  1. FATS

  2. CONTENTS • INTRODUCTION • PHYSICAL PROPERTIES • ACID VALUE • IDENTIFICATION & QUANTIFICATION OF FA’S • SEPERATION OF FATTY ACIDS • SAPONIFICATION VALUE • ESTER VALUE • IODINE VALUE • PEROXIDE VALUE • ESTIMATION OF OILS • ACETYL VALUE • HYDROXYL VALUE

  3. FATS These compounds are so named because the first isolated member was from fat. The general formula is R-COOH, R being an alkyl group with a short or long chain.

  4. FATTY ACIDS • The general chemical structure of fatty acid is CH3(CH2)n.COOH,where n has a value ranging from 0 to 20. • By virtue of being carboxylic acid, fatty acids are capable of forming salts with inorganic bases like NaOH or KOH,MG(OH)2… • The mineral salt of fatty acid is called a soap.

  5. TRIGLYCERIDES • Fatty acids can form esters with alcoholic hydroxyl also • Those esters are called mono glycerides, di glycerides, depending on the no. of –OH groups that are esterified to fatty acids. • As there are no polar groups triglycerides are called as the neutral fats.

  6. PHYSICAL PROPERTIES • They are colorless, odorless, tasteless substances than water in which they are insoluble but soluble in organic solvents. • The melting point of fats are higher than their solidification points.

  7. ACID VALUE / ACID NUMBER The number of mg. of KOH required to neutralize the free acids present naturally in 1g. of neutral fat, is called as acid number. This indicates the degree of purity of fat, which is purer with lower values of this number.

  8. ESTIMATION OF FREE FATTY ACIDS PRINCIPLE: • The free fatty acid in an oil is estimated by titrating it against KOH in the presence of phenolphalein indicator. • The acid number is defined as the mg of KOH required to neutralize the fatty acids present in 1g. of sample. • However the free fatty acid content is expressed as oleic acid equivalents.

  9. MATERIALS: • 1% phenolphalein in 95% ethanol • 0.1N KOH • Neutral solvent. PROCEDURE: 1 to 10g of oil in 50ml.the neutral solvent in 250ml conical flask ↓ 2drops indicator added ↓ Titrate against 0.1N KOH ↓ Shake constantly until pink color persists for 15 sec.

  10. CALCULATION: Acid value (mg KOH/g) = titer value× N of KOH×56.1 wt. of sample (g) The free fatty acid is calculated as oleic acid using the eq. 1ml. N/10 KOH =0.028g oleic acid

  11. IDENTIFICATION & QUANTIFICATION OF FATTY ACIDS PRINCIPLE: • FA are made volatile by converting them into methyl esters. The conversion of FA’s in methyl esters is carried out directly by trans esterification. • The esters are identification & quantified by injecting into GLC & comparing with a set of std esters.

  12. MATERIALS: • 10% BCl3 or 14% BF3 in methanol • Saturated NaCl solution • Na2SO4(anh) • Hexane • N2 gas • GLC • Column- pre tested 10% silar 10ºc on GC with 100 to 200 mesh. • Detector – FID • Injector temp. -280ºc

  13. Detector temp. -250ºc • Carrier gas –N2 at 50ml/min • Column/oven temp. -165ºc PROCEDURE: 150 to 300mg oil ↓ 3ml of 10% BCl3 added + boiling chips & heat at 83ºc for 6 min ↓ Transfer the contents to seperatory flask & collect the washings which is done 4 times with 1ml portions of hexane. ↓

  14. Shake & allow to separate ↓ 4ml sat. NaCl solution added ↓ Shake & collect hexane layer over anh.Na2SO4 ↓ Rinse funnel with 2ml hexane& collect the hexane layer ↓ Filter the hexane extract ↓ Reduce the vol. to 2-3ml by drying with N2 gas steam ↓

  15. Inject an aliquot to pre conditioned GLC ↓ Inject std methyl esters separately & calculate the retention time. CALCULATION: By identifying the peaks in their relative positions, Esters appear in order of increasing no. of C- atoms & of increasing unsaturation for the same no. of C- atoms

  16. DETERMINATION OF THE ACID VALUE OF A FAT PRINCIPLE: • During storage, fats may become rancid as a result of peroxide formation at the double bonds by atm. O2 & hydrolysis by micro organisms with the liberation of free acids. • The amt of free acid gives an indication of the age & quality of the fat.

  17. MATERIALS: • Olive oil, butter& margarine - 200g • Fat solvent - 6Lt • Phenolphthalein - 200ml • KOH - 1Lt • Burettes - 50 METHOD: 10g of test comp. weighed ↓ Melted fat suspended in 50ml of fat solvent ↓

  18. 1ml phenolphthalein ↓ Mix thoroughly ↓ Titrate with 0.1 mol./lit. KOH ↓ Faint pink color persists for 20-30 sec • Note the no. of ml. of std alkali required & calculate the acid value of fat.

  19. SEPERATION OF FATTY ACIDS BY REVERSE PHASE PAPER CHROMATOGRAPHY • In this method, the S.P is the organic solvent adsorbed to an inactive supporting material. • The M.P immiscible with the first is aq. • Whatmaan no.1 & 3 filter paper of size 20×20cm is dipped in the 10% liq. paraffin in pet. Ether.

  20. The std FA’s samples are applied to the paper in the followed manner: • Saturated FA’s (2-5µg each): lauric acid, myristic acid, palmatic acid, stearic acid. • Unsaturated FA’s (1-3µg each): linolenic acid, oleic acid. • Develop the papers in the chromatographic chambers saturated with the solvents like acetone-water 80:20 or acetic acid-acetonitrile 1:1v/v saturated with liq.paraffin in pet. Ether. • After development the papers are hanged to room temp. for detecting the spots with phosphomolybdic acid reagent. • Heat in hot air oven at 120ºc for 10-15 min. by identifying the FA content of sample.

  21. SAPONIFICATION VALUE PRINCIPLE: • The saponification value is the no. of mg. of KOH required to neutralize the FA’s resulting from the complete hydrolysis of 1g. Of fat. • The saponification value gives an indication of the nature of the FA’s in the fat since longer the C-chains the less acid is liberated per gram of fat hydrolyzed.

  22. MATERIALS: • Fats – 20g • Fat solvent(95% ethanol ,ether) – 1Lt • Alcoholic KOH – 3Lt • Reflux condenser - 100 • Boiling water bath - 100 • Phenolphthalein – 50ml • HCl – 3Lt • Burettes – 100 • Conical flasks - 100

  23. METHOD: 1g of fat weighed in tarred beaker ↓ Dissolve in 3ml.of fat solvent ↓ Contents transferred to 250ml conical flasks ↓ Rinsing beaker with further ml of solvent 3 times ↓ 25ml.of 0.5mol/Lt alc. KOH added ↓

  24. Attached to reflux condenser ↓ Attach another reflux condenser as blank ↓ Heat on boiling water bath for 30min. ↓ Leave to room temp. ↓ Titrate with 0.5mol/Lt HCl ↓ Phenolphthalein indicator was added

  25. CALCULATION: Saponification value (s) = 3×56×1000 avg.mol wt.of fat Avg mol wt. of fat = 3× 56×1000 s

  26. DETERMINATION OF ESTER VALUE PRINCIPLE: • The ester value is the no. of mg. of KOH required to saponify the esters present in 1g. Of the substance. • Ester value = saponification value-acid value.

  27. THE IODINE NUMBER OF A FAT PRINCIPLE: • The number of grams of iodine absorbed by 100g of fat by virtue of its unsaturation is termed as iodine value. • Higher the iodine value, greater is the proportion of unsaturated FA’s in fat. • Halogens add across the double bonds of unsaturated FA’s to form additional compounds.

  28. MATERIALS: • Fats – 1Lt • Iodine chloride –(0.2mol/Lt) – 3Lt • KI(100g/Lt) – 1.5Lt • Sod.thio sulfate(0.1g/Lt) – 4Lt • Starch indicator(10g/Lt) -250ml • Stoppered bottles(250ml) – 200 • Burettes (25ml) – 100 • Chloroform – 1Lt

  29. METHOD: Pipette out 10ml of fat solution ↓ 25ml of iodine chloride solution added ↓ Leave to stand in dark for 1hr. Shaking thoroughly ↓ Rinse the stoppers, necks with 50ml water ↓ 10ml.KI solution added ↓

  30. When the solution is pale straw color add 1ml. Of starch solution until blue color disappears ↓ Bottles must be shaken thoroughly to ensure that all iodine is removed from chloroform layer. CALCULATION: Iodine number = (B-T) × 6.35g per 100g of fat

  31. SIGNIFICANCE: • The iodine value is a measure of the unsaturation of an oil. The higher the iodine value the more double bonds are present, which consequently reflects the reactivity of the oil.

  32. DETERMINATION OF PEROXIDE VALUE PRINCIPLE: • Peroxide value is a measure of peroxides contained in the oil. • The peroxides present are determined by the titration against thio sulfate in the presence of KI. • Starch is used as indicator.

  33. MATERIALS: • Solvent mixture – mix 2 vol. of glacial acetic acid with 1 vol. of chloroform • 5% KI solution • 1% starch solution • N/500 sod. Thio sulfate solution

  34. PROCEDURE: 1g of oil/fat are weighed in dry boiling tube ↓ 1g of powdered KI & 20ml of solvent mixture ↓ Place the tube in boiling water for 30sec. ↓ Transfer the contents to conical flask containing 20ml of 5% KI solution ↓ Wash the tube with 25ml water twice ↓

  35. Titrate against N/500 sod. Thio sulfate solution until yellow color disappears ↓ 0.5ml starch added ↓ Shake vigorously till blue color just disappears. CALCULATION: Peroxide value = S × N × 1000 sample (g)

  36. ESTIMATION OF OIL IN OIL SEEDS PRINCIPLE: • Oil from known quantity of the seed is extracted with pet. Ether. • It is then distilled off completely & dried. MATERIALS: • Pet. Ether(40-160°c) • Whatmaan no.2 filter paper • Absorbent cotton • Soxhlet apparatus.

  37. PROCEDURE: Fold a piece of filter paper in such a way hold the seed meal. ↓ Cotton wool is placed at the top to distribute evenly ↓ Place the sample packet in butt tubes of soxhlet apparatus ↓ Extract with pet. Ether for 6hrs without heating ↓ Cool & dismantle the apparatus ↓

  38. Evaporate the ether on steam or water bath until no odour remains ↓ Cool to room temp. ↓ Carefully remove the dirt outside the flask & weigh ↓ Repeat heating until constant wt. is obtained.

  39. CALCULATION: Oil in ground sample % = wt. of oil (g) ×100 wt. of sample (g) Oil in dry wt. basis = % oil in ground sample 100% moisture in whole seed.

  40. DETERMINATION OF ACETYL VALUE PRINCIPLE: • The acetyl value is the no. which express in mg the amount of KOH required to neutralize the acetic acid liberated by the hydrolysis of 1g of the acetylated substance. METHOD: 10g with 20ml acetic anhydride in 200ml RB flask ↓ Support the flask on sheet of heat resistant material with diameter of 4cm ↓ Boil gently for 2 hrs & cool ↓

  41. Pour the contents into 600ml water containing beaker ↓ 0.2g of pumice powder added ↓ Boil for 30min & cool ↓ Transfer to a separator & discard the lower layer ↓ Wash the acetylated product with each 50ml of warmed sat. solution of NaCl. ↓ Shake with 20ml warm water ↓

  42. Remove the aq. Layer completely ↓ Pour the acetylated sub. into small dish ↓ 1g of powdered anh. Sod. Sulfate added ↓ Stir thoroughly & filter. CALCULATION: Acetyl value = 1335 (b-a) / (1335-a)

  43. DETERMINATION OF HYDROXYL VALUE PRINCIPLE: • The hydroxyl value is the no. of mg of KOH required to neutralize the acid combined by acetylation in 1g of the substance. METHOD: Accurately weigh the substance in 150ml acetylation flask ↓ Pyridine acetic anhydride reagent added ↓

  44. Boil for 1hr on water bath & maintain it to 3cm above the level of liquid in flask ↓ 5ml water added from top of the condenser ↓ If cloudiness is observed add pyridine to produce clear liquid ↓ Shake & replace the flask for 10min & cool ↓ Rinse the walls & condenser with 5ml ethanol ↓ Titrate with 0.5M ethanolic KOH using dilute phenolphthalein as indicator.

  45. CALCULATION: Hydroxyl value = acid value + 28.05 v/w V = difference in ml during titration W = wt. in grams of substance.

  46. ESTIMATION OF VOLATILE ACIDS PRINCIPLE: • Steam distillation after acidifying the sample with 1+1 H2SO4 results in the evaporation of volatile acids which on condensation yield liquefied volatile acids. • These acids could be titrated against 0.1N alkali with phenolphthalein indicator to find out the amount of volatile FA’s.

  47. MATERIALS: • Dilute H2SO4 1+1 – mix 1 vol. of conc. H2SO4 with 1 vol. of water. • Ferric chloride solution – dissolve 82.5g FeCl3.6H2O in 1Lt dist. Water • Diatomaceous silica filter aid • Magnesium sulfate • Std NaOH, titrant 0.1N – dissolve 4g NaOH in 1Lt distilled water & std against any std acid • Phenolphthalein indicator.
