Calculation of slope angles

Calculation of slope angles. The 2008 Level 3 S pecification for Skills says: Candidates will be required to calculate slope angle from a topographic map and provide an answer in degrees and percent. Slope angles can be expressed as:. An angle in degrees ° A percentage %.

liuz
Télécharger la présentation

Calculation of slope angles

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Calculation of slope angles The 2008 Level 3 Specification for Skills says: Candidates will be required to calculate slope angle from a topographic map and provide an answer in degrees and percent.

  2. Slope angles can be expressed as: An angle in degrees ° A percentage % • Learning how to calculate slope angle (gradient) as a degree and as a percentage before going into the 2008 exam would be wise.........also make sure you have a scientific calculator.

  3. Slope angles as degrees Two pieces of information are needed to work out degrees: The HORIZONTAL DISTANCE between two points on a map (expressed in metres) The DIFFERENCE IN HEIGHT between the lowest point and the highest point (expressed in metres) Note: • The horizontal distance and height need to be expressed in the same • unit of measurement • The slope angle will be an average over the distance, it will not take into • consideration valleys or peaks across that distance • Working out slope in degrees is simple by following five easy steps

  4. Step 2: Calculate the difference in height between the two points Step 3: Calculate the distance between the two points Step 1: Find the two points to calculate slope between 100m 200m 300m 325m B 325m – 100m = 225m 250m A to B is 3cm on the map. This is 1.5km but must be converted to same unit of measurement as height so it becomes 1500m 150m A Scale: 1:50 000 (1cm = 500m)

  5. Step 4: Apply the formula Slope = • difference in height (m) • horizontal distance (m) • 225m • 1500m • = 0.15 (gives a decimal answer) • Slope = Step 5: Work out the inverse tangent (by pushing shift Tan ¯¹ on your scientific calculator) to get the degrees • = 0.15 • =Tan¯¹ 0.15 • = 8.5° (1dp) • 8.5° degrees is the angle of slope

  6. Slope angles as a percentage Simply go back to the decimal answer (step 4) and convert to a percentage... o.15 x 100 = 15% The slope angle as a percentage is 15% So that is a gradient of 8.5° as a degree or a gradient of 15% as a percentage

  7. Acknowledgements • http://www.nzgs.co.nz/Resources.aspx#map accessed 9/6/08 • H. McMillan - Saint Kentigern College • Martin Newton • Nick Page - Otumoetai College
