1. Architecture

2. Architecture • Planning and designing a successful system • Use tried and tested techniques • Easy to maintain • Robust and long lasting

3. The DVD Swap Shop • Written in VB.NET • Suffers from much poor design • Available for download from the module web site / blackboard • We shall look at a quick demo of what the program does

4. Security Issues • The standard login for the program is • User name mjdean@dmu.ac.uk • Password password123 • What happens if we use the following? • User name hi' or '1'='1 • User name hi' or '1'='1

5. SQL Injection Attacks • SQL is a language designed for querying database • It stands for Structured Query Language • Most commonly abbreviated to • SQL or Sequel (as in Sequel Server) • We are going to use SQL later in this module and you will be learning it in a parallel module so it won’t do any harm to show you a little SQL now

6. Concatenation • select * from Users where EMail = '" & EMail & "' and UserPassword = '" & Password & "'" • With the following account • mjdean@dmu.ac.uk • password123 • This concatenates to … • select * from Users where EMail = 'mjdean@dmu.ac.uk' and UserPassword = 'password123'

7. The Injection Attack • select * from Users where EMail = '" & EMail & "' and UserPassword = '" & Password & "'" • With the following “account” • hi' or '1'='1 • This concatenates to … • select * from Users where EMail = 'hi' or '1'='1' and UserPassword = 'hi' or '1'='1'

8. How it Works • The single speech mark has terminated the string early • Since 1 always equals 1 we return all of the records • There are more than zero records so it logs the user in as the first account • The first user on any system is often the administrator • This is not a lesson on SQL injection attacks • it does server to illustrate the vulnerabilities of poor architecture

9. Maintenance • DVD Swap Shop built on Access • Not the best choice for an internet application • Change to another database e.g. SQL Server • DVD.MDB becomes DVD.MDF

10. Web page 1 Database Name Web page 2 Database Name Conduit Class Database Web page 3 Database Name Web page 4 Database Name The Problem 100 page site with ten references to the database per page = 1000 changes to the code!

11. Scalability • How many of you have FaceBook or Twitter on your phone? • How would we modify the DVD swap shop so there is a phone app that does the same? • Re-design the pages • However what do we do about the functionality?

12. Compare the Following Pages

13. Other Issues to Think About • Dealing with International Markets • Dealing with Different Computer Platforms

14. Dealing with International Markets

15. Amazon Search

16. Dealing with Different Computer Platforms • Mobile Apps - Apple/Android/WinMo 7 & 8 • Tablet computers e.g. iOS / Windows 8/ Android • Windows Computers • Linux machines • Servers running Apache / IIS • What is the technology that makes it possible to support such a range of platforms?

17. Presentation (Interface) Middle Tier Business Logic (Objects/Classes) Data Layer Database Simple Three Layered Architecture

18. Some Benfits • The interface has no knowledge of the structure of the database • Middle tier handles communication of data • Database may be switched with no impact on interface • All functionality in the middle tier • This means we may bolt on many different interfaces

19. Presentation (Interface) Web browser Data Layer Database Middle Tier Business Logic (Objects/Classes) Presentation (Interface) Mobile phone app Multiple Interfaces Single System The big plus here is that if we change the functionality of the middle tier, any applications that are built on it instantly benefit.

20. Overview of Driving Test 4
