  1. Tool Identification By:Gord Darling Construction Technology

  2. Adjustable Wrench • Turning various size nuts and bolts.

  3. Allen Wrench • Turning hex head socket screws.

  4. Aviation Snips • Cutting sheet metal.

  5. Ball Pein Hammer • Hammering metal.

  6. Bar Clamp • Clamping large sections of wood together.

  7. Bent Nose Pliers • Reaching obstructive or awkward places.

  8. Bolt Cutters • Cutting bolts & steel rods.

  9. Box End Wrench • Turning hex head nuts and bolts.

  10. C Clamp • Clamping two or more pieces of metal together.

  11. Chain Saw File • Sharpening chain saw file.

  12. Chalk Line Reel • Making straight lines.

  13. Circular Carbide Saw Blade • Blade used on portable electric saw.

  14. Cold Chisel • Cutting metal.

  15. Combination Oil Stone • For sharpening and honing cutting tools.

  16. Combination Square • Determining 45o and 90o angles.

  17. Combination Wrench • Turning hex and square nuts and bolts.

  18. Compass • Drawing circles.

  19. Compass Saw • Cutting wood in close places.

  20. Coping Saw • Cutting curves and irregular cuts.

  21. Cordless Drill • Drilling holes with a tool that uses a battery pack.

  22. Countersink • Flaring top of hole for recessing head for flathead screw or bolt.

  23. Diagonal Cutting Pliers • Surface and diagonal wire cutting.

  24. Drift Punch • Aligning holes.

  25. Drill Press Vise • Holding stock while drilling.

  26. Dust Mask • Protects the respiratory system from airborne particles.

  27. Emery Dresser • Smoothing face of grinding wheel.

  28. End Cutting Nippers • Cutting ends of wire, nails and small bolts.

  29. Finishing Nail • Nailing boards where head will not be noticed.

  30. Framing Square • Squaring cut corners and laying out stairs and rafters.

  31. Glass Cutter • Cutting glass.

  32. Groove Joint Pliers • Gripping when greater pressure is needed.

  33. Hack Saw • Sawing metal.

  34. Half Hatchet • Cutting and fitting wood.

  35. Half Round File • Curve and flat filing.

  36. Hammer Drill • Power drilling in concrete, brick or block.

  37. Hand Screw Clamp • Clamping wood together.

  38. Level • Leveling and plumbing.

  39. Line Level • Leveling between long distance points.

  40. Long Nose Pliers • Reaching into recessed areas.

  41. Machinist’s Vise • Holding metal firm while working.

  42. Masonry Bit • Boring a hole in concrete, brick, or block.

  43. Miter Box • Cutting angles.

  44. Nail Hammer • Driving nails.

  45. Nail Set • Countersinking nail heads.

  46. Nailing Gun • Rapid nailing using air, gas, or electricity.

  47. Open End Wrench • Turning square head nuts and bolts.

  48. Phillip’s Screwdriver • Turning phillips heads screws.

  49. Pin Punch • Driving out metal pins.

  50. Pipe Wrench • Turning and holding metal pipe.
