Presentation Transcript

  1. Pressure 12/09/2011

  2. The definition of pressure • PRESSURE is the amount of FORCE acting per unit AREA • The formula for pressure is • Pressure = Force Area

  3. Help with Calculations F P X A

  4. Examples of pressure in everyday life • Tyres • Weather • Hydraulics • Blood pressure • Power hose

  5. Breaking System • A relatively small force is applied to the piston on the left say 100N. This puts pressure on the oil • The pressure of the oil causes a force of 5000N to act on the piston on the right. • Because pressure = Force and 100N Area 10cm2 • is the same as 5000N 500cm2
