1. Breaking the MapReduce Stage Barrier Abhishek Verma, Nicolas Zea, Brian Cho, Indranil Gupta and Roy Campbell Department of Computer Science, University of Illinois at Urbana-Champaign

2. MapReduce • MapReduce introduced by Google [OSDI 04] • Programming model • Map and reduce primitives borrowed from functional languages • Map applies the same computation identically on partitioned data and reduce aggregates map outputs • Clustered computing system • Automatic parallelization & job distribution • Fault-tolerance via job re-execution • Provides status and monitoring tools IEEE Cluster 2010

3. Who is using MapReduce/Hadoop? IEEE Cluster 2010

4. MapReduce Model <be, 1>, <be, 1> <be, 2> <to, 1>, <be, 1>, <or, 1>, <not, 1>, <to, 1>, <be, 1> <in, 1> <in, 1>, <is, 1> To be, or not to be: <is, 1> <mind, 1> <nobler, 1> <not, 1> <or, 1> <question, 1> <suffer, 1> <or, 1>, <not, 1>, To be, or not to be: that is the question: Whether 'tis nobler in the mind to suffer <mind, 1> <nobler, 1> <not, 1> <or, 1> <question, 1> <suffer, 1> <that, 1>, <is, 1>, <the, 1>, <question, 1> <mind, 1> <suffer, 1> that is the question: <nobler, 1>, <question,1>, <whether, 1>, <tis, 1>, <nobler, 1>, <in, 1> Whether 'tis nobler in <to, 1>, <to,1>, <that, 1>, <the, 1>, <the, 1>, <tis, 1>, <to, 1>, <to, 1>, <to, 1>, <to, 1> <whether, 1> <that, 1>, <the, 2>, <tis, 1>, <to, 4>, <whether, 1> <the, 1> <to, 1> <the, 1>, <mind,1>, <to, 1>, <suffer, 1> <whether, 1> <tis, 1> the mind to suffer <that, 1>, <the, 1> IEEE Cluster 2010

5. Motivation • Barrier between Map and Reduce stages • Reduce stage does not start till all the map tasks have completed • Why is the barrier present? • Grouping of values by keys done through sorting • Simplifies re-execution of failed tasks • Is this barrier necessary? • Which applications benefit if we remove this barrier? IEEE Cluster 2010

6. Outline • Motivation • Breaking the barrier • Classify reduce operations • Memory management • Evaluation • Conclusion IEEE Cluster 2010

7. Original Wordcount function map (key, value): // key: document name // value: document contents for each word in value do Emit intermediate (word, 1) end for function reduce (key, values): // key: a word // values: a list of counts result ←0 for each val in values do result ← result + val end for Write (key, result) as output function run( ): • while there more keys do • key ← current key • values ← current values • reduce (key, values) • end while IEEE Cluster 2010

8. Barrier-less Wordcount function map (key, value): // key: document name // value: document contents for each word in value do Emit intermediate (word, 1) end for function reduce (key, values): // key: a word // values: a list of counts Fetch result from Treemap for eachval invalues do result ← result + val end for Update (key, result) in TreeMap function run( ): • Create a new TreeMap • while there are more keys do • key ← current key • values ← current values • if TreeMap does not contain key then • Insert (key, 0) in the TreeMap end if • reduce (key, values) • end while • // After all reduce invocations are done • for each(key, value) in TreeMap do • Write (key, value) as output • end for IEEE Cluster 2010

9. Barrier-less MapReduce <be, 1>, <be, 1> <be, 2> <to, 1>, <be, 1>, <or, 1>, <not, 1>, <to, 1>, <be, 1> To be, or not to be: To be, or not to be: that is the question: Whether 'tis nobler in the mind to suffer that is the question: <or, 1>, <not, 1>, <not, 1> <or, 1> Whether 'tis nobler in <to, 1>, <to,1>, <to, 2> the mind to suffer IEEE Cluster 2010

10. Barrier-less MapReduce <be, 2> <to, 1>, <be, 1>, <or, 1>, <not, 1>, <to, 1>, <be, 1> To be, or not to be: that is the question: <mind, 1> <not, 1> <or, 1> <suffer, 1> <mind, 1> <suffer, 1> <not, 1> <or, 1> Whether 'tis nobler in <the, 1> <to, 1> <the, 1>, <mind,1>, <to, 1>, <suffer, 1> <the, 1> <to, 3> <to, 2> the mind to suffer IEEE Cluster 2010

11. Barrier-less MapReduce <be, 2> <to, 1>, <be, 1>, <or, 1>, <not, 1>, <to, 1>, <be, 1> To be, or not to be: <in, 1> <in, 1> that is the question: <mind, 1> <nobler, 1> <not, 1> <or, 1> <suffer, 1> <mind, 1> <not, 1> <or, 1> <suffer, 1> <nobler, 1>, <whether, 1>, <tis, 1>, <nobler, 1>, <in, 1> Whether 'tis nobler in <the, 1>, <tis, 1>, <to, 3>, <whether, 1> <whether, 1> <tis, 1> <the, 1>, <mind,1>, <to, 1>, <suffer, 1> <the, 1> <to, 3> the mind to suffer IEEE Cluster 2010

12. Barrier-less MapReduce <be, 2> <to, 1>, <be, 1>, <or, 1>, <not, 1>, <to, 1>, <be, 1> To be, or not to be: <in, 1>, <is, 1> <is, 1> <in, 1> <that, 1>, <is, 1>, <the, 1>, <question, 1> that is the question: <mind, 1> <nobler, 1> <not, 1> <or, 1> <suffer, 1> <mind, 1> <nobler, 1> <not, 1>, <or, 1> <question, 1> <suffer, 1> <question,1> <whether, 1>, <tis, 1>, <nobler, 1>, <in, 1> Whether 'tis nobler in <that, 1> <the, 2>, <tis, 1>,<to, 3>, <whether, 1> <the, 1>, <tis, 1>, <to, 3>, <whether, 1> <the, 1>, <mind,1>, <to, 1>, <suffer, 1> <that, 1>, <the, 1> the mind to suffer IEEE Cluster 2010

13. MapReduce Timeline IEEE Cluster 2010

14. Implementation • Modified Hadoop 0.20 • Bypass the sorting mechanism • Modify reduce invocation so it can be called with a single record • Shared buffer producer consumer • first thread shuffles intermediate data • other thread applies reduce function on shuffled data • Configurable boolean flag • conf.setBarrier(true/false) IEEE Cluster 2010

15. Classifying Reduce Operations • Post-reduction processing • Single reducer aggregation • Sorting • Selection • Aggregation • Identity • Cross-key operations IEEE Cluster 2010

16. Classifying Reduce Operations • Post-reduction processing • Single reducer aggregation • Sorting • Selection • Aggregation • Identity • Cross-key operations IEEE Cluster 2010

17. Post Reduction Processing • Two step process • Entries are processed and inserted in temp structure • Post-processing operation applied finally • E.g.: Last.fm tracks the number of unique users listening to a particular music track • Default implementation • Group users by track by emitting <TrackId, UserID> • Finally find the number of unique users • Barrier-less implementation • Maintain a set for each TrackId with the UserIDs IEEE Cluster 2010

18. Single Reducer Aggregation • Use single reducer to aggregate output from multiple map tasks • E.g.: Computing Black-Scholes option pricing • Map computes exponentiations • Single reduce computes mean and std dev • Barrier-less implementation • Reducer keeps running sum and sum of squares IEEE Cluster 2010

19. Sorting • One of the few applications which requires sorted keys • TeraSort and other sorting benchmarks • Use identity map and identity reduce function • Framework does the sorting in the shuffle phase • Barrier-less: Use Red-Black tree • Maintain O(records) state IEEE Cluster 2010

20. Memory Management Techniques • Intermediate results can grow up to O(records) • overflow memory capacity • Techniques to manage memory • Disk-spill and merge • When memory usage reaches a threshold, spill the results to disk • Merge partial results together in the end • Disk-spilling key/value store • Every reduce invocation fetches previous partial result, processes it and stores it back • Key/value store can evict records according to LRU IEEE Cluster 2010

21. Evaluation • Experimental Setup • 16 nodes of OpenCirrus Cloud • 8 cores, 16GB RAM, 2 TB hard disk • One node as job and DFS master + 15 slaves • Number of map and reduce tasks per node = 4 • Does the job completion time decrease after removing barrier? • How much programmer effort is required? • How well do our memory management techniques work? IEEE Cluster 2010

22. Application Speedups IEEE Cluster 2010

23. Memory management techniques IEEE Cluster 2010

24. Memory management IEEE Cluster 2010

25. Conclusion • General purpose MapReduce frameworks without barrier can result in significant benefits • Experiments demonstrate an average speedup of 25% • Preserves fault tolerance and ease of programming • Questions? • verma7@illinois.edu IEEE Cluster 2010
