  1. Your universal enclosure 159 LC SERIES

  2. 159 LC • 159 Cubic inches of space with a hinged lid • Made from all galvanized steel, powder coated white, with a rubber gasket to seal enclosure closed • The 159LC follows the NEMA 4 specification ratings

  3. 159 LC • Enclosure weighs 4.34 lbs • Overall height 12 7/8” x 10 1/8” wide x 3 ½” deep • Inside height 11 15/16” x 6” wide x 2 ¼” deep

  4. 159 LC • New design allows door hinge to be floating, which makes seating the gasket extremely even • Integrated pipe clamp/wall mount system, uses hose clamps for infinite pipe diameter • New, all thumb screw design, allows use of screwdriver or tool less entry and maximum seal with rubber gasket • Lids is lockable

  5. 159 LC • Grounding screws on inside and outside • 3 antennae KO’s on top, 3 antennae KO’s on bottom, with 1 Ethernet pass thru hole • Enclosure comes with 4 standoffs on the inside for use with customized sub plate(optional) • Kit includes 2 ss 036 hose clamps with range of 46-70mm, & 1 universal standoff kit for mounting any board

  6. 159 LC Series
