  1. Design and Use of Memory-Specific Test Structures to Ensure SRAM Yield and Manufacturability F. Duan, R. Castagnetti, R. Venkatraman, O. Kobozeva and S. Ramesh LSI Logic Corporation

  2. Outline • Products need very high-density and high-performance memories without sacrificing yield and manufacturability • LSI Logic’s Industry-leading 1.87um2 embedded SRAM bitcell in 130 nm CMOS SoC technology • Need for SRAM-specific test structures to ensure robustness and manufacturability • Accurately shows process-design interaction • Correlate to SRAM yield • Direct feedback for rapid process-improvement • Accurate SRAM device and cell characterization • RAMPCM for design rule robustness validation • Summary ISQED-2003

  3. LSI Logic SRAM Technology for SoC • Smallest production high-density SRAM in 180nm and 130nm technology • Fabricated by standard CMOS SoC process “High-Density and High-Performance 6T-SRAM for System-on-Chip in130 nm CMOS Technology,” 2001 VLSI Technology Symposium, pp. 105-106, W. Kong, R. Venkatraman, R. Castagnetti, F. Duan and S. Ramesh. ISQED-2003

  4. Why Do We Need for SRAM-specific Test Structure? An Example (a) (b) (c) Structures to test metal bridging ISQED-2003

  5. Electrical Test Data Only structure (a) detects the early metal /contact bridging ISQED-2003

  6. Features of Our Structures • Compared to the conventional structures, our structures: • More product-driven than process-development-driven • Accurately show process-design interaction • Correlate to functionality and yield directly • Identify the yield limiting factors quickly for fast process or design improvements. • Sensitive enough for ongoing monitoring and process transfers. ISQED-2003

  7. Test Structure Design and Results • Yield correlation and improvement • SRAM manufacturability • SRAM device and cell characterization • RAMPCM chip • Functional SRAM test chip • Used for SRAM design rule validation ISQED-2003

  8. Test Structures of Front-end Critical Layer Monitor • Critical layers: island, poly and contact • Monitor bridging current from intra- and inter- layers • Monitor shared-contact connection ISQED-2003

  9. Test Structures of Back-end Monitor • Monitor bridging current from: • Contact and metal 1 (blue arrows) • Metal 2 (red arrows) • Metal 3 (black arrow) ISQED-2003

  10. Example of a Test Structure For Poly Bridging Test array Test cell ISQED-2003

  11. Poly Bridging Data 100,000 cells No poly bridging found in SRAM ISQED-2003

  12. Metal Bridging and Correlation to SRAM Yield 100,000 cells Detected early metal /contact bridging ISQED-2003

  13. Metal Bridging and Correlation to SRAM Yield (cont.) Metal bridging identified as yield limiting factor ISQED-2003

  14. Metal 1 Bridging Data after Process Improvement 100,000 cells No metal bridging seen after improvement ISQED-2003

  15. Test Structures for Manufacturability • An illustration of test structure • List of test structures • Electrical data ISQED-2003

  16. An Illustration of the Test Structure • Sizing poly by 5% per side • Build test cell to test its effects on: • Poly to poly bridging • Poly to contact bridging • Pull down transistor leakage ISQED-2003

  17. List of Test Structures for SRAM Manufacturability • Sizing island • Island to island bridging • Transistor leakage • Sizing poly • Poly to poly bridging • Poly to contact bridging • Transistor leakage • Sizing contact • Contact to poly bridging • Contact / metal 1 bridging • Contact resistance • Sizing metal 1 • Metal 1 / contact bridging ISQED-2003

  18. Effect of Poly Sizing – SRAM Poly to Poly Bridging 100,000 cells Poly to poly spacing in SRAM is robust ISQED-2003

  19. Effect of Poly Sizing – SRAM Poly to Contact Bridging 100,000 cells Poly to contact spacing in SRAM is robust ISQED-2003

  20. Effect of Poly Sizing – SRAM Pull Down Transistor Leakage 100,000 cells All leakage currents are within device model spec ISQED-2003

  21. Test Structures for Characterization • Transistors in SRAM • Due to the environmental difference (OPC, etc), transistors in SRAM may behave differently compared to isolated devices • Need to measure transistor in the real SRAM array for accurate characterization • An illustration of test structures • Electrical data for transistor measurement • Cell characterization ISQED-2003

  22. Illustration of Measuring SRAM Transistor ISQED-2003

  23. Transistors in SRAM Cell • Measure all the 6 transistors in 6T SRAM • To compare cell symmetry between left and right • To compare with isolated devices • Measure 4 orientations ISQED-2003

  24. Saturation Current of Pass Gate Transistors (Left, Right, Isolated Counterpart) Good symmetry and little difference between iso. / dense ISQED-2003

  25. Saturation Current of Pull Down Transistors (Left, Right, Isolated Counterpart) Good symmetry and little difference between iso. / dense ISQED-2003

  26. Threshold Voltage of Pull Down Transistor in 4 Directions (0, 90, 180, 270) Little difference of 4 different orientations ISQED-2003

  27. SNM and Cell Current of 1.87 um2 Bitcell(130nm Generation) 0.001 0.003 0.005 0.007 0.009 Cell Current (A) Butterfly curve Cell current (L&R) ISQED-2003

  28. RAMPCM Test Chip • RAMPCM is a functional SRAM test chip that is used to prove robustness of the most critical SRAM design rules. • Size of the chip is 1M with 1024 row by 1024 columns • Every 64 columns evaluate one critical SRAM design rule ISQED-2003

  29. RAMPCM Test Chip (continued) • 8 most critical design rules are evaluated • Each design rule has 4 variations, distributed across array • Data logs from failing dies are used to extract numbers of failing bits per design rule variation ISQED-2003

  30. RAMPCM Test Data -- Normalized Failure Rate Within process window Design rules used in 1.87 um2 cell Note: More than 50Mb data for each variation. This data proves the robustness and manufacturability of the 1.87 um2 bitcell ISQED-2003

  31. Use of Test Structures in 90nm and Beyond • Increased design-process interaction in 90nm and beyond (Ex. OPC variation) • The test structure methodology we have presented today becomes even more necessary for 90 nm and beyond • Gate leakage impact for SRAM must be accurately evaluated • We have designed such necessary test structures for the 90nm node ISQED-2003

  32. Summary • We have designed and used SRAM-specific test structures as effective tool for SRAM technology development. • The data from these SRAM test structures provides us direct feedback on process-design interactions and helps to identify yield-limiting factors early and quickly. • The data (including from RAMPCM) is analyzed to prove the robustness and manufacturability of our industry-leading 1.87 um2 SRAM cell. ISQED-2003
