Threads Cannot be Implemented as a Library

1. Threads Cannot be Implemented as a Library Hans-J. Boehm

2. About the Author • Hans-J. Boehm • Boehm conservative garbage collector • Parallel GC for C/C++ • Participated in revising the Java Memory Model • Co-authored the Memory model for multi-threaded C++ • Compiler-centric background

3. Introduction • Multi-threaded programs are ubiquitous • Many programs need to manage logically concurrent interactions • Multiprocessors are becoming mainstream • Desktop computers support multiple hardware contexts, which makes them logically multiprocessors • Multi-threaded programs are a good way to utilize increasing hardware parallelism

4. Thread support • Threads included in language specification • Java • C# • Ada • Multiple-threads not a part of language specification • C/C++ • Thread support provided by add-on libraries • Posix threads • Ptreads standard does not specify formal semantics for concurrency

5. Memory Model • Which assignments to a variable by one thread can be seen by a concurrently executing thread • Sequential Consistency • All actions occur in a total order (the execution order) that is consistent with program order; furthermore, each read r of a variable v sees the value written by the write w to v such that: • w comes before r in the execution order, and • There is no other write w´ such that w comes before w´ and w´ comes before r in the execution order • Happens-Before • Simple version of java memory model, slightly too weak • Weak • Allows for compiler optimizations

6. Surprising results caused by statement reordering • r1 & r2 are local, A & B are shared • Write in one thread • Read of same variable in another thread • Write and read are not ordered by synchronization • -

7. Surprising results caused by statement reordering • r1 & r2 are local, A & B are shared • Write in one thread • Read of same variable in another thread • Write and read are not ordered by synchronization • Race Condition!

8. Pthread approach • Provided as add-on library • Include hardware instructions to prevent reordering • Avoid compiler reordering by appearing as an opaque function • Require disciplined style of synchronization • Valid 98% of the time • What about the other two percent??

9. Pthread correctness • Apparently correct programs may fail intermittently • New compiler or hardware induced failure • Poor performance may force slight rule bending • Difficult for programmer to reason about correctness • Let’s see some examples why…..

10. Concurrent modification • Pthread specifications prohibit races • But is this enough? x=y=0 if(x==1) ++y; ++y; if(x!=1) –-y; if (y==1) ++x; ++x; if (y!=1) --x; Is x==1 y==1 acceptable? • No for sequential consistent interpretation • But, if the compiler makes the modifications on the right, there is a race! T1: T2:

11. Why threads cannot be implemented as a library • Argument ( 1 ) • Since the compiler is unaware of threads, it is allowed to transform code subject only to sequential correctness constraints and produce a race • But, example is kind of far-fetched

12. Rewriting of Adjacent Data • Bit fields on a little endian 32-bit machine • Concurrent write to memory location, not variable. struct {int a:17; int b:15 } x; Implementation of x.a=42 { tmp = x; tmp &= ~0x1ffff; //mask off old a tmp | 42; x = tmp; //replace x }

13. Rewriting of Adjacent Data • Bit fields on a little endian 32-bit machine • Concurrent write to memory location, not variable. struct {int a:17; int b:15 } x; Implementation of x.a=42 { tmp = x; tmp &= ~0x1ffff; //mask off old a tmp | 42; x = tmp; //replace x } Updates to x.b introduce a race

14. Why threads cannot be implemented as a library • Argument ( 2 ) • For languages like C, if the specification does not define when adjacent data can be overwritten, then race conditions can be introduced. If so, then the compiler would know to avoid this optimization

15. Register promotion for(…) { … if (mt) pthread_mutex_lock(…); x = … x …. if ( mt) pthread_mutex_unlock(…); } • Repeatedly update globally shared variable x r = x; for(…) { … if (mt) { x = r; pthread_mutex_lock(…); r = x; } r = … r …. if ( mt) { x = r; pthread_mutex_unlock(…); r = x; } } x = r;

16. Register promotion for(…) { … if (mt) pthread_mutex_lock(…); x = … x …. if ( mt) pthread_mutex_unlock(…); } • Repeatedly update globally shared variable x • Using profile feedback or static heuristics • it becomes beneficial to promote x to a registerr in the loop r = x; for(…) { … if (mt) { x = r; pthread_mutex_lock(…); r = x; } r = … r …. if ( mt) { x = r; pthread_mutex_unlock(…); r = x; } } x = r;

17. Register promotion for(…) { … if (mt) pthread_mutex_lock(…); x = … x …. if ( mt) pthread_mutex_unlock(…); } • Repeatedly update globally shared variable x • Using profile feedback or static heuristics • it becomes beneficial to promote x to a registerr in the loop • Thus • Extra reads and writes introduce possible race conditions r = x; for(…) { … if (mt) { x = r; pthread_mutex_lock(…); r = x; } r = … r …. if ( mt) { x = r; pthread_mutex_unlock(…); r = x; } } x = r;

18. Why threads cannot be implemented as a library • Argument ( 3 ) • If the compiler is not aware of existence of threads, and a language specification does not address thread-specific semantic issues, then optimizations might cause race conditions

19. Implications • Compilers forced into blanket removal of optimization in many cases • Or perhaps a toned-down version of the optimization • This can degrade performance of code that is not thread-specific

20. Sieve of Eratosthenes For(mp=start ; mp < 10,000 ; ++mp) if(!get(mp)) { . for(multiple = mp ; multiple <100,000,000 ; multiple+=mp) . if(!get(multiple)) . set(multiple); } 10,000 10,002 10,003..10,005 10,007….. 100,000,000 false false false false false false true true false false false true true truetrue false false true true true true truefalsetrue true true true trueprimetrue

21. Synchronizing global array access For(mp=start ; mp < 10,000 ; ++mp) if(!get(mp)) { . for(multiple = mp ; multiple <100,000,000 ; multiple+=mp) . if(!get(multiple)) . set(multiple); } • Mutex • Spin-locks • Non-blocking • None

22. Performance results • Pthreads library approaches (1)&(2) cannot reach optimal levels • This algorithm is designed for a weak memory model, which is not possible using thread library

23. Performance results • Similar results for hyper-threaded p4 processor • Even more dramatic performance differences moving to a more parallel processor • Itanium  HT P4

24. Additional Implications of Pthreads approach x = 1; pthread_mutex_lock(lock); y = 1; pthread_mutex_unlock(lock); • If we choose to allow concurrent accesses to concurrent variables, within library code • Unpredictable results can occur without language specifications pthread_mutex_lock(lock); y = 1; x= 1; pthread_mutex_unlock(lock);

25. Additional Implications of Pthreads approach x = 1; pthread_mutex_lock(lock); y = 1; pthread_mutex_unlock(lock); • If we choose to allow concurrent accesses to concurrent variables, within library code • Unpredictable results can occur without language specifications pthread_mutex_lock(lock); x = 1; y = 1; pthread_mutex_unlock(lock); Is this a problem??

26. Conclusion • Compilers can introduce race conditions where there are none in source code • Library code cannot intervene • Impossible to achieve the performance gains of a multiprocessor without direct fine-grained use of atomic operations • Which is impossible to do in a library based thread implementation • Why not just use the java memory model • Designed to preserve type-safety • which C/C++ are not • C++ needs it’s own memory model

27. REFERENCES • JSR-133 Expert Group, “JSR-133: Java Memory Model and Thread Specification” http://www.cs.umd.edu/~pugh/java/memoryModel • Daniel P. Bovet,Marco Cesati, “Understanding the Linux Kernel 3rd Edition” O’Reilly • Sarita V. Adve, Kourosh Gharachorloo, “Shared Memory Consistency Models: A Tutorial” Digital Western Research Laboratory

28. Appendix • Happens-Before

29. Appendix • Section 5

30. Appendix • Section 5(cont)
