Comm Operator Tool - RS232 Device Simulator & Communication Software

Comm Operator is a versatile tool for simulating, testing, and troubleshooting RS232 devices. It allows communication via Serial Port, TCP/IP, and UDP, with support for Text, Hex, and Decimal formats. The tool features quick send panel for NCD relay boards and XBee devices, automated data sending, and checksum support. Users can work with multiple data files, create COP files, and log data for later use.

kamil
Télécharger la présentation

Comm Operator Tool - RS232 Device Simulator & Communication Software

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Comm Operator Introduction Serial Port Tool http://www.serialporttool.com

  2. Content • What is Comm Operator for • Main GUI • Main Features

  3. What is Comm Operator for • RS232 device simulator. • Debug, test and troubleshoot RS232 devices. • Communicate with Serial Port, TCP/IP and UDP. • Auto send and receive data.

  4. Menu Tool Bar Quick Send Panel Data Log Panel Send Data List Panel Status Bar Main GUI

  5. Main Features • Communicate with Serial Port, TCP/IP and UDP • Support data in Text, Hex and Decimal format • Support quick send panel for NCD relay boards and XBee devices • Send data automatically with predefined rules • Send data repeatedly with appointed interval • Support three methods for checksum • Work with multiple send data list files • Create send data list from file in different format • Copy and paste data between different list • Create COP file for Comm Operator Pal • Keep data log to a file for later using • Drag and drop to open send data list directly

  6. Communicate with Serial Port, TCP/IP and UDP

  7. Support data in Text, Hex and Decimal format

  8. Support quick send panel for NCD relay boards and XBee devices

  9. Send data automatically with predefined rules

  10. Send data and repeatedly with appointed interval

  11. Support three methods for checksum

  12. Right-Click to show Work with multiple send data list files

  13. Create send data list from file in different format

  14. Copy and paste data between different list

  15. Create COP file for Comm Operator Pal

  16. Keep data log to a file for later using

  17. Drag and drop to open send data list directly
