  1. Vector-borne diseases S. Sears, MD

  2. Lyme disease • Multisystem inflammatory disease • Causes by spirochetes • Borrelia burgdorferi • Spread by Ixodes ticks • I. scapularis • Eastern,North central and Southern United States • I. pacificus • Western United States • I. ricinus • Europe • I. persulcatus • Asia • Transmission • Bite of an infected nymph in the spring-really small, barely even know you’ve been bitten • Preferred host • White-tailed deer

  3. Borrelia burgdorferi

  4. Ixodes scapularis

  5. Clinical manifestations • Early localized disease • Occurring few days to one month after the tick bite • Early disseminated disease • Occurring days to 10 months after the tick bite • Late or chronic disease • Occurring months to years after the tick bite

  6. Early localized disease • Erythema migrans • 50-70% of patients • Found • Near axilla • Inguinal region • Behind the knees • Belt line • Asymptomatic • May burn or itch • Expands over the course a few days with central clearing • Associated symptoms • Fatigue • Malaise • Lethargy • Headache • Stiff neck • Myalgias • Arthralgias • Lymphadenopathy

  7. Erythema migrans

  8. Early disseminated disease • Carditis : 8 -10% of patients • Conduction defects • Cardiomyopathy or myopericarditis • Neurologic disease :10% of patients • Lymphocytic meningitis • Encephalitis • Cranial neuropathy (often bilateral facial) • Peripheral neuropathy • Radiculoneuropathy • Myelitis • Musculoskeletal involvement : 50% of patients • Migratory polyarthritis • Skin involvement • Erythema nodosum • Lymphadenopathy • Eye involvement • Conjunctivitis • Iritis • Retinitis • Vitritis • Choroiditis • Hepatitis • Microhematuria with proteinuria

  9. Late or chronic disease • Musculoskeletal symptoms • 50% : migratory polyarthritis • 10% : chronic monoarthritis (knee) • Neurologic disease (incidence not established) • Neuroborrelosis • Encephalopathy • Neurocognitive dysfunction • Peripheral neuropathy • Encephalopathy • Encephalomyelitis • Peripheral neuropathy • Ataxia • Dementia • Psychiatric disturbances • Cutaneous involvement • Acrodermatitis chronica atrophicans • Morphea (localized scleroderma-like lesions)

  10. Acrodermatitis chronica atrophicans

  11. Diagnosis Centers of Disease Control and Prevention criteria • Presence of erythema migrans • OR • At least one late manifestation • Plus laboratory confirmation • Late manifestations can include if not explained by another disease • Musculoskeletal system • Chronic arthritis • Not • Chronic progressive arthritis • Chronic symmetrical arthritis • Fibromyalgia • Nervous system • Lymphocytic meningitis • Cranial neuritis • Encephalomyelitis • CSF confirmation of antibody against B. burgdorferi • Not • Headache • Fatigue • paresthesias

  12. Diagnosis • Serologic tests • Used to confirm the diagnosis • Diagnosis make on clinical grounds • Two-rest step approach • Sensitive enyzme-linked immunosorbent assay (ELISA) • Followed by Western immunoblot • If ELISA positive-test Western blot • If ELISA negative-no Western blot • Same sample tested by each test • If < 4 weeks illness - IgM and IgG tested • If > 4 weeks illness - IgG tested • Synovial fluid or CSF • Tested for the antibodies to B.burgdorferi • Antibiotics in early disease may prevent seroconversion • Prior vaccine interferes with the test (vaccine no longer available)

  13. Treatment Early disease • Erythema migrans • < 10% do not respond • Do not use macrolides • For areas also endemic for human ehrlichiosis use doxycycline • Doxycycline 100mg po bid for 10-21 days • Amoxicillin 500mg po tid for 14-21 days • Cefuroxime 500mg po bid for 14-21 days Disseminated disease • Cardiac • First degree AV block • Doxycycline 100mg po bid for 14-21 days • Amoxicillin 500mg po tid for 14-21 days • Cefuroxime 500mg po bid for 14-21 days • Late disease • Ceftriaxone 2g IV daily for 14-21 days

  14. Treatment Disseminated disease • Neurologic disease • Early • Isolated facial nerve palsy • Doxycycline 100mg po bid for 14-21 days • Amoxicillin 500mg po tid for 14-21 days • Cefuroxime 500mg po bid for 14-21 days • More serious disease • Early or late • Meningitis • Radiculopathy • Encephalitis • Ceftriaxone 2 g IV daily for 14-28 days • Arthritis • No evidence of neurologic disease • Doxycycline 100mg po bid for 28 days • Amoxicillin 500mg po tid for 28 days • Cefuroxime 500mg po bid for 28 days • With neurologic disease • Ceftriaxone 2g IV daily for 14-28 days

  15. Outcome • Treatment with standard antibiotics generally successful • 10 % experience treatment failure • Non-specific symptoms may linger • Asymptomatic seropositive patients • Recommendation not to treat

  16. Human ehrlichiosis Ehrlichiae • Obligate intracellular bacteria • Grow in membrane bound vacuoles • Human and animal leukocytes • Diseases • Human monocytic ehrlichiosis (HME) • Caused by Ehrlichia chaffeensis • Human granulocytic anaplasmosis (HGA) • Caused by Anaplasma phagocytophilum • Occurs in spring and summer • In southeastern, southcentral,mid-Atlantic United States • Tick vector • E.chaffeensis - Lone star tick (Amblyomma americanum) • A.phagocytophilum - Ixodes scapularis • Animal reservoir • HME - white tail deer • HGA - deer and white-footed mouse

  17. Ehrlichia chaffeensis

  18. Lone star tick

  19. Clinical manifestations • Incubation period 1-2 weeks prior to presentation of symptoms • Fever can persist for 2 months • Nonspecific • Malaise • Myalgia • Headache • Chills • Nausea • Vomiting • Arthralgias • Cough • Maculopapular or petechial rash • Neurologic • Mental status changes • Stiff neck • Clonus • Complications • Seizures • Coma • Congestive heart failure • Pericardial effusion

  20. Rash

  21. Investigations • Laboratory findings • Leukopenia • Thrombocytopenia • Anemia • Increased liver function tests • CSF lymphocytic pleocytosis • Diagnosis • Indirect fluorescent antibody (IFA) test • Examination of peripheral blood or buffy coat • PCR for HME and HGA • Immunochemical staining of ehrlichial/anaplasmal antigens in tissue

  22. Treatment • Drug of choice • Doxycycline IV or oral • 100 mg bid for 10 days • Intolerance to doxycycline • Use rifampin 300mg po bid for 7-10 days

  23. Outcome Mortality rates • HME - 2 to 5 percent • HGA - 7 to 10 percent Life-threatening disease • In patients co-infected with HIV • Solid organ transplant recipients Prevention • Tick repellants • Tick removal

  24. Babesiosis • Tick borne illness • Protozoa of the family Babesiidae • Animal reservoir • Rodents and cattle • Human disease • Due to Babesia microti • Enters the red blood cells and causes hemolysis • Vector • Ixodid tick • Occurs northeast coast of the United States

  25. Clinical manifestations • Incubation period • Following a tick bite • 1-3 weeks • After blood transfusion • 6-9 weeks • Symptoms • Fever • Chills • Sweats • Myalgia • Arthralgia • Nausea • Vomiting • Fatigue • Physical exam • Splenomegaly • Hepatomegaly • Jaundice

  26. Severe disease • High-level parasitemia (> 10 percent) • Significant hemolysis ( plus DIC) • Renal ,hepatic, pulmonary compromise Risk factors • Age over 50 years • Asplenia • Underlying malignancy • Immunosuppressive therapy • HIV/AIDS

  27. Diagnosis Laboratory • Anemia • Thrombocytopenia • Conjugated hyperbilirubinemia Confirmation • Blood smear • Intraerythrocytic parasites • PCR • Serology • Indirect immunofluorescent antibody test

  28. Babesia microti

  29. Treatment • First-line treatment • 7-10 days • Clindamycin-quinine • Or atovaquone-azithromycin • Dosing • Atovaquone - 750 mg po q 12 hrs • Azithromycin - 500-1000 mg po x1 then 250 mg po daily • Clindamycin - 600 mg po tid or 300 mg IV qid • Quinine - 650 mg po q6hrs • Severe disease • Antibiotics • Plus exchange transfusion • Until parasitemia is < 5 percent • Outcome is variable with level of disease

  30. Malaria • Human malaria caused by species Plasmodia • P. falciparum • P. vivax • P. ovale • P. malariae • Predominates • Tropical Africa • Southeast Asia • Haiti • South America • Dominican Republic • Central America • Middle East • India • Transmission • Bite of Anopheles mosquito • Congenital • Blood transfusion • Contaminated needles • Transplantation

  31. Anopheles mosquito

  32. Malaria All four malaria parasites • Digest red blood cell proteins and hemoglobin • Results in hemolysis and increased splenic clearance Liver and spleen enlarge over time • Thrombocytopenia from increased splenic clearance P. Falciparum • Forms stick knobs • Forms rosettes • Results in obstruction of blood flow Protection against malaria • Sickle cell genetic alterations • Alpha thalassemia • Beta thalassemia • Ovalocytes Immunity • Partial immunity may occur in those in endemic areas

  33. Cycle of malaria

  34. Clinical manifestations Incubation period • 1-4 weeks Symptoms • Chills • Sweats • Headache • Myalgias • Fatigue • Nausea • Abdominal pain • Vomiting • Diarrhea • Cough • Signs • Anemia • Thrombocytopenia • Splenomegaly • Hepatomegaly • Jaundice • Splenic rupture

  35. Clinical manifestations P. falciparum • Associated with transient increases in HIV viral load • Cerebral malaria • Impaired state of consciousness • Seizures Risk factors • Age • Pregnancy • Poor nutritional status • HIV infection • Prior splenectomy Complications • Renal failure • ARDS • Hypoglycemia • Anemia • Bleeding • Gastroenteritis P. vivax and ovale • Liver forms-late relapses P. malariae • GN from chronic immune complex formation and deposition

  36. Diagnosis Light microscopy • Stained thick and thin blood smear • Thick smear • Malaria • Thin smear • Morphologic features • Parasite density estimation • Fluorescent microscopy • Antigen detection • PCR- DNA / RNA

  37. Blood smear

  38. Treatment Supportive measures Antimalarial medications Mechanisms of antimalarial drugs • Quinoline derivatives • Chloroquine,quinine,quinidine,mefloquine • Inhibit heme polymerase activity • Accumulation of free heme is toxic to parasites • Antifolates • Pyrimethamine,sulfonamides,dapsone • Kill intrahepatic forms of the parasite • Artemisinin derivatives • Artemisinin,artemether,artesunate • Produce free radical that damage parasite proteins • Antimicrobials • Clindamycin,atovaquone,tetracyclines • Kill blood parasites

  39. Treatment Chloroquine-sensitive • P.vivax • P.ovale • P. malariae • Chloroquine 10mg base/kg (max 600mg base) • Followed by 5mg/kg base (max 300mg base) • At 6, 24,and 48 hours • Cure rates 95% Chloroquine resistant • P. vivax • Mefloquine or quinine PLUS doxycycline Prevention of relapse • Liver forms of malaria • P. vivax and P. ovale • Primaquine 30mg/day for 14 days • Start immediately after completing chloroquine • Screen for glucose-6-phosphate-dehydrogenase to prevent hemolysis

  40. P. Falciparum malaria Chloroquine-sensitive • Treat like other forms of malaria for the chloroquine Most cases are chloroquine-resistant • Uncomplicated disease • One of the following: • Quinine-based • Atovaquone-proquanil • Mefloquine • Artemisinin derivative combinations Quinine-based • Quinine sulfate 10mg/kg salt (max 650 mg) q8hrs for 3-7days • Combined with • 3 tabs of pyrmethamine-sulfadoxine(25/500mg) on day three • Or doxycycline 100mg po bid for seven days • Quinine causes reversible tinnitus and reversible high-tone hearing loss

  41. P. Falciparum malaria Atovaquone-proquanil • 250mg atovaquone plus 100mg proguanil • Four tablets for 3 days • Common side-effects gastrointestinal Mefloquine • 25 mg/kg base as a single dose • Side-effects • Vomiting,nightmares,ataxia,delirium,seizures Artemisinin derivatives • IV ,IM or oral • Given for 5-7 days • 4mg/kg on day 1 • 2mg/kg on days 2,3 • 1mg/kg on days 4-7 • Combined with • Mefloquine-750mg then in 12 hrs 500mg • Or doxycycline 100mg po bid for 7 days • No serious toxicities from artenisinin derivatives have been observed in humans

  42. Severe Falciparum malaria Definition • Parasitemia of > 5 percent • Altered consciousness • Oliguria • Jaundice • Severe normocytic anemia • Hypoglycemia • Organ failure Additional features • Seizures • Acute renal failure • Electrolyte abnormalities • Metabolic acidosis • ARDS • Shock • Hemoglobinuria • bleeding

  43. Treatment-severe disease Use intravenous medications • Quinine-based • IV quinidine gluconate 10mg/kg over 2 hrs the 0.02mg/kg/min • Artemisinin-based • Artesunate 2.4 mg/kg IV followed by 1.2mg/kg at 12 and 24 hrs the 1.2mg/kg daily for 6 days • Quinine-resistant • Artenisinin-based • Plus tetracycline or mefloquine • Artenisinin not in the United states • Need to use quinine plus tetracycline/doxycycline • Supportive measures • Exchange transfusion • For parasitemia > 10% • Or MSOF • Transfusion • Removes parasitized red blood cells • Parasitic toxins • Cytokines • Replaces with fresh plasma • Continue until parasitemia < 5 %

  44. Prognosis Mortality • Untreated-100% • Treated -10-40 % Indicators of poor prognosis • Age < 3 years • Deep coma • Convulsions • Papilledema • Absent corneal reflexes,decorticate/decerebrate rigidity • Organ dysfunction,ARDS,shock • Parasitemia > 5% • Peripheral mature pigmented parasites • Hematocrit <15 %, hemoglobin < 5 g/dL • Peripheral WBC > 12,000 • Blood glucose < 40 g/dL • BUN > 60 mg/dL or creatinine > 3mg/dL • Lactate > 5 mmol/L • Increased liver function test 3 times normal • High CSF lactate >6 mmol/L • Low antithrombin III levels • High plasma TNF concentration

  45. Rocky Mountain Spotted Fever Causative agent rickettsia • Gram-negative bacteria-coccobacillus • Intracellular parasite • Grows in the nucleus and cytoplasm of host cells Vector • Dermacentor variabilis-American dog tick • Eastern and south central United States • Dermacentor andersonii-Rocky Mountain wood tick • Mountain states west of Mississippi • Brown dog tick (Rhipicephalus sanguineus) • Arizona • Ricksettsia • Induces cell death and necrosis • Leads to vasculitis • Hemorrhage • Increased vascular permeability • Edema • Activation of humoral immunity

  46. Rickettsia rickettsii

  47. American dog tick

  48. Brown dog tick

  49. Clinical manifestations Occurs in spring and summer • Fever-common • Severe headache • Malaise • Arthralgias • Nausea • Between 3-5 days • Rash • Begins on the ankles and wrists • Spreads to hands and feet • Spreads centrally • Maculopapular and becomes petechial • Abnormal mentation • Seizures • Focal neurologic deficits

  50. Rash
