  1. Binary & hex I/O

  2. Binary input : read in a binary number from keyboard, followed by a carriage return. character strings of 1’s & 0’ we need to convert each character to a bit value& collects the bits in a register

  3. Algorithm • Clear BX….. To hold the binary value • Input a character …….. ‘1’ or ‘0’ • WHILE character <> CR then Convert character to binary value Left shift BX Insert value into LSB of BX Input a character END_WHILE

  4. The algorithm assumes • Input characters are either “0”,”1”or CR • At most 16 bit are input • BX is shifted left to make room and the OR operation is used to insert the new bit into BX

  5. Code XOR BX,BX ; clear BX MOV AH,1 ; input character function INT 21H ;read a character WHILE_: CMP AL,0DH ; CR? JE END_WHILE ; yes , done AND AL,0FH ; no, convert to binary value SHL BX,1 ;make room for new value OR BL,AL ;put value in BX INT 21H ;read a character JMP WHILE_ ;loop back END_WHILE :

  6. Binary output: Outputting contents of BX in binary … Shift Operation

  7. Algorithm FOR 16 times DO Rotate left BX /* BX … output CF… MSB */ IF CF = 1 THEN output ‘1’ ELSE output ‘0’ END_IF END_FOR

  8. Binary output MOV AH, 2 MOV CX, 16 TOP: ROL BL,1 JC ONE JNC ZERO ONE: MOV DL,'1‘ ; or ( 31h) JMP DISPLAY ZERO: MOV DL,'0‘ ; or (30h ) DISPLAY: INT 21H LOOP TOP

  9. Hex Input Digits “0” to “9” & letters “A” to “F” Followed by a carriage return

  10. Assume • Only upper case letters are used. • The user inputs no more than 4 hex characters. • BX must be shifted 4 times to make room for a hex value.

  11. Algorithm for hex input • Clear BX • Input a hex character • WHILE character <> CR DO • Convert character to binary value • Left shift BX 4 times • Insert value into lower 4 bits of BX • Input a character END_WHILE

  12. Code XOR BX,BX; clear BX MOV CL,4 MOV AH,1; input character function INT 21H;read a character WHILE_: CMP AL,0DH; CR? JE END_WHILE; yes , done ; convert character to binary digit CMP AL,39H ; a digit ? JG LETTER ; no, a letter ; input is a digit AND AL,0FH ; convert digit to binary value JMP SHIFT ; go to insert in BX

  13. Code LETTER: SUB AL, 37H ; convert letter to binary value SHIFT: SHL BX,CL ;make room for new value ; insert value into BX OR BL,AL ; put value into low 4 bits of BX INT 21H ; input a character JMP WHILE_ ; loop until CR END_WHILE:
