  1. Wireless Optical IP in the Last Mile Implementing the network

  2. Agenda • Overview • OptiSwitch Master product line • Mesh Implementation • Service Management • Applications

  3. Overview • The system responsible for “making it all come together” is the OptiSwitch MasterTM • Enables carrier class access network • Provides the flexibility for specific carrier business model

  4. OptiSwitch MasterTM (OSM) • Modular system • 10/100/1000 Ethernet interfaces • Unique software: based on Linux OS • Unique Hardware: based on Network Processors

  5. OptiSwitch MasterTM Implementation of Linux OS • Code stability • Fast time to market • Cutting edge applications

  6. OptiSwitch MasterTM • Network Processors are micro-code programmable network computing components • Wire-speed manipulation of any part of an IP datagram • Becomes more powerful when combined with an open PC architecture and open source software

  7. OptiSwitch MasterTM • Carrier class recovery: IP Routing tools • Carrier Class subscriber privacy: IP security tools • Carrier Class Service: SLA tools

  8. Routing • SONET level recovery • Internal hardware designed for failure detection in milliseconds • Software customization and integration with policing tools

  9. Security • IP Intrusion control provides the best non-encryption based security solution. • No client application at the user’s site • Easy to implement user-to-user attacks • Tools for denial of Service prevention • Easy to manage

  10. SLA tools • Per flow Classification and Policing tools • Definition of bandwidth guaranty, resource reservation, prioritization and scheduling • Rate limiting per flow according to layer 2-7 (tag, IP address, TCP/UDP port etc.) • Traffic engineering for traffic burst-size control • Definition of bandwidth violation policies

  11. Mesh implementation • “No-drop” recovery and re-routing time • SONET level convergence • Also supports Ring and star topologies • Provides RF fail over path combined with SLA • Simple integration with OptiSwitch systems

  12. Service Management • User’s authentication, Authorization to resources, and Accounting with RADIUS • Default gateway aggregation • Tools for IP address manipulation • Network Topology management

  13. Backbone Campus Application

  14. Applications TereScope Link 2 TereScope Link 1 TereScope Link 3 RF Link Voice Gateway/ IP PBX E-Business Residential

  15. Voice Gateway/ IP PBX E-Business Residential Application TereScope Link 3 Frame SLA? RF Link

  16. Ethernet OSM in the CO • AAA • Routing • Classification Uplink Router OSM OptiSwitch Central Office SDH

  17. Thank You
