  1. The UART project Applying what we’ve learned about Linux device-drivers to the PC’s serial-port controller

  2. Project’s purpose • Allow you to gain experience encountering the kinds of issues that commonly arise in crafting software to operate real hardware: • Learning the hardware device’s capabilities • Deciding which driver-methods to implement • Accommodating your platform’s interfaces • Exploiting the OS kernel’s support-functions • Devising a strategy for testing and debugging

  3. Universal Asynchronous Receiver-Transmitter (UART) See our CS635 course website at: <http://cs.usfca.edu/~cruse/cs635f07> for links to the UART manufacturer’s documentation and to an in-depth online programming tutorial

  4. Tx and Rx • The UART has a transmission-engine, and also a reception-engine, which are able to operate simultaneously (i.e., “full-duplex”) • Software controls the UART’s operations by accessing several registers, using the x86 processor’s ‘in’ and ‘out’ instructions • Linux provides some convenient ‘macros’ that ‘hide’ the x86 machine-code details

  5. PC-to-PC communications student workstation student workstation KVM cable KVM cable rackmount PC system rackmount PC system ‘null-modem’ serial cable ethernet cables

  6. Using ‘echo’ and ‘cat’ • Your device-driver module (named ‘uart.c’) is intended to allow unprivileged programs that are running on a pair of adjacent PCs to communicate via a “null-modem” cable Transmitting… Receiving… $ echo Hello > /dev/uart $ _ $ cat /dev/uart Hello _

  7. Kudlick Classroom 08 09 10 15 16 17 18 19 20 28 29 30 04 05 06 07 11 12 13 14 24 25 26 27 01 02 03 21 22 23 lectern Indicates a “null-modem” PC-to-PC serial cable connection

  8. Linux char-driver components Device-driver LKM layout module’s ‘payload’ is a collection of callback-functions having prescribed prototypes function function function AND a ‘package’ of function-pointers fops . . . the usual pair of module-administration functions init registers the ‘fops’ exit unregisters the ‘fops’

  9. Requires a device-file node • Our System Administrator has created the device-file needed for your driver-module: root# mknod /dev/uart c 84 0 root# chmod a+w /dev/uart • Your driver-module needs to ‘register’ your package of driver-methods (i.e., functions) in its initialization routine (and ‘unregister’ them later in its cleanup routine)

  10. ‘write()’ and ‘read()’ • Obviously your driver-module’s ‘payload’ will have to include ‘methods’ (functions) which perform the ‘write()’ and ‘read()’ operations that applications will invoke • You may decide your driver needs also to implement certain additional ‘methods’ • A little history is helpful for understanding some of the UART device’s terminology

  11. DCE and DTE • Original purpose of the UART was for PCs to communicate via the telephone network • Telephones were for voice communication (analog signals) whereas computers need so exchange discrete data (digital signals) • Special ‘communication equipment’ was needed for doing the signal conversions (i.e. a modulator/demodulator, or modem)

  12. PC with a modem computer terminal modem serial cable Data Communications Equipment (DCE) Data Terminal Equipment (DTE) phone wire

  13. Serial data-transmission The Transmitter Holding Register (8-bits) Software outputs a byte of data to the THR The bits are immediately copied into an internal ‘shift’-register The bits are shifted out, one-at-a-time, in sync with a clock-pulse 0 1 1 0 0 0 0 1 0 1 1 0 0 0 0 1 1-0-1-1-0-0-0-0-1-0 data-bits The transmitter’s internal ‘shift’ register clock stop bit start bit clock-pulses trigger bit-shifts

  14. Serial data reception input voltage clock clock-pulses trigger voltage-sampling and bit-shifts at regular intervals The receiver’s internal ‘shift’ register 0 1 1 0 0 0 0 1 1-0-1-1-0-0-0-0-1-0 data-bits stop bit start bit Software can input the received byte from the RBR 0 1 1 0 0 0 0 1 The Receiver Buffer Register (8-bits)

  15. Normal 9-wire serial cable 1 Carrier Detect 1 6 6 Data Set Ready Rx data Request To Send Tx data Clear To Send Data Terminal Ready Ring Indicator 9 9 Signal Ground 5 5

  16. Signal functions • CD: Carrier Detect The modem asserts this signal to indicate that it successfully made its connection to a remote device • RI: Ring Indicator The modem asserts this signal to indicate that the phone is ringing at the other end of its connection • DSR: Data Set Ready Modem to PC • DTR: Data Terminal Ready PC to Modem

  17. Signal functions (continued) • RTS: Request To Send PC is ready for the modem to relay some received data • CLS: Clear To Send Modem is ready for the PC to begin transmitting some data

  18. 9-wire null-modem cable CD CD RxD RxD TxD TxD GND GND DSR DSR DTR DTR RTS RTS CTS CTS RI RI Data Terminal Equipment Data Terminal Equipment no modems

  19. The 16550 UART registers Base+0 Divisor Latch Register 16-bits (R/W) Base+0 Transmit Data Register 8-bits (Write-only) Base+0 Received Data Register 8-bits (Read-only) Base+1 Interrupt Enable Register 8-bits (Read/Write) Base+2 Interrupt Identification Register 8-bits (Read-only) Base+2 FIFO Control Register 8-bits (Write-only) Base+3 Line Control Register 8-bits (Read/Write) Base+4 Modem Control Register 8-bits (Read/Write) Base+5 Line Status Register 8-bits (Read-only) Base+6 Modem Status Register 8-bits (Read-only) Base+7 Scratch Pad Register 8-bits (Read/Write)

  20. Rate of data-transfer • The standard UART clock-frequency for PCs equals 1,843,200 cycles-per-second • Each data-bit consumes 16 clock-cycles • So the fastest serial bit-rate in PCs would be 1843200/16 = 115200 bits-per-second • With one ‘start’ bit and one ‘stop’ bit, ten bits are required for each ‘byte’ of data • Rate is too fast for ‘teletype’ terminals

  21. Divisor Latch • The ‘Divisor Latch’ may be used to slow down the UART’s rate of data-transfer • Clock-frequency gets divided by the value programmed in the ‘Divisor Latch’ register • Older terminals often were operated at a ‘baud rate’ of 300 bits-per-second (which translates into 30 characters-per-second) • So Divisor-Latch was set to 0x0180

  22. How timing works Transmitter clock (bit-rate times 16) DATA OUT start-bit data-bit 0 data-bit 1 … 24 clock-cycles 16 clock-cycles 16 clock-cycles sample sample Receiver clock (bit-rate times 16) receiver detects this high-to-low transition, so it waits 24 clock-cycles, then samples the data-line’s voltage every 16 clock-cycles afterward

  23. Programming interface The PC uses eight consecutive I/O-ports to access the UART’s registers 0x03F8 0x03F9 0x03FA 0x03FB 0x03FC 0s03FD 0x03FE 0x03FF RxD/TxD IER IIR/FCR LCR MCR LSR MSR SCR interrupt enable register line status register modem status register line control register modem control register receive buffer register and transmitter holding register (also Divisor Latch register) scratchpad register interrupt identification register and FIFO control register

  24. Modem Control Register 7 6 5 4 3 2 1 0 0 0 0 LOOP BACK OUT2 OUT1 RTS DTR Legend: DTR = Data Terminal Ready (1=yes, 0=no) RTS = Request To Send (1=yes, 0=no) OUT1 = not used (except in loopback mode) OUT2 = enables the UART to issue interrupts LOOPBACK-mode (1=enabled, 0=disabled)

  25. Modem Status Register 7 6 5 4 3 2 1 0 DCD RI DSR CTS delta DCD delta RI delta DSR delta CTS set if the corresponding bit has changed since the last time this register was read Legend: [---- loopback-mode ----] CTS = Clear To Send (1=yes, 0=no) [bit 0 in Modem Control] DSR = Data Set Ready (1=yes, 0=no) [bit 1 in Modem Control] RI = Ring Indicator (1=yes,0=no) [bit 2 in Modem Control] DCD = Data Carrier Detected (1=yes,0=no) [bit 3 in Modem Control]

  26. Line Status Register 7 6 5 4 3 2 1 0 Error in Rx FIFO Transmitter idle THR empty Break interrupt Framing error Parity error Overrun error Received Data Ready These status-bits indicate errors in the received data This status-bit indicates that the data-transmission has been completed This status-bit indicates that the Transmitter Holding Register is ready to accept a new data byte This status-bit indicates that a new byte of data has arrived (or, in FIFO-mode, that the receiver-FIFO has reached its threshold)

  27. Line Control Register 7 6 5 4 3 2 1 0 Divisor Latch access set break stick parity even parity select parity enable number of stop bits word length selection 00 = 5 bits 01 = 6 bits 10 = 7 bits 11 = 8 bits 0 = 1 stop bit 1 = 2 stop bits 0 = normal 1 = ‘break’ 0 = no parity bits 1 = one parity bit 0 = not accessible 1 = assessible 1 = even parity 0 = ‘odd’ parity

  28. Interrupt Enable Register 7 6 5 4 3 2 1 0 0 0 0 0 Modem Status change Rx Line Status change THR is empty Received data is available If enabled (by setting the bit to 1), the UART will generate an interrupt: (bit 3) whenever modem status changes (bit 2) whenever a receive-error is detected (bit 1) whenever the transmit-buffer is empty (bit 0) whenever the receive-buffer is nonempty Also, in FIFO mode, a ‘timeout’ interrupt will be generated if neither FIFO has been ‘serviced’ for at least four character-clock times

  29. FIFO Control Register 7 6 5 4 3 2 1 0 RCVR FIFO trigger-level reserved reserved DMA Mode select XMIT FIFO reset RCVR FIFO reset FIFO enable 00 = 1 byte 01 = 4 bytes 10 = 8 bytes 11 = 14 bytes NOTE: DMA is unsupported for the UART on our systems Writing 1 empties the FIFO, writing 0 has no effect Writing 0 will disable the UART’s FIFO-mode, writing 1 will enable FIFO-mode

  30. Interrupt Identification Register 7 6 5 4 3 2 1 0 0 0 ‘highest priority’ UART interrupt still pending 00 = FIFO-mode has not been enabled 11 = FIFO-mode is currently enabled highest 011 = receiver line-status 010 = received data ready 100 = character timeout 001 = Tx Holding Reg empty 000 = modem-status change lowest 1 = No UART interrupts are pending 0 = At least one UART interrupt is pending

  31. Responding to interrupts • You need to ‘clear’ a reported interrupt by taking some action -- depending on which condition was the cause of the interrupt: • Line-Status: read the Line Status Register • Rx Data Ready: read Receiver Data Register • Timeout: read from Receiver Data Register • THRE: read Interrupt Identification Register or write to Transmitter Data Register (or both) • Modem-Status: read Modem Status Register

  32. Usage flexibility • A UART can be programmed to operate in “polled” mode or in “interrupt-driven” mode • While “Polled Mode” is simple to program (as we shall show on the following slides), it does not make efficient use of the CPU in situations that require ‘multitasking’ (as the CPU is kept busy doing “polling” of the UART’s status instead of useful work

  33. How to transmit a byte Read the Line Status Register Transmit Holding Register is Empty? NO YES Write byte to the Transmitter Data Register DONE

  34. How to receive a byte Read the Line Status Register Received Data is Ready? NO YES Read byte from the Receiver Data Register DONE

  35. How to implement in C/C++ // declare the program’s variables and constants char inch, outch = ‘A’; // --------------------- Transmitting a byte ------------------- // wait until the Transmitter Holding Register is empty, // then output the byte to the Transmit Data Register do { } while ( (inb( LINE_STATUS) & 0x20) == 0 ); outb( outch, TRANSMIT_DATA_REGISTER ); // ---------------------- Receiving a byte ------------------------ // wait until the Received Data Ready bit becomes true, // then input a byte from the Received Data Register do { } while ( (inb( LINE_STATUS ) & 0x01 ) == 0 ); inch = inb( RECEIVED_DATA_REGISTER );

  36. How to initialize ‘loopback’ mode Set the Divisor Latch Access Bit in the Line Control Register Write a nonzero value to the Divisor Latch Register Clear the Divisor Latch Access Bit and specify the desired data-format in the Line Control Register Set the Loopback bit in the Modem Control Register DONE

  37. How to adjust the cpu’s IOPL • Linux provides a system-call to privileged programs which need to access I/O ports • The <sys/io.h> header-file prototypes it, and the ‘iopl()’ library-function invokes it • The kernel will modify the CPU’s current I/O Permission Level in cpu’s EFLAGS (if the program’s owner has ‘root’ privileges) • So you first execute our ‘iopl3’ command

  38. In-class experiments • For learning purposes, we can write user-programs that are able to execute ‘in’ and ‘out’ instructions, and so control the UART • But to avoid the CPU’s normal ‘segfaults’ we will have to acquire I/O privileges • The ‘iopl3’ command (created by our CS System Administrator Alex Fedosov) will establish the permissions which we need

  39. Experiment #1 • Download and run our ‘testuart.cpp’ demo • It uses the UART’s ‘loopback’ test mode to ‘receive’ each character that it ‘transmits’ UART ‘loopback’ mode TxShiftReg TxData RxShiftReg RxData Output loops back to become input The external signal-lines are bypased

  40. Experiment #2 • Download and run our ‘uartecho.cpp’ app (it does nothing untill you do the next step) • Modify the ‘testuart.cpp’ demo-program by commenting out the instruction that places the UART into ‘loopback’ mode • Execute those two programs on a pair of PCs that are connected by a null-modem

  41. Experiment #3 • Add a pair of counters to ‘testuart.cpp’: • Declare two integer variables (initialized to 0) int txwait = 0, rxwait = 0; • Increment these in the body of your do-loops do { ++txwait; } while ( /* Transmitter is busy */ ); do { ++rxwait; } while ( /* Receiver not ready */ ); • Display their totals at the demo’s conclusion printf( “txwait=%d rxwait=%d \n”, txwait, rxwait );

  42. Experiment #4 • Modify the ‘testuart.cpp’ demo-program to experiment with using a different baud rate and a different data-format • For example, use 300 baud and 7-N-2: • output 0x0180 to the Divisor Latch register • output 0x06 to the Line Control register • Then, to better observe the effect, add the statement ‘fflush( stdout );’ in the program loop immediately after ‘printf( “%c”, data);’

  43. Is your cable working? • We created a diagnostic program (called ‘trycable.cpp’) that you can use to check whether two PCs are properly connected with a working “null-modem” cable • You run ‘uartecho.cpp’ on one of the PCs and then execute ‘testcable.cpp’ on the adjacent PC – you will see a message on both screens if your cable is working OK
