  1. System Design Proposal For Dar Es Salaam City Surveillance Installed by Special Security NB: The map we use from that City Surveillance Plan was sample for Sao Paulo Brazil Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  2. TOC • Project Overview: - City Coverage and Requirements - Monitoring Areas • System Architecture • Solution Design: • Focused Objects Definition • Camera Selections and Setting • Design and Installation • Management • Networking Design • Conclusion Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  3. Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  4. City: Police Force, Asuncion Dar Es Salaam City • City Coverage: 5 regions each region has the same pattern (i.e. no. of blocks) • A main high way connects to City • Requirements: • To monitor traffic, car, pedestrians, etc for the safety of citizens • 5 monitoring spots in each region • Recording 24 hrs, 30 days as a cycle • Local recording and management at each police station • Central management to view City Emap at HQ of police station • Local: 8fps for recording and 5 fps for live-view • Central: 1fps monitoring via CMS Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  5. Dar Es Salaam City Surveillance System Diagram-- for All Zones NVR server*2 NVR server*1 CMS NVR server*2 NVR server/ workstation Police Zones Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com NVR server*4 NVR server*5 Police HQ Station

  6. Internet City Surveillance System Diagram – In Dar Es Salaam City Tazara Flyover Surface Power Box Intersection Power Box CMS Control Center Police Station (HQ) Highway Power Box Legend: UPS PoE Switch Router Tazara Flyover Underground Power Box Cat 5 Cable NVR server/ Workstation Police Division Power Cable Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com DRB Pedestrian Bridge Power Box

  7. Focused Object Definition Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  8. Design and Installation Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security(T) Ltd Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  9. Design and Installation Prepared By Gerald Temu, Title: Director of Marketing & Operation, Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  10. Camera Model Recommendation Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security(T)Ltd Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  11. Camera Model Recommendation Prepared By Gerald Temu, Title: Director of Marketing & Operation, Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  12. Camera Model Recommendation Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  13. Camera Setting – Traffic Lights Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  14. Bus Number Driver’s Name Bus Plate Number Bus Company Toll and Contact Number

  15. Camera Setting – City Streets & Bridges Surface/ Underground Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  16. Equipment and Item list Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  17. PC Selection Note: Please consider the same recommended specification or at a higher specification for the PC server for the City Surveillance project. Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  18. Switch Selection For this specific project you can consider using: Police Division (local): - Catalyst 3550-24 PWR Pólice Station (HQ): - Cisco Catalyst 6500 Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  19. Bandwidth & Storage Recording will be based on 2 megabit bandwidth as maximum. However will be setup as variable frame rate and bit rate to save storage costs. Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  20. Storage, Bandwidth & Powering-Intersection • Camera: • TCM-5311 x 4 • CAM-6630 x 1 • Recording hours per day: 24 • Recording days per month: 30 • Total bandwidth required: 19.5Mbps • Total storage required: 4,860GB (5TB) • Local storage (within 30 days):10TB (HDD) • Tape backup (30 ~ 90 days):Tape recycle (LTO3, 400GB) • Camera: • TCM-5311 x 4 by POE Switch • CAM-6630 x 1 by AC-24V • Power Consumption: • Watt: 93W Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  21. Storage, Bandwidth & Powering- Flyover Underground & Surface • Camera: • ACM-7411 x 4 • ACM-5811 x 2 • ACM-5611 x 2 • Recording hours per day: 24 • Recording days per month: 30 • Total bandwidth required: 31.2Mbps • Total storage required: 10108GB (5TB) • Local storage (within 30 days):10TB (HDD) • Tape backup (30 ~ 90 days):Tape recycle (LTO3, 400GB) Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  22. Management • System setup • Camera setup • Recording/ Backup Police Station (Local site) ACTi NVR Server • Monitoring • Playback • eMap • Event Handling • Synchronized Playback Police Bureau (Center site) ACTi CMS Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  23. Conclusion and benefit • Unified solution for simplified management • Single window throughout project implementation • Superior video quality for each monitoring site • Competitive P/P value delivered • Full range of product for flexible expansion NB: SPECIAL SECURITY was company recommended to Distribute and Supply ACTi products In East & Central Africa. Prepared By Gerald Temu, Title: Director of Marketing & Operation, Special Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com

  24. Thank you Police force Tanzania Prepared By Gerald Temu, Title: Director of Marketing & Operation, Cyber Security Contact: +255717002558, +255778843476, +22762851963, temu_gerald@yahoo.com
