  1. Verification reuse Itai Nadler Verification leadership seminar 2005

  2. DV reuse – introduction • Reuse (obvious) advantages - Shortens the verification time. - It’s a mean of transferring knowledge between teams. - Will decrease the chance for unfound Bugs !!! • There are two kinds of reuse - across similar projects ( next generation designs or similar designs) - Between IP developments and system development.

  3. Basic requirements for easy reuse • Organization infrastructure - Shared data base for common Verification Components - Adopting similar verification methodologies across the organization. - When possible , joint specification of the VC by all optional users. • Building a VC dedicated for reuse - High quality documentation. - Modular architecture ( for instance make it easy to replace the registers description ). - Build a hardware interface - Build a User interface

  4. IP to System reuse • Leverage the knowledge of the IP verification engineer. - IP engineer can recommend a basic set of tests which ensures the proper integration of the IP. - The same thing could also be done by issuing a reduced set of verification goals. • Building the VC for reuse in system - Checkers and scoreboards should be based on monitors ( and not the drivers). - Co-exist with other VC and with several instantiation of the same VC. - When possible , the system verification engineer should be involved in the specification of the VC, in order to adjust the VC for system special needs ( for example different handling of interrupts ).

  5. Interesting case of reuse • The following slide was presented by Roy Sofer in the 2003 Verisity users group convention.

  6. S D R A M PC PC SoC EMIF MIPS Eth eVC GMII eVC Ethernet MAC master Host Protocol eVC Eth eVC GMII slave Intr • Need to shift the already written • e-drivers/BFM to c-code that will • be executed by the CPU. • We get the 2 Master Problem. • The CPU become a degenerate • master of a test. • Almost all the Host side eVC • transaction should be called by • the CPU OPCODE WR_RD CMD OPCODE Back-Door eVC Legend : Virtual “rd_wr_vbus” function DV PDR Release w/o change System VBUS eVC According to eRM/sVM -eVC Drivers and test become passive. -only the monitor is still active • Our goal is to extend the eRM/sVM methodology and reuse the whole IP DV • Activate the IP DV Drivers/BFM and tests within SoC test (no change in IP DV – transparent) • No static verification (no pre-defined tests) • One master of the test flow VBUS eVC
