  1. Batteries Physics

  2. Power Cell • Device for storing chemical energy and then releasing it in the form of electricity when current is needed

  3. Battery • More than one power cell working together

  4. 9 V battery Inside a 9 V are 6-1.5 V power cells connected in a row.

  5. Parts of a Power Cell 1. Anode • Metal • High affinity for oxygen • Draw oxygen from cathode to become oxidized

  6. Parts of a Cell 2. Cathode • Metallic oxide • Lower affinity for oxygen • Becomes reduced when oxygen is taken

  7. Parts of a Cell 3.Separator • Insulator • Keeps cathode separated from anode to control reaction

  8. Parts of a Cell 4.Current Collector • Connected to anode and cathode • Good conductor 5.Electrolyte • Usually liquid (ionized water, acid/base) • “Domino Effect” of oxygen from cathode to anode

  9. Operation of Power Cell • As anode becomes oxidized, an electron must be given up • Electron flows through anode’s current collector  through circuit (outside of battery) as electrical current  back to cathode’s current collector

  10. Carbon-Zinc (C-Zn) • 1.5 volts • Works well if using 100 mA or less • Low capacity • 3 year shelf life

  11. anode and anode collector NH4Cl ZnCl2 Cathode collector MnO2

  12. Alkaline • 1.5 V: lose voltage gradually • High Capacity (electrical energy) • Last longer • 5 year shelf-life • Better in high drain devices than C-Zn

  13. steel MnO2, graphite Electrolyte KOH Zn powder Metal nail

  14. Lithium • Started off as button cell • Anode: lithium • Cathode: magnesium dioxide • 3 V: Takes up less space with more voltage

  15. Lithium • High Capacity • Low Drain Rate • Toxic: Special disposal • Light Weight

  16. Button Cell • Anode: Zinc or Lithium • Cathode: Silver or Mercury Oxide • Compact • Large Life

  17. Recharging Batteries • A current from an outside source is pushed through the cell in the opposite direction from the original current • Oxygen goes from anode to cathode

  18. Nickel-Cadmium (Ni-Cd) • 1.2 Volts • Low capacity • Memory effect (Rechargeable) • If you re-charge the battery too soon, you lower its capacity

  19. Nickel-Metal Hydride (NiMH) • 1.2 V • Best rechargeable battery • High Capacity • Good for high drainage devices

  20. Lithium-Ion • 3.6 V • Slow-loss of charge (5% per month) • Best energy to weight ratio • No memory effect • Popular for portable electronics (cell phones, IPod)

  21. Ideal Power Cell • Unlimited shelf life • Maximum energy for minimum space • Light weight • Rechargeable (fast and complete)

  22. Ideal Power Cell (cont.) • Consumer proof/Safe • Resistant to environmental extremes • Cost • Perform in a variety of different applications

  23. Diode • Made of semi-conducting material • Only permits current to pass in one direction • L.E.D.: light emitting diode • Longer leg must be connected to positive side of circuit (cathode)
