  1. CMP Presentation Stephen Farrell Baltimore Technologies

  2. Outline • Provide historical perspective • Highlight major features of the protocol • Provide a status update and expected future direction • Thanks to: • Steve Lloyd and Carlisle Adams who prepared the initial version of these slides

  3. Historical Perspective • Discussed within IETF PKIX working group since early 1996 • RFC 2510 (March 1999), update in draft stage • Editors: • Carlisle Adams (Entrust Technologies) • Stephen Farrell (Baltimore Technologies) • Reflects all aspects of comprehensive certificate/key life cycle management • Based on earlier experience with EU SESAME Project and Nortel’s (later Entrust’s) SEP • Major CMC/CMP kefuffle -> CRMF (RFC2511)

  4. Certificate/Key Life Cycle Management • Key pair generation • Certificate creation • Key pair distribution to end-entity as required • Encryption/decryption key pair backup • Encryption/decryption key pair recovery • Key update/renewal • Certificate revocation • Certificate and revocation information retrieval • Cross-certification • CA Key rollover • Certificate/key archival

  5. Noteworthy Features/Options • Accommodates multiple PKI-component variations (i.e., CA-CA, CA-RA, EE-CA, EE-RA, even EE-RA-RA-CA!) • Supports both hierarchical and networked trust models • Supports explicit POP when signing keys not available • Supports secure, in-band installation of PKI trust anchor • Supports generic message structure to convey additional operational aspects/information • Supports two-way, three-way and four-way protocol exchanges • RFC2511 (CRMF) common to CMC & CMP

  6. What about Interoperability? • As with any feature rich, flexible protocol, functional subsets are expected to be defined • Minimum interoperability profiles already specified (CMP Appendix B) • CA-TALK list (ICSA driven interop) has been working through this set of operations • Now a PKI Forum activity • Other profiles expected to be defined based on target domain requirements

  7. CMP 2000 (Version 2) • draft-ietf-pkix-rfc2510bis-00.txt • Nearing completion (“speak now or…”) • Main differences from RFC2510: • text is clarified based on experience with CMP interoperability trials and mail list feedback • confirmation for selected certificates added • additional acknowledgement message from CA to EE has been added to trigger EE operation (when req’d) • transport-specific issues removed (due to re-use elsewhere, e.g. TSP, LAAP,…) • POP simplified

  8. Conclusions • A widening range of PKI vendors are now involved with implementations • CMP supports all facets of comprehensive certificate/key life cycle management • CMP offers maximum flexibility to accommodate different requirements • Transport aspects being re-used elsewhere • Subsets of CMP can be implemented as required (e.g. TSP use of transports/headers)

  9. www.PKIForum.org
