  1. Case Study: Using PVS to Analyze Security Protocols Kyle Taylor

  2. Overview • Using PVS: • Specify Communication • Specify Encryption • Specify Intruder • Specify Protocol • Analyze Results

  3. What is PVS • General • Prototype Verification System • Inductive Theorem Prover • Augments classical higher-order logic with an advanced type system • Implemented in Common Lisp • Based upon 20 years of experience • Emacs Interface

  4. What is PVS Cont. • Intended for the formalization of requirements and high level design • Functional Specification Language • Haskell, Lisp, ML • PVS consists of • Specification language • Predefined theories • Proof Checker

  5. PVS Specification Language • Type checking is undecidable because of constrained types • Generates proof obligations for the theorem prover • Assumptions • Definitions • Axioms • Conjectures • Theorems • Lemmas

  6. PVS Proof Checker • Provides a collection of powerful primitive inference procedures • Propositional and quantified rules • Induction • Rewriting • Decision procedures for linear arithmatic • Requires Interactive proving • Contains automated proof strategies

  7. PVS and Security • PVS does not have built in security or communication primitives • The primitives need to be defined when a specification is developed • Luckily the definitions of the security primitives can be reused

  8. Communication and Encryption • Messages are defined as a function • Said(Sender: P, Receiver: P, Fields: F) • Fields are constructed by type coercion • Agent(Principle: P): F • Num(num: nat): F • Pkey(pkey: K): F • Con(field: F, field: F): F • Ped(pkey: K, field: F): F

  9. Communication and Encryption Cont • Encryption • Pub(principle: P): K • Priv(principle: P): K • Invkey(key: K): K • Axiom • Invkey(pub(A))=priv(A)

  10. Specifying Security • Parts(S) • All sub fields of a set S • Analz(S) • All sub fields of a set S that is accessible to an attacker • Synth(S) • The set of fields that is constructible for S • Secret() • Basic secrets • Initial() • Initial attacker knowledge

  11. Specifying a Protocol • Each protocol step is a function • The function accepts a Message and a Trace • The function returns a bool • The function constrains the Message and the Trace

  12. Specifying an Intruder • Done with a function • The function accepts a Message, a Trace, and a set of initial knowledge • The function returns a bool • Constructs messages from a set of initial knowledge and the set of derivable knowledge present in a trace • Constructed message is from the intruder

  13. ffgg Protocol • AB: A • BA: B, N1, N2 • AB: A, {N1, N2, M}PKB % {N1, X, Y}PKB • BA: N1, X, {X, Y, N1}PKB

  14. Ffgg Attack • AB: A • (A)B’: A % masquerade • B(A): N1, N2 • B’(A): N’1, N’2 • (B)A: N1, N’1 • AB: {N1, N’1, M}PKB • B(A):N1, N’1, {N’1, M, N1}PKB • (A)B’: {N’1, M, N1}PKB • B’(A): N’1, M, {M, N1, N’1}PKB

  15. ffgg Specification a1(E,H): bool= EXISTS (A, B): A /= B AND E = Said(A, B, Con(Num(1), Agent(A)))

  16. ffgg Specification Cont ffgg(Q: trace): RECURSIVE bool= CASES Q OF cons(E, H): ffgg(H) AND (Fake(E, H, initial) OR a1(E, H) OR b2(E, H) OR a3(E, H) OR b4(E, H)), null: TRUE ENDCASES MEASURE length

  17. ffgg Results • PVS derived a case enumerating a trace of the attack that the user would have to prove

  18. Discussion • Lessons Learned • Learning PVS is not trivial • Specification and prover are not intuitive • Theorem proving has the ability to be very useful • Security is tricky • Limitations • Amount of background required of the user • Amount of training time required • Ambiguity of specification

  19. Future Work • Develop a theorem prover that is specifically designed for Security protocols (Athena?) • Provide a less powerful specification language to increase simplicity • Provide better separation of modules

  20. Conclusion • 6 month estimate to learn PVS is very optimistic • One on one training with a PVS guru is a must • Limited use due to ambiguity of specifications

  21. References • Millen, “A Necessarily Parallel Attack”, FMSP ‘99, http://www.csl.sri.com/users/millen/capsl/ • Crow, Owre, Rushby, Shankar, Srivas, “A Tutorial Introduction to PVS” WIFT ’95, http://pvs.csl.sri.com/ • Butler, “An elementary tutorial on formal specification and verification using PVS”, http://pvs.csl.sri.com/ • Owre, Shankar, Rushby, “The PVS Specification Language”, http://pvs.csl.sri.com/ • Owre, Shankar, Rushby, “Users Guide for the PVS Specification and Verification System”, http://pvs.csl.sri.com/
