  1. AdventNet Network Simulator By Michael Jovero CS 158B Sec 03

  2. What is a network simulator? • A program that virtually simulates a computer network for the purpose of studying how it behaves under certain circumstances.

  3. Why do we need a network simulator? • It lets us test a conceptual network before we ever implement it. • Significantly saves one a lot of money • We can simulate situations that are otherwise not practical with real network • Its can be an effective training tool for future network managers. • It can also be used to test new NMS apps.

  4. What is AdventNet Network Simulator Toolkit? -it is a suite of fully independent software made specifically to simulate and test a network in a virtual environment.

  5. What are these software that are included in the suite? • Network Designer/Simulator

  6. What are these software that are included in the suite? • Network Designer/Simulator • Cisco Routers and Switches • Hosts/Servers (Linux, Solaris, Windows2000) • Printers (Lexmark inkjet, HP laser etc…) • Firewall

  7. Network Designer

  8. What are these software that are included in the suite? • Network Designer/Simulator • SNMP agent simulator

  9. SNMP Agent Simulator

  10. What are these software that are included in the suite? • Network Designer/Simulator • SNMP agent simulator • IOS simulator (Cisco)

  11. What are these software that are included in the suite? • Network Designer/Simulator • SNMP agent simulator • IOS simulator (Cisco) • Network and Trap Recorders

  12. What are these software that are included in the suite? • Network Designer/Simulator • SNMP agent simulator • IOS simulator (Cisco) • Network and Trap Recorders • MIB Browser • Get, getnext, set and getbulk requests • Graph capability (choice of line or bar graph)

  13. What are these software that are included in the suite? • Network Designer/Simulator • SNMP agent simulator • IOS simulator (Cisco) • Network and Trap Recorders • MIB Browser • SNMP V3 Config Tool

  14. The demo network

  15. References: Adventnet Network Simulation Toolkit Manual, http://www.adventnet.com/products/simulator/help/index.html , Retrieved 3/28/05 Ball, Peter, Introduction to Discrete Event Simulation, http://www.dmem.strath.ac.uk/~pball/simulation/simulate.html#Introduction, Retrieved 3/28/05 The Network Simulator – ns2, http://www.isi.edu/nsnam/ns/index.html, Retrieved 3/28/05
