, Pioneering Network for Higher Education and Research

  13. Service Interface: web GUI or API (web services) Control plane Lichtpaths are becoming user controlled public DRAC internal User Admin CPE Customer equipment CPE Customer equipment Resource SURFnet, Pioneering Network for Higher Education and Research

  14. GLIF, Global Lambda Integrated Facility • In 2003 it was agreed to continue the international cooperation for lambda networking under the name GLIF. • GLIF is an international virtual organization managed as a cooperative activity with ‘participants’ rather than ‘members’ under a lightweight governance structure. • Open to anybody sharing the vision of optical interconnection of different facilities, who voluntarily contributes network resources (e.g. equipment, lambdas) or actively participates in relevant activities. • Secretariat functions provided by TERENA with voluntary contributions from participants. SURFnet, Pioneering Network for Higher Education and Research

  15. GLIF Vision Linking the World with Light • Optical networks are the central architectural element in support of this decade’s most demanding e-science applications. • A research world without geographical boundaries. • Hybrid research networks worldwide connected by lambdas and GLIF Open Lightpath Exchanges (GOLEs) SURFnet, Pioneering Network for Higher Education and Research

  16. GLIF Working Groups (1) • Governance and Growth (GOV) Working Group Chair: Kees Neggers (SURFnet) Goals: To identify future goals in terms of lambdas, connections and applications support, and to decide what cross-domain policies need to be put in place. • Research and Applications (RAP) Working Group Chair: Maxine Brown (UIC) & Larry Smarr (UCSD) Goals: To train a new generation of scientists on the use of super-networks. SURFnet, Pioneering Network for Higher Education and Research

  17. GLIF Working Groups (2) • Technical Issues (Tech) Working Group Co-Chairs: Erik-Jan Bos (SURFnet) & René Hatem (CANARIE)Goals: The goals of the working group are to design and implement an international LambdaGrid infrastructure, identify which equipment is being used, what connection requirements are required, and which functions and services should be provided. • Control Plane and Grid Integration Middleware Working Group Chair: Gigi Karmous-Edwards (MCNC)Goals: To agree on the interfaces and protocols that talk to each other on the control planes of the contributed Lambda resources. SURFnet, Pioneering Network for Higher Education and Research

  18. GLIF resources: lambdas SURFnet, Pioneering Network for Higher Education and Research

  19. GLIF resources: GOLEs • GLIF lambdas are interconnected through established lightpath exchange points known as GOLEs: GLIF Open Lightpath Exchanges • GOLEs are comprised of equipment capable of terminating lambdas and performing lightpath switching, allowing end-to-end connections • GOLEs have an open connection policy SURFnet, Pioneering Network for Higher Education and Research

  20. AMPATH – Miami, FL, USA CERN – Geneva, CH CzechLight – Praha, CZ HKOEP - Hong Kong, CN KRLight – Daejoen, KR MAN LAN - New York, NY, USA MoscowLight – Moscow, RU NetherLight – Amsterdam, NL NGIX-East – Washington, DC, USA NorthernLight – Stockholm, SE Pacific Wave (LAX) - Los Angeles, CA, USA Pacific Wave (SEA) – Seattle, WA, USA Pacific Wave (JSV) – Sunnyvale, CA, USA StarLight – Chicago, IL, USA T-LEX – Tokyo, JP UKLight – London, UK GOLEs around the world http://www.glif.is/resources/ SURFnet, Pioneering Network for Higher Education and Research

  21. NetherLight: The GOLE in Amsterdam • GLIF Open Lightpath Exchange, located in the Science Park Amsterdam • Operational since January 2002 • Built and operated by SURFnet • Nortel HDXc Optical Cross Connect at the centre (full duplex 640G non-blocking) • Nortel OME6500, Nortel ERS8600, and Cisco ONS15454 at the edges for grooming SURFnet, Pioneering Network for Higher Education and Research

  22. NetherLight Topology SURFnet, Pioneering Network for Higher Education and Research

  23. 7th Annual Global LambdaGrid Workshop • The 2007 GLIF Workshop will be held on September 17-18, 2007 in Prague, Czech Republic • Host: CESNET, Czech NREN • Location: Charles University, Prague • Followed by: 4th Customer Empowered Fiber Workshop SURFnet, Pioneering Network for Higher Education and Research

  24. Questions? • More information: http://www.netherlight.net/ http://www.glif.is/ http://www.surfnet.nl/info/en/ Erik-Jan Bos <erik-jan.bos@surfnet.nl> SURFnet, Pioneering Network for Higher Education and Research
