  1. Selecting COTS Products Using a Requirements-Based Approach Jaelson Castro, Carina Alves Centro de Informática Universidade Federal de Pernambuco

  2. Motivations • Development of large and complex systems • Reusable components or COTS The potential benefits of using COTS are increased product reliability and stability, at shorter development time and reduced cost.

  3. What is COTS? • Commercial-Off-The-Shelf • There is no agreed definition • “ COTS are products: that are sold, leased or licensed to the general public; that is usually available without source code; that is supported and evolved by the vendor who returns the intellectual property rights ” Software Engineering Institute

  4. COTS-Based Development (CBD) • Large incentives from industry and academia • Improved productivity and quality of software development • Emphasizes the acquisition and integration of COTS components over in-house development

  5. Main Characteristics of CBD • The nature of COTS suggest new life cycle models • The success of COTS-based systems largely depends on the successful selection of software products

  6. Evaluation Adaptation Integration Update Selection ? ? ? COTS-based systems life cycle

  7. The Evaluation Process • Consists of determining the quality of a product in the context of its intended use • Decision making • Must accommodate uncertainty • Evaluation activities can span the entire lifetime of systems

  8. The Selection Process • Critical activity for COTS-Based systems • Oriented by evaluation criteria • COTS candidates must satisfy user requirements • Includes an accurate understanding of the features of each product

  9. The Adaptation Process • COTS are Plug and Pray • Development of all necessary software adapters and enhancements to the selected COTS • Component Wrapping – includes a software barrier around the components; limiting what it can do

  10. The Integration Process • Includes all development efforts required to interconnect different COTS into a single integrated system • Consists of developing additional parts not supported by available products • Conventional development efforts

  11. The Update Process • Like other systems, COTS-based systems need successive updates • Repair an error • New required functionality • Acquisition of new releases

  12. Current Problems with COTS-Based Development • Products from different vendors have to be integrated and tailored to provide complete system functionality • Customers have limited access to product´s internals design • COTS lifecycle is determined by vendor When using COTS products, customers are placed in a situation over which they have no control

  13. The impact of these problems can be minimized if adequate attention is paid to the process of COTS evaluation and selection

  14. The importance of the Selection Process • Includes the understanding of user requirements • Careful analysis of the capabilities and limitations of each COTS candidate • Assessment of products´ quality

  15. Main Dimensions of the Selection Process

  16. Selection Process Challenges • Lack of well defined process • Use of inappropriate evaluation criteria • Back-box nature of COTS components • Unclear system expectations • Rapid rate of changes of COTS This means that any evaluation will typically have some degree of error

  17. Related Works  Address fully * Deals with the issue but not fully – does not deal with the issue

  18. The lack of a careful consideration of non-functional requirements increases the risks of COTS failure and costs of the final system

  19. Our Contribution • An approach that addresses the lack of requirements engineering methods during COTS evaluation/selection • Focus on non-functional requirements analysis to assist the evaluation of COTS products

  20. The CRE Method • A systematic, repeatable and requirements-driven approach • Iterative process of requirements acquisition/ modeling and product evaluation/selection

  21. Number Increasing number and detail of requirements statements Decreasing number of candidate products Time CRE Iterative Process • The selection is made by rejection, products that do not meet user requirements are eliminated

  22. CRE Main Features • Goal oriented - each phase is oriented by predefined goals • CRE provides templates that include some guidelines • Interactive phases – The order is not rigid

  23. The CRE Templates

  24. The Phases • Identification – identify core requirements and candidates COTS products • Description – Describe each product and user requirements • Evaluation – Analyze products compliance with requirements • Acceptance – Verify legal issues

  25. User Requirements • Evaluation Criteria • Functional Requirements • Non-functional Requirements • Architecture Issues • Domain Issues • Vendor Guaranties • Market variables • Products Features • Legal Issues Application Architecture Metas Metas Project objectives and restrictions Goals Products availability Organization infrastructure Identification • Define selection goals, include analysis of influencing factors

  26. Identification • Evaluation criteria definition • Elicitation of critical requirements • Interviews and questionnaires techniques • COTS product searching • Possible sources: in-house libraries, Internet, magazines, conferences, vendors. • Final result - list with all COTS candidates

  27. Description • Evaluation criteria must be elaborated in detail • Non-functional requirements play an important role to discriminate between similar functional products (ex. flexibility, reliability, portability) • It is usually difficult to check if a product satisfies non-functional requirements • Use NFR Framework to refine these requirements

  28. Description • Feedback mechanism – information exchange between requirements process and products description

  29. Description • Requirements document is elaborated containing (all) relevant information about stakeholders needs

  30. Description • CRE method provides situation rules to deal with requirements conflict IF <condition> THEN <action> If Strong_Confl [Req1,Req2] and Req1_Prio > Req2_Prio Then Deal with Req1 Else If Strong_Confl [Req1,Req2] and Req2_Prio > Req1_Prio Then Deal with Req2

  31. Description • Checklist to help the elicitation of product information

  32. Evaluation • Use of appropriate techniques to assist decision-making process • WSM (Weighted Scoring Method) • Simple but results are not accurate • AHP (Analytic Hierarchy Process) • Complex use, provides more confidence in decisions

  33. Scorea = ( weight * scoreaj) n å j=1 WSM - Weighted Scoring Method Where a represents an alternative and n the number of criteria

  34. Select Product Goal Cost Vendor Guaranties Functionalities Usability Criteria Product A Product B Product C Alternatives AHP (Analytic Hierarchy Process)

  35. Evaluation • Perform product demonstration sessions to obtain detailed information about COTS features and limitations • Obtain products compliance score with evaluation criteria • Important step during decision-making process

  36. Evaluation • The cost of each COTS alternative extends the acquisition price • Apply cost estimation models • COCOTS proposed by B. Boehm • Provides a model to estimate the associated costs of COTS integration

  37. Acceptance • Negotiation of legal issues with COTS vendors • A license should minimally specify: • License grant • Payments to the supplier • Who owns the licensed product • The risks and liability each party assumes

  38. Main Contributions • An effective approach to guide the selection of COTS products • An iterative process of requirements acquisition and product evaluation • Including a detailed description of non-functional requirements • Support for decision-making analysis

  39. Future Work • Detailed treatment of requirements prioritization and negotiation • The interplay between software architecture and the selection of multiple COTS

  40. Non-Functional Requirements (NFR) • Address important issues of quality for software systems • Related to constraints on system services • Play critical importance during system development • Have a global impact on systems • Referred as “ilities”

  41. NFRs Main Features • Subjective • interpreted and evaluated differently by different people • Relative • importance may vary depending on the particular system • Interacting • Attempts to achieve one NFR can hurt or help the achievement of other

  42. Non-functional requirements can be difficult to deal with, yet dealing with NFRs can be vital for the success of a software system

  43. Non-Functional Requirements • There is not a unique definition or complete list of non-functional requirements • Different researchers use different terminology • Previous works • Bohem, 1976 • Roman, 1985 • Keller, 1990 • Standards ISO, ANSI, IEEE

  44. Usability requirements Delivery requirements Implementation requirements Standards requirements Types of Non-Functional Requirements [sommerville 92] Non-functional requirements Process requirements Product requirements External requirements Legal constraints Reliability requirements Economic constraints Safety requirements Interoperability requirements Efficiency requirements Performance requirements Capacity requirements

  45. The NFR Framework • Proposed by Chung, University of Toronto • Systematic and global representation of NFRs • Process-oriented approach • Qualitative approach • Represents NFRs explicitly as softgoals

  46. Main Characteristics • Softgoals - are the basic unit for representing non-functional requirements • Interdependencies - state interrelationships among softgoals • Methods - offer operationalization techniques • Correlations - provide catalogues for inferring possible interactions

  47. The notion of Softgoals • A goal that has no clear definition • Qualitative reasoning • Degrees of satisfaction • Interact in synergy or conflict • Decomposed through AND or OR relationship • AND - the softgoal is satisfied if all of its sub-goals are • OR - the softgoal is satisfied if any of its sub-goals are

  48. NFR Framework can be used to • Acquire knowledge about: • the particular domain • functional requirements • particular kinds of NFRs • Identify particular NFRs for the domain • Decompose NFRs • Identify operationalizations (satisfice)

  49. Using the NFR Framework (cont.) • To deal with: • ambiguities • tradeoffs and priorities • interdependencies among NFRs • Select operationalizations • Support decisions (design rationale) • Evaluate the impact of decisions

  50. Catalogues • Present knowledge about NFRs • Sources of knowledge: specialists, developers, textbooks, developer guides, etc. • Provide a broad range of expertise • Types of catalogues: • NFR types (organize NFRs into specialized hierarchies) • method (refine NFRs considering operationalizations) • correlation (show implicit interdependencies)
