1. Shock Stephanie N. Sudikoff, MD
Pediatric Critical Care
Yale School of Medicine
2. Learning Objectives
Understand the pathophysiology of shock
Understand the principles of treatment of shock
Examine septic shock as one example
3. The reason you get up in the morning is to deliver oxygen to the cells.
Mark Mercurio, MD
5. Oxygen Consumption vs. Delivery Oxygen consumption (DEMAND)
VO2 = CO x (CaO2-CvO2)
Oxygen delivery (SUPPLY)
DO2 = CO x CaO2
7. What are PRELOAD and AFTERLOAD?
8. Preload PreloadLV = (EDPLV)(EDrLV)/2tLV
where, LV = left ventricle
ED = end diastole
Represents all the factors that contribute to passive ventricular wall stress at the end of diastole
10. Venous return and CO
11. Factors affecting venous return Decrease in intravascular volume
Increase in venous capacitance
Increase in right atrial pressure
Increase in venous resistance
12. Afterload AfterloadLV = (SPLV)(SrLV)/2tLV
where, LV = left ventricle
S = systole
Represents all the factors that contribute to total myocardial wall stress during systolic ejection
14. Myocardial contractility
15. Myocardial contractility
16. Heart rate HR ? CO
At high HR, diastolic filling is impaired
Atrial contraction accounts for up to 30% of Stroke Volume
17. SHOCK
19. Classification of Shock
20. Systemic response to low perfusion
21. Systemic response to low perfusion Increase CO
Increase preload
Aldosterone
Na reabsorption
Interstitial fluid reabsorption
ADH secretion
Venoconstriction
22. Systemic response to low perfusion Increase CO
Increase contractility
Sympathetics
Increase afterload
Vasoconstriction
Increase HR
Sympathetics
23. Systemic response to low perfusion Increase CO
Increase contractility
Sympathetics
Increase HR
Sympathetics
Increase SVR
Vasoconstriction
Increase blood volume
24. Local response to low perfusion Increase O2ER
Opening of previously closed capillaries
Increased surface area for diffusion
Shortened diffusion distance
Increased transit time
25. Physical Signs of low CO
26. Objective monitors Systemic perfusion
base deficit
lactate
27. Objective monitors Systemic perfusion
ABG
lactate
CO
PA catheter
Arterio-venous oxygen difference
Preload
CVP
Echo
Myocardial contractility
Echo
Afterload
PA catheter
Invasive or noninvasive BP
HR
EKG
CaO2
Hb
ABG
28. TREATMENT OF SHOCK
29. Goals of therapy Treat underlying cause
30. Reduction of demands for CO Treat hyperthermia aggressively
31. Reduction of demands for CO Treat hyperthermia
Reduce work of breathing
As much as 20% of CO goes to respiratory muscles
32. PPV and CO Advantages
Decreases work of breathing
Improves acidosis
Decreases PVR
Decreases LV afterload
Improves oxygenation
33. Reduction of demands for CO Treat hyperthermia
Reduce work of breathing
Sedation
Seizure control
Paralysis
35. Increase supply:Restoration of perfusion Preload
Fluid resuscitation
Colloids vs. crystalloids
36. Increase supply:Restoration of perfusion Preload
Fluid resuscitation
Colloids vs. crystalloids
Myocardial contractility
Inotropic support
ECMO
Other mechanical support
37. Increase supply:Restoration of perfusion Preload
Fluid resuscitation
Colloids vs. crystalloids
Myocardial contractility
Inotropic support
ECMO
Other mechanical support
Afterload
Vasopressors
Vasodilators
38. Increase supply:Restoration of perfusion Preload
Fluid resuscitation
Colloids vs. crystalloids
Myocardial contractility
Inotropic support
ECMO
Other mechanical support
Afterload
Vasopressors
Vasodilators HR
Anti-arrhythmics
Pacer
39. Increase supply:Restoration of perfusion Preload
Fluid resuscitation
Colloids vs. crystalloids
Myocardial contractility
Inotropic support
ECMO
Other mechanical support
Afterload
Vasopressors
Vasodilators HR
Anti-arrhythmics
Pacer
Beta-blockers?
CaO2
Blood transfusion
Oxygen support
40. SEPTIC SHOCK
43. Types of septic shock Cold shock
? CO, ? SVR (60% pediatric)
Narrow pulse pressure, thready pulses, delayed capillary refill
44. Phases of septic shock Warm shock (early)
? CO, ? SVR
? CO, ? SVR
Wide pulse pressure, bounding pulses, brisk capillary refill
Cold shock (late)
? CO, ? SVR
Narrow pulse pressure, weak pulses, delayed capillary refill
46. Early recognition!
47. Early recognition!
49. Increase preload Aggressive fluid resuscitation
50. Increase preload Aggressive fluid resuscitation
Usually requires 40-60 mL/kg but can be as much as 200 mL/kg
20 mL/kg IV push titrated to clinical monitors
51. Monitor improvement in CO Cardiac output
Heart rate
Urine output
Capillary refill
Level of consciousness
Blood pressure NOT reliable endpoint
52. Increase preload Aggressive fluid resuscitation with crystalloids or colloids
Usually requires 40-60 mL/kg but can be as much as 200 mL/kg
20 mL/kg IV push titrated to clinical monitors
Maintain hemoglobin within normal for age (=10 g/dL)
53. Antibiotic therapy IV antibiotics within 1 hr of recognition of severe sepsis
Cultures before antibiotics
Cover appropriate pathogens
Penetrate presumed source of infection
55. Improve myocardial contractility and titrate afterload
59. Cold Shock, Adequate BP:Decrease afterload
61. Adequacy of resuscitation Capillary refill < 2 sec
Adequate pulses
Warm limbs
Normal mental status
Urine output > 1 mL/kg/hr
Adequate blood pressure
Improved base deficit
Decreased lactate
ScvO2 > 70%
62. Early shock reversal improves outcome
63. SUMMARY
65. Goals of therapy Treat underlying cause
67.
Special thanks to Vince Faustino, MD for use of his slides
