  1. Task Force APIAccounting Process Implementation SOMA document validation process V1.0, 24.3.2011

  2. TSO B TSO A Possible SOMA validation process «good case» Internal data collec- tion and validation Internal data collec- tion and validation Data available 9:00 9:01, Send TSO_A-SOMA V1 Assemble SOMA Validate SOMA=> but no data 9:02, neg. ACK, Data not yet available Wait for TSO B 9:19 Data available 9:20, Send TSO_B-SOMA V1 Assemble SOMA - Validate SOMA=> Everything OK - Prepare SOMA V2 9:2x, pos. ACK on TSO_B-SOMA V1 TSO_B-SOMA done 9:2x, Send TSO_A-SOMA V2 (content = TSO_A-SOMA V1) - Validate SOMA => Everything OK 9:3x, pos. ACK on TSO_A-SOMA V2 TSO_A-SOMA done Note: The used times are only for illustration purposed

  3. TSO B TSO A Possible SOMA validation process «bad case» Internal data collec- tion and validation Internal data collec- tion and validation Data available 9:00 9:01, Send TSO_A-SOMA V1 Assemble SOMA Validate SOMA=> but no data 9:02, neg. ACK, Data not yet available Wait for TSO B 9:19 Data available 9:20, Send TSO_B-SOMA V1 Assemble SOMA - Validate SOMA=> Everything OK - Prepare SOMA V2 9:2x, pos. ACK on TSO_B-SOMA V1 TSO_B-SOMA done 9:2x, Send TSO_A-SOMA V2 (content = TSO_A-SOMA V1) - Validate SOMA => Outside tolerance 9:2x+, neg. ACK, Data outside tolerance - Analyse problem- ev. call TSO B- ev. adjust data- Prepare SOMA V3 Phone call Discuss problem 9:30, Send TSO_A-SOMA V3 - Validate SOMA => Everything OK 9:3x, pos. ACK on TSO_A-SOMA V3 TSO_A-SOMA done Note: The used times are only for illustration purposed
