  1. Controlsystem GPT 2000 suited for Hotmix 20, RC-receptgenerator, cement-and fibregranulatedosing. All statisicswill be saved.

  2. GPT 2000 Bildskärm 2

  3. Cold feed system withbeltfeeders and collectingconveyer as a trailer.

  4. Kingpinat the coldfeed system

  5. Inclinedconveyerto the drum

  6. Crudegasduct from drumto filter

  7. Ameco-filter withexhaust fan and exhaust stack

  8. Electric controlcabinet

  9. Fillerscrews, Filler weighhopper (loadcellweighing)

  10. Reclaimed and imported fillersilo Bothcan be used for reclaimed filler

  11. Reclaimed and imported fillerscrews

  12. Dryerdrum, burner and screen at the outside the dryerdrum 4 fractionsincluding Bypass

  13. Undercarrige for the dryerdrum trailer Overflowtube Undercarrige for mineral- and fillerweighhopper, mineralelevator and mixer.

  14. Mineral weighhopper and mineral elevator to mixer

  15. Vit text Cementsilo (BH)

  16. Recyklinghopperwithoversizegrid (BH)

  17. RC-hopperwithbeltconveyer Beltweighing system

  18. Cementsilo, RC-conveyers , RC-hopper

  19. Fibregranulatefeed system

  20. Bitumenpump o bitumen weighscale.

  21. Bitumen weighhopper, Fibregranulatinlet, Recyklinginlet in mixer. Filler weighscale and inletof from cement silo

  22. Mineral weighhopper, fillerscrew, elevator, mixer and skip.

  23. Vit text Skip and skiptrack

  24. Mixed material silos, trailer 3 times 35 ton

  25. Mixed material silos, skip

  26. Readymix silos

  27. Bitumentank no. 4 Electricallyheated

  28. Bitumentank no.1 and 2, Fueloilheated

  29. Bitumentank no.3 electricallyheated

  30. Control cabin on topof a workshop container
