  1. Checkers Cheaters Moti Berger & EliranMoyal

  2. Goals • Detection of the board and the pieces (blacks and whites). • Display of an optimal move using animated arrows according to a non-trivial heuristic.

  3. Board Detection Apply Filter 30X30 Max Points Find Diagonal Closest Compute Distance and Homography Find OuterPoints

  4. HOUGH CIRCLES TRANSFORM With specific radius : 0.3*tile 0.4*tile With very low threshold in canny and center detection – find BLACK ON BLACK Circles Detection

  5. UI Click anywhere to take picture Arrow(s) with best move will appear. Press green button to take another picture

  6. Supports Kings Click On "Place kings" and then on kings, Message will appear. Press Solve to get best move with king

  7. MiniMax with • Suggested move is achieved by MiniMax search algorithm with pruning for optimization. • Board’s stateevaluation process involves a weighted set of heuristics.

  8. Algorithm’s limitations • Taking a picture from a wide angle (having difficulty to detect circles). • Taking a picture from one of the board’s corners (having difficulty to detect farthest points).
